Kemppi KempGouge ARC 800 User Manual

EN
6. ORDERING NUMBERS
KempGouge ARC 800 (incl. transport unit)
6284000
Connector cable
4 X 16 mm, 5 m W000869
Connector cable
4 X 16 mm, 10 m W003408
Earthing cable
95 mm², 5 m (DIX120) 61840951
Earthing cable
95 mm², 10 m (DIX120) 61840952
Earthing cable
120 mm², 5 m 61841201
Earthing cable
120 mm², 10 m 61841202
Remote control R10
6185409
7. TECHNICAL SPECIFICATIONS
KempGouge ARC 800
Connection voltage
3~ 50/60 Hz 400 V -15 ... +20%
Rated power
50% ED 44 kVA
100% ED 35 kVA
Primary current
50% ED I
1max
65 A
100% ED I
1
51 A
Connection cable
H07RN-F 4G16 (16 mm²)
Fuse (recommended)
63 A delayed
Idle power
120 W
Efficiency
0.90
Power factor
0.90
Load capacity at 40 °C
50% ED 800 A / 44 V
100% ED 600 A / 44 V
Current adjustment range
20 A – 800 A
Open circuit voltage
50 V
Gouging carbon
max. size ø 13 mm
Recommended pressure of the
compressed air
500 – 700 kPa (5 – 7 bar)
Storage temperature range
-40 °C ... +60 °C
Operating temperature range
-20 °C ... +40 °C
EMC class
A
Minimun short circuit power Ssc of
supply network *
7.6 MVA
Degree of protection
IP23S
Dimensions
(without/with transport unit)
Length 590/700 mm
Width 230/660 mm
Height 885/1,400 mm
Weight 94/115 kg
Maximum load of lifting lug
200 kg
* See paragraph 2.3.
12
KempGouge ARC 800 / © Kemppi Oy / 1117
