Auxiliary input jack Plays audio input from a source (e.g. turntable with
phono stage) through a 3.5 mm audio cable.
S
Subwoofer output jack Connects a subwoofer to the speakers through an
RCA cable.
V
TV port Plays audio input from a source (e.g. ARC port of
television) through an HDMI cable.
T
Primary/Secondary
connection port
Connects the Primary Speaker and Secondary
Speaker with the inter-speaker cable.
N
Network port Connects the speakers to a router with a LAN cable.
This port is colour-coded yellow.
A
AC input connector Connects the speakers to the power source with the
power cables.
5.3 Bottom Panel
• Rubber feet are found on the bottom panel of each speaker to prevent slipping on a
hard surface.
• Additionally, a threaded hole (1/4–20 UNC) is also available for mounting on various
accessories (see chapter “Installation Accessories”).
