SF 53 PANEL OVERVIEW FOR FASTMIG SYNERGIC5.14
9. 14.10. 15.11. 16.12. 17.13.
m/min
A V
ARC FORCE
DYNAMICS
WIRE INCH
GAS TEST
MMA
SYNERGIC
PROGRAM
PANEL
SF 53 MLS™
U
MIG
SET
ON
CH
PANEL
SAVE
SET
quick setup ch clear ch remote
MEMORY
POWER
weld
4T
SETUP
SELECT
MMA
2T
data
W001257
1. 2. 3. 4. 5. 6. 7. 8.
Main switch1.
a) Wire feed speed/welding current/sheet thickness display 2.
b) Display of selected adjustable parameter
Activation of welding dynamics adjustment3.
Selection of gas/water cooled MIG gun4.
Gas purge5.
Weld data: Last used welding parameters shown in displays6.
Wire inch7.
a) Welding voltage display 8.
b) Display of value of selected adjustable parameter
1-MIG selection check/1-MIG welding arc selection activation9.
a) Selection of MIG process: 2T/4T 10.
b) Changing of basic parameters of the unit, SETUP (long pressing)
Selection of welding process MIG,1-MIG, MMA, FR-MIG *)11.
Activation of additional MIG function parameter adjustment12.
Selection of additional MIG functions13.
a) Adjustment of wire feed speed 14.
b) Adjustment of welding power setting (1-MIG)
c) Adjustment of MMA welding current
d) Selection of SETUP parameter
e) Selection of 1-MIG arc (material)
Memory channels, storage of MIG parameters15.
a) Welding voltage display 16.
b) Adjustment of length of welding arc (1-MIG)
c) Adjustment of MIG dynamics
d) Adjustment of SETUP parameter
e) Selection of 1-MIG arc
Manual control/remote control unit selection17.
*) FR-MIG for root pass welding is not included in standard delivery.
22
FastMig MXF65, 67 / © Kemppi Oy / 0920
