Kenwood PW-A series User Manual

PW-A
42
PARTS LIST
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
J30-0671-04 SPACER
J73-0835-02 PCB(UNMOUNTED)
C101 CQ93FMG1H103J CAP. PLASTIC FILM 0.01µ 5% 50V
C102 C90-4747-05 CAP. ELECTRO 3300µ 20% 25V
C103 CQ93FMG1H103J CAP. PLASTIC FILM 0.01µ 5% 50V
C104 C90-4749-05 CAP. ELECTRO 2200µ 20% 35V
C105 C90-4749-05 CAP. ELECTRO 2200µ 20% 35V
C109 C90-4749-05 CAP. ELECTRO 2200µ 20% 35V
C110 C90-4824-05 CAP. ELECTRO 100µ 20% 6.3V
C111 C90-4824-05 CAP. ELECTRO 100µ 20% 6.3V
C112 C90-4824-05 CAP. ELECTRO 100µ 20% 6.3V
C115 C91-1128-05 CAP.CERAMIC 0.1µ -25 50V
C116 C91-1128-05 CAP.CERAMIC 0.1µ -25 50V
C118 C90-4825-05 CAP. ELECTRO 47µ 20% 16V
C119 C90-4825-05 CAP. ELECTRO 47µ 20% 16V
C120 C90-4825-05 CAP. ELECTRO 47µ 20% 16V
C123 C90-4825-05 CAP. ELECTRO 47µ 20% 16V
C201 CE04BW1A102M CAP. ELECTRO 1000µ 20% 10V
C203 CE04BW1E471M CAP. ELECTRO 470µ 20% 25V
C204 CE04BW1E471M CAP. ELECTRO 470µ 20% 25V
C205 C91-2698-05 CAP. FILM 0.01µ 10% 630V
C301 C90-4839-05 CAP. ELECTRO 22000µ 20% 25V
C302 C90-4846-05 CAP. ELECTRO 8200µ 20% 50V
C303 C90-4841-05 CAP. ELECTRO 6800µ 20% 50V
C304 C90-4841-05 CAP. ELECTRO 6800µ 20% 50V
C401 CF92JV1H104J CAP. METAL FILM 0.1µ 5% 50V
C402 CF92JV1H104J CAP. METAL FILM 0.1µ 5% 50V
C403 CF92JV1H104J CAP. METAL FILM 0.1µ 5% 50V
C404 CF92JV1H104J CAP. METAL FILM 0.1µ 5% 50V
CN103 E40-7808-05 BORDE CONNECTOR 17P
CN104 E40-3299-05 PIN CONNECTOR 2P
CN105 E40-3302-05 PIN CONNECTOR 5P
CN201 E40-3369-05 PIN CONNECTOR 10P
CN202 E40-3367-05 PIN CONNECTOR 8P
CN203 E40-3299-05 PIN CONNECTOR 2P
CN301 E40-7292-05 PIN CONNECTOR 8P
CN302 E40-7392-05 PIN CONNECTOR 6P
CN303 E40-7292-05 PIN CONNECTOR 8P
CN304 E40-7292-05 PIN CONNECTOR 8P
CN401 E40-3367-05 PIN CONNECTOR 8P
CN402 E40-3365-05 PIN CONNECTOR 6P
CN403 E40-7669-05 PIN CONNECTOR 4P
CN501 E40-7627-05 PIN CONNECTOR 5P
CN502 E40-7627-05 PIN CONNECTOR 5P
D101 S1VB20 DIODE
D102 S1VB20 DIODE
D104 DSM1D2 DIODE
D105 DSM1D2 DIODE
D106 MTZ16JB DIODE, ZENER
D107 1SS133 DIODE
D108 MTZ11JC DIODE, ZENER
D401 S5VB20 DIODE
D402 S4VB20 DIODE
Name & Description
D403 S4VB20 DIODE
D404 S4VB20 DIODE
IC101 TA7805S IC
IC102 TA7805S IC
IC103 TA79005S IC
IC106 NJM4558D IC
IC107 TA79L012P IC
P301 E23-1516-05 TERMINAL SCREW
P302 E23-1516-05 TERMINAL SCREW
P401 E23-0401-05 TERMINAL
P402 E23-0401-05 TERMINAL
P403 E23-0401-05 TERMINAL
P404 E23-0401-05 TERMINAL
Q101 2SC4793 TR.SI, NPN
R106 RD14BB2C471J RES.CARBON 470 5% 1/6W
R107 RN14BK2C5600F RES. METAL FILM 560 1% 1/6W
R108 RN14BK2C1001F RES. METAL FILM 1k 1% 1/6W
R109 RN14BK2C6201F RES. METAL FILM 6.2k 1% 1/6W
R110 RN14BK2C6201F RES. METAL FILM 6.2k 1% 1/6W
R111 RN14BK2C6201F RES. METAL FILM 6.2k 1% 1/6W
R112 RN14BK2C5601F RES. METAL FILM 5.6k 1% 1/6W
R113 RD14BB2C471J RES.CARBON 470 5% 1/6W
R115 RN14BK2C2201F RES. METAL FILM 2.2k 1% 1/6W
R203 RD14BB2C100J RES.CARBON 10 5% 1/6W
R204 RD14BB2C100J RES.CARBON 10 5% 1/6W
R301 RD14BB2C203J RES.CARBON 20k 5% 1/6W
R302 RD14BB2C203J RES.CARBON 20k 5% 1/6W
R303 RD14BB2C203J RES.CARBON 20k 5% 1/6W
R304 RD14BB2C203J RES.CARBON 20k 5% 1/6W
S501 S66-0607-05 POWER SWITCH
S601 S62-0646-05 SLIDE SWITCH
S602 S62-0646-05 SLIDE SWITCH
TH101 102AT-2 THERMISTOR
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
2
Name & Description
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
1
Parts No.
Ref. No
Ref. No
Parts No.
POWER SUPPLY UNIT (X68-2300-00)
