EN
TIG welding panel MTL – basic functions
2.
3.
4.
7.
5.
9.
6.
8.
14.
13.
12.
11.
10.
1.
1. Selection of MMA welding
2. Selection of arc force (MMA) and pedal low/high (minimum and maximum welding current)
displays and regulation (TIG welding)
3. Selection of hot start (MMA) and gas test (TIG welding)
4. Selection of TIG welding, 4T and 2T functions of torch switch
5. Selection of HF/contact and water ll function
6. Selection of panel, foot pedal and remote control
7. Selection of welding parameters
8. Adjustment of welding parameters
9. Pre-gas 0 – 10 s
10. Upslope 0
– 10 s
11. Welding current
12. Downslope 0 – 15 s
13. Post-gas 1 – 30 s
14. Return to welding current
1. MMA
Select MMA welding by pressing the selection button of MMA welding. The led is lit when
MMA is on.
2. Arc force
Press the arc force button and you will see the numerical value corresponding to the MMA
dynamics in the display. Factory setting for all electrode types is zero. You can change the
value by turning the pulse potentiometer. If numerical value is adjusted negative (-1...9) the
arc is softened, and the amount of spatter decreases when welding at the upper end of the
recommended current range of the electrode. On the positive side (1...9) the arc is rough.
In TIG mode, you can select the max. and min. current for the foot pedal (PEDAL LO/HI).
12
Master, MasterTig, MasterCool 10 / © Kemppi Oy / 1112
