KEF LSX Owner's Manual

9
The LSX slave speaker contains the slave M/S PAIRING button, the interspeaker cable connection for CABLE MODE, and the AC power
cable connector.
In normal operation, the indicator on the front panel of the Slave speaker will not be lit.
4 – Audio Specifications
THE UNI-Q
LSX features the patented Uni-Q driver for crystal clear audio reproduction no matter where you
are situated.
The new 4” Uni-Q driver array is the same signature KEF technology used throughout KEF’s
speaker line.
Uni-Q has been in constant development since 1988. Through precise positioning of the drivers, all
frequencies are produced from the same point in space.
The effect is an amazing spread of sound. Uni-Q eliminates the tiny ‘HiFi sweet spot’ that only
allows one or two listeners to hear the music in its highest quality. Coupled with an extremely
natural response, the beauty of the sound is enjoyed equally by everyone in the room.
Slave Speaker

KEF LSX Specifications

General

Frequency Response	54Hz - 28kHz (±3dB)
Frequency Range	49Hz - 47kHz (-6dB)
Max. SPL	102dB
Outputs	Subwoofer Output
Design	2-way bass reflex
Driver	Uni-Q driver array: HF: 19mm (0.75in.) aluminium dome, LF/MF: 115mm (4.5in.) magnesium/aluminium alloy cone
Amplifier Power	LF: 70W, HF: 30W
Wireless Features	Wi-Fi, Bluetooth 4.2
Streaming Services	Spotify Connect, Tidal
Inputs	TOSLINK Optical, 3.5mm Auxiliary
Resolution	24-bit/96kHz
Dimensions	240 x 155 x 180 mm (H x W x D)
Weight	3.6kg per speaker
Finish Options	Black, Blue, White
