EN
CONNECTION OF SYSTEM2.2
Water cooled system: FastMig Pulse + MXF + FastCool 102.2.1
1.
4.
8.
2.
3.
9.
5.
6.
7.
1. MXF wire feed unit
2. FastMig Pulse power source
3. FastCool water cooler and power connection
4. Gas supply
5. MMA electrode holder
6. Remote control device
7. Liquid cooled welding Gun
8. Power cable
9. Earth return lead and clamp
7
FastMig MXF65, 67 / © Kemppi Oy / 0920
