Kenwood DMX7722DABS User Manual

FM radio section
Frequency Range
(Frequency Step)
87.5 MHz to 108 MHz
(50 kHz)
Usable Sensitivity
(S/N: 30 dB)
6.2 dBf (0.56 μV/75 Ω)
Quieting Sensitivity
(DIN S/N: 46 dB)
15.2 dBf (1.58 μV/75 Ω)
Frequency Response
(±3.0 dB)
30 Hz to 15 kHz
Signal to Noise Ratio 68 dB (MONO)
Selectivity (±400 kHz) > 80 dB
Stereo Separation 40 dB (1 kHz)
LM radio section
Frequency Range
(Frequency Step)
153 kHz to 279 kHz (9 kHz)
Usable Sensitivity 45 μV
MW radio section
Frequency Range
(Frequency Step)
531 kHz to 1 611 kHz
(9 kHz)
Usable Sensitivity 28.5 μV
Video section
Color System of
External Video Input
NTSC/PAL
External Video Input
Level (RCA jack)/
(mini jack)
1 Vp-p/75 Ω
1 Vp-p/75 Ω
External Audio Max
Input Level (mini
jack)
2 V/25 kΩ
Video Input Level
(RCA jack)
1 Vp-p/75 Ω
Video Output Level
(RCA jack)
1 Vp-p/75 Ω
Audio section
Maximum Power
Output (Front & Rear)
50 W × 4
Typical Power
Output (Front & Rear)
Full Bandwidth Power (at less
than 1% THD) 22 W × 4
Output Frequency
Band
20 Hz to 88 000 Hz
Preout Level 2.5 V/10 kΩ
Preout Impedance ≤ 600 Ω
Speaker Impedance 4 Ω to 8 Ω
General
Operating Voltage 12 V DC car battery
Installation
Dimensions
(W × H × D)
Main unit:
180 mm × 100 mm × 75 mm
With sleeve:
182 mm × 111 mm × 74 mm
Weight (Main Unit) 1.2 kg (including trim plate
and sleeve)
Design and specifications are subject to change
without notice.
SpecificationsSpecifications
Tweeter HPF: Frequency (Hz):
1k/1.6k/2.5k/4k/5k/6.3k/8k/
10k/12.5k
Slope (dB/Oct.):
−6/−12
Gain (dB):
–8/–7/–6/–5/–4/–3/–2/–1/0
Phase: Normal/Reverse
Mid Range HPF: Frequency (Hz):
Through/30/40/50/60/70/
80/90/100/120/150/180/
220/250
Slope (dB/Oct.):
−6/−12
Mid Range LPF: Frequency (Hz):
1k/1.6k/2.5k/4k/5k/6.3k/8k/
10k/12.5k/Through
Slope (dB/Oct.):
−6/−12
Gain (dB):
–8/–7/–6/–5/–4/–3/–2/–1/0
Phase: Normal/Reverse
Subwoofer LPF: Frequency (Hz):
30/40/50/60/70/80/90/100/
120/150/180/220/250/
Through
Slope (dB/Oct.):
−6/−12
Gain (dB):
–8/–7/–6/–5/–4/–3/–2/–1/0
Phase: Normal/Reverse
60
ENGLISH
00DMX7722DABSE.indb6000DMX7722DABSE.indb60 2022/10/1716:202022/10/1716:20

Kenwood DMX7722DABS Specifications

General

Display Size	6.8 inches
Resolution	800 x 480 pixels
Touchscreen	Yes
Bluetooth	Yes
Apple CarPlay	Yes
Android Auto	Yes
DAB+ Radio	Yes
USB Input	Yes
Rear View Camera Input	Yes
Audio Formats	MP3, WMA, AAC, WAV, FLAC
AUX Input	Yes
DVD Player	No
CD Player	No
AM/FM Tuner	Yes
Steering Wheel Control	Yes
Power Output	4 x 50W
Pre-out	3 (Front, Rear, Subwoofer)
Video Formats	MPEG1, MPEG2, MPEG4
