Kemppi WFX 200 User Manual

5
© Kemppi Oy / 1736
EN
WFX 200, WFX 200 P Fe, WFX 200 P Ss, WFX 200 AMC and WFX 200-T
4.
1.
2.
3.
7.
6.
5.
8.
9.
1. Control panel
2. Remote control connector
3. Voltage sensing cable connection
4. Euro gun connector
5. Shielding gas connection
6. Connection for control cable
7. Welding current cable connector
8. Lead-in and clamping of cooling
liquid hoses
9. Measurement cable connection

Kemppi WFX 200 Specifications

General

Brand	Kemppi
Model	WFX 200
Category	Welding System
Language	English
