Keithley 2001 - Page 65

62
:CALibration
:PROTected
:DC
:ZERO
:LOW <NRf>
:HIGH <NRf>
:LOHM <NRf>
:HOHM <NRf>
:OPEN
:CALCulate
:UNPRotected
:ACCompensation
User calibration subsystem.
Low-thermal short calibra-
tion step.
+2V DC calibration step.
+20V DC calibration step.
20kΩ calibration step.
1MΩ calibration step.
Open circuit calibration
step.
Calculate DC cal constants.
All commands in this subsystem
are not protected by CAL
switch.
Perform user AC calibration
(disconnect all cables).
Table 25. DISPlay command summary
Command Description
:DISPlay
[:WINDow[1]]
:TEXT
:DATA <a>
:DATA?
:STATe <b>
:STATe?
:DATA?
Path to locate message to top display.
Path to control user text messages.
Define ASCII message “a” using up
to 20 characters.
Query text message.
Enable (1 or ON) or disable (0 or
OFF) message mode.
Query text message mode (0 or 1).
Query data on top portion of display.
:WINDow2
:TEXT
:DATA <a>
:DATA?
:STATe <b>
:STATe?
:DATA?
Path to locate message to bottom display.
Path to control user text messages.
Define ASCII message “a” using up
to 32 characters.
Query text message.
Enable (1 or ON) or disable (0 or
OFF) message mode.
Query text message mode (0 or 1).
Query data on bottom portion of dis-
play.
Table 24. CALibrate command summary (cont.)
Command Description
