Keithley 2010 Quick Reference Guide

9
Maximum inputs for the Model 2010 are summarized in
Table 1.
Basic measurement procedure
1. Connect the instrument as explained in “Instrument
connections”.
2. From the function keys, select the desired measure-
ment function.
3. Use the RANGE keys to select autoranging or a
manual range. Pressing the AUTO range key tog-
gles autoranging. You can select a different range
with the ▲ and ▼ RANGE keys.
4. Take a reading from the display.
Table 1. Maximum inputs
Function Maximum input
DCV 1000V peak
ACV 750V rms, 1000V peak, 8
× 10
7
V•Hz
DCI 3A, 250V dc
ACI 3A 250V rms
FREQ (PERIOD) 1000V peak, 8
× 10
7
V•Hz

Keithley 2010 Specifications

General

Frequency Range	3 Hz to 300 kHz
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	3 A
DC Current Accuracy	0.05%
AC Current Range	3 A
Resistance Accuracy	0.01%
Interface	GPIB, RS-232
Power Supply	50 Hz or 60 Hz
