Kenwood eXcelon KDC-X792 User Manual

12
|
KDC-X792/KDC-X692/KDC-MP738U/KDC-MP638U
G-Analyzer Operation
Function of KDC-X792
G-Analyzer Control
You can adjust following G-Analyzer Control items ;
Item Setting/ Page Setting overview
> “GMENU” G- Graphic/ Downloaded
G-Graphic*
1
/ G-Meter*
2
/
G-Counter*
2
G-Analyzer display
Selection
> “GMA” > “STOP.
W”
(page 13) G-Analyzer Stop Watch
> “GMA” > “HP” (page 14) G-Analyzer Horsepower
Analysis
> “GMA” > “RESET” (page 14) G-Analyzer Reset
> “GMA” > “LEVEL” Level1 – 3*
3
G-Counter Level seting
> “GMA” > “CAL”* (page 13) G-Analyzer Calibration
setup
> “GMA” > “HP
SET” *
(page 12) G-Analyzer vehicle setup
* Can be set in standby state.
*
1
G-Graphic can be switched to customized pictures. Refer
to <Picture downloading> (page 21).
*
2
The value of G-Meter display and G-Counter display can
be reset by <G-Analyzer Reset> (page 14).
*
3
Calibrating G-Point. Setting the level according to the
kinds of vehicles. In the case of driving situations calling
for few accelerations, set the G-Point up to “Level1”. In
the case of frequent accelerations, set it up to “Level3”.
1 Enter Display Control mode (In Display Type F)
Select “DISP”.
For how to select Function Control item, refer to
<Function Control> (page 6).
2 Enter G-Analyzer item mode
Turn the Control knob or push it towards left
or right.
Press the Control knob.
3 Select the G-Analyzer item you want to set
Turn the Control knob or push it towards left
or right.
4 Exit G-Analyzer item mode
Press the Control knob.
In Standby mode
G-Analyzer Vehicle Setup
Enter vehicle weight or class to calculate
horsepower.
1 Enter G-Analyzer vehicle weight setup
mode (In Display Type F)
Select “DISP” > “GMA” > “HP SET” > “WEIGHT”.
For how to select Function Control item, refer to
<Function Control> (page 6).
“WEIGHT INPUT” is displayed.
2 Enter weight input
Operation type Operation
Select the weight numbers Turn the Control knob.
Select the digits to enter Push the Control knob towards right
or left.
3 Exit G-Analyzer vehicle wight setup mode
Press the Control knob.
4 Enter G-Analyzer vehicle class setup mode
Select “DISP” > “GMA” > “HP SET” > “CLASS”.
“CLASS SELECT” is displayed.
5 Select vehicle class
Turn the Control knob.
“Mid Size”/ “Full Size”/ “SUV”/ “Van/ Mini-Van”/
“Pickup Truck”/ “Sporty”/ “Compact”
6 Exit G-Analyzer vehicle class setup mode
Press the Control knob.
