LOADING THE FILLER WIRE AND AUTOMATIC FEED2.7
Automatic wire feed makes wire spool changes faster. When changing the wire spool, the
pressure of feed rolls need not be released.
Simply ensure that the groove of the feed roll matches the diameter of ller wire used. Release
the wire end from the spool and cut o any deformed section. Be careful the wire does not
spill from the spool sides.
Straighten about 20cm of ller wire and ensure the tip has no sharp edges. File if necessary, as
a sharp wire edge may damage the wire gun liner - particularly softer plastic liners.
Present the ller wire tip to the back of the wire feed rolls and press the wire inch switch on
the wire feed panel. Feed the wire to the gun contact tip and prepare to weld.
NOTE! Smaller diameter ller wires may need to be loaded manually - with the feed roll pressure
arms released. This is because it is easy to over estimate the pressure required to feed these smaller
ller wires. Too high feed roll pressures can easily deform ller wires and contribute to later feeding
problems.
DURATORQUE™ 400, 4 WHEEL WIRE FEED MECHANISM2.8
Wire guide tubes
Ss, Al, Fe,
Mc, Fc
ø 0.6 ... 1.6 mm ø 2.5/64 mm,
W000762,
silver, plastic
ø 2.5/33 mm,
W000956,
silver, plastic
ø 2.0 mm,
W000624,
plastic
ø 1.6 ... 2.4 mm ø 3.5/64 mm,
W001430,
silver, plastic
ø 3.5/33 mm,
W001431,
silver, plastic
ø 3.5 mm,
W001389,
plastic
Fe, Mc, Fc ø 0.6 ... 0.8 mm ø 1.0/67 mm,
W001432,
white, steel
ø 2.0/33 mm,
W001435,
orange, steel
ø 2.0 mm,
W000624,
plastic
ø 0.9 ... 1.6 mm ø 2.0/64 mm,
W001433,
orange, steel
ø 3.5 mm,
W001389,
plastic
ø 1.6 ... 2.4 mm ø 4.0/63 mm,
W001434,
blue, steel
ø 4.0/33 mm,
W001436,
blue, steel
ø 3.5 mm,
W001391,
brass
24.8.2005 12:55
10
FastMig MXF65, 67 / © Kemppi Oy / 0920
