3.5.4 Input and output currents / overload of the 230 V devices
Input currents 230 V devices
Device size 07 09
Rated input current @ U
N = 230 V Iin / A 8 14
Rated input current UL @ U
N _UL = 230 V Iin_UL / A 8 14
Rated input current DC @ U
N_dc = 325 V
1)
Iin_dc / A 3.3 6.2
Rated input current DC UL @ U
N_UL_dc = 325 V
1)
Iin_dc_UL / A 3.3 6.2
Table 22: Input currents of the 230 V devices
1)
The values resulting from rated operation with B6 rectier circuit and mains choke 4% UK.
Output currents 230 V devices
Device size 07 09
Rated output current @ U
N = 230 V IN / A 4 7
Rated output current UL @ U
N_UL = 230 V IN_UL / A 4 7
Rated output overload (60s)
1)
I60s / % 150
Rated output overload (3s)
1)
I3s / % 200
Overcurrent
1)
IOC / % 240
Table 23: Output currents of the 230 V devices
1)
The values refer in % to the rated output current IN.
