6. TECHNICAL DATA
Kempoweld 3200 3200W
Connection voltage
3 ~ 400 V 380 V -10 % ... 415 V +6 % 380 V -10 % ... 415 V +6 %
3 ~ 230 V 220 V -10 % ... 240 V +6 % 220 V -10 % ... 240 V +6 %
Connection capacity 230 V / 400 V
40 % ED 13,6 kVA 13,6 kVA
60 % ED 10,0 kVA 10,0 kVA
100 % ED 6,6 kVA 6,6 kVA
Main cable / fuses
220 - 240 V 4 x 2,5 mm² / 20 A delayed 4 x 2,5 mm² / 20 A delayed
380 - 415 V 4 x 2,5 mm² / 16 A delayed 4 x 2,5 mm² / 16 A delayed
Connection to wire feeder unit
30 V / 250 VA 30 V / 250 VA
- Fuse delayed
8 A 8 A
Loading capacity (nominal values)
40 % ED 320 A / 32 V 320 A / 32 V
60 % ED 265 A / 27 V 265 A / 27 V
100 % ED 205 A / 24 V 205 A / 24 V
Control range 40 steps
40 – 320 A / 15 – 32 V 40 – 320 A / 15 – 32 V
Open circuit voltage 40 steps
15 – 40 V 15 – 40 V
Open circuit power
< 50 W < 50 W
Efficiency
320 A / 32 V 75 % 75 %
Power factor
320 A / 32 V 0,95 0,95
Temperature class
H (180 °C) H (180 °C)
Operation temperature range
-20 ... +60 °C -20 ... +60 °C
Storage temperature range
-40 ... +60 °C -40 ... +60 °C
Degree of protection
IP23S IP23S
EMC class
A A
Minimun short circuit power Ssc of
supply network *
0.9 MVA 0.9 MVA
Cooling unit power
- - - 230 V / 250 VA
- Fuse delayed
- - - 2 A
External dimensions
lenght 990 mm 990 mm
width 530 mm 530 mm
height 880 mm 1090 mm
Weight
106 kg 118 kg
* See paragraph 2.2
16
Kempoweld 3200, 3200W / © Kemppi Oy / 1117
