Kenwood NX-5200 User Guide

INSTALLING THE (OPTIONAL) ANTENNA
.
Screw the antenna into the connector
on the top of the transceiver by
holding the antenna at its base and
turning it clockwise until secure.
.
INSTALLING THE BELT CLIP
.
If necessary, attach the belt clip using
the two supplied M3 x 8 mm binding
screws.
Note:
●
If the belt clip is not installed, its
mounting location may get hot during
continuous transmission or when left
sitting in a hot environment.
CAUTION
Do not use glue which is designed to prevent screw loosening when
installing the belt clip, as it may cause damage to the transceiver.
Acrylic ester, which is contained in these glues, may crack the
transceiver’s back panel.
Optional
antenna
Belt clip
M3 x 8 mm
screws
15

Kenwood NX-5200 Specifications

General

IP Rating	IP67
Zones	128
GPS	Yes
Bluetooth	Yes
Voltage Range	7.5V DC ±20%
Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Battery Life	14 hours (Digital mode)
Digital Protocol	NXDN, DMR
Display	LCD
