Kenwood NX-5200 User Guide

TRANSMITTING
1
Select the desired zone and channel using the Selector knob
and the [Zone Up]/ [Zone Down] or [Channel Up]/ [Channel
Down] keys.
2
Press the PTT switch and speak into the microphone. Release
the PTT switch to receive.
●
The LED indicator lights red while transmitting and green while
receiving a signal. This indicator can also be disabled by your
dealer.
●
For best sound quality at the receiving station, hold the
microphone approximately 1.5 inches (3 cm to 4 cm) from your
mouth.
RECEIVING
Select the desired zone and channel. If signaling has been
programmed on the selected channel, you will hear a call only if
the received signal matches your transceiver settings.
25

Kenwood NX-5200 Specifications

General

IP Rating	IP67
Zones	128
GPS	Yes
Bluetooth	Yes
Voltage Range	7.5V DC ±20%
Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Battery Life	14 hours (Digital mode)
Digital Protocol	NXDN, DMR
Display	LCD
