Page #103 background imageLoading...
Page #103 background image
103
Table of ContentsSetting UpWi-Fi StreamingUsing KEF Connect AppFAQ and Troubleshooting
18.4 IR Command Codes
LSX II works with universal programmable remote control provided that the remote
control manufacturers have implemented KEF IR command codes in their remote
controls.
The following table lists the command codes required.
Code Format:
NEC
Factory Code:
0x01
Functions Function codes
1 Power on/off toggle 0x40
2 Mute/un-mute toggle 0x20
3 Play/Pause 0x18
4 Forward 0x52
5 Next source 0x58
6 Volume up 0x60
7 Volume down 0xA0
8 Backward 0xD2
9 Power ON 0x38
10 Power OFF 0x3A
11 Mute 0x48
12 Un-mute 0x4A
13 Source: Wi-Fi 0x30
14 Source: Bluetooth 0x2A
15 Bluetooth pairing 0x98
16 Source: AUX 0x02
17 Source: Optical 0x0A
18 Preset volume (30 %) 0x78
19 Source: HDMI 0x88 / 0x8A
20 Source: USB 0x1A
21 Previous source 0xD0

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KEF LSX II and is the answer not in the manual?

KEF LSX II Specifications

General IconGeneral
Design2-way bass reflex
Dimensions240 x 155 x 180 mm (9.5 x 6.1 x 7.1 in.)
Drivers0.75 inch tweeter
Amplifier PowerLF: 70W Class D, HF: 30W Class D
Frequency Response49Hz - 47kHz (-6dB)
ConnectivityHDMI ARC, TOSLINK Optical, 3.5mm Auxiliary Input, USB-C, Ethernet, Wireless: Dual-band 2.4GHz/5GHz Wi-Fi; Bluetooth 5.0
Bluetooth CodecSBC, AAC
Streaming ServicesSpotify Connect, Tidal Connect, Amazon Music, Qobuz, Deezer
Resolution24-bit/192kHz
Weight3.6kg (8.0lbs) Master Speaker, 3.6kg (8.0lbs) Satellite Speaker
Finish OptionsMineral White, Lava Red, Carbon Black
