Kenwood PW-A series User Manual

PW-A
43
PARTS LIST
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
1
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
Ref. No
Name & Description
-00
-01
Parts No.
-02
1 1 1 E02-0217-05 SOCKET
1 AT29C010A-KX3 PROGRAMED ROM
1 AT29C010A-LS3 PROGRAMED ROM
1 AT29C010A-MS0 PROGRAMED ROM
0.5 0.5 0.5 J73-0751-12 PCB(UNMOUNTED)
2 N67-3010-41 SCREW, SEMS PAN HD (M3✽10)
C1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C2 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C3 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C4 1 1 1 C92-1547-05 CAP.ELECTRO 100µ 20% 10V
C5 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C6 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C7 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C8 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C9 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C11 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C12 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C13 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C14 1 CC73GSL1H102J CAP.CERAMIC 1000p 5% 50V
C15 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C16 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C17 1 C92-0523-05 CAP.ELECTRO 10µ 20% 16V
C18 1 C92-0523-05 CAP.ELECTRO 10µ 20% 16V
C19 1 C92-0523-05 CAP.ELECTRO 10µ 20% 16V
C20 1 C92-0523-05 CAP.ELECTRO 10µ 20% 16V
C21 1 C92-0523-05 CAP.ELECTRO 10µ 20% 16V
C22 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C23 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C24 1 1 C92-1547-05 CAP.ELECTRO 100µ 20% 10V
C25 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C26 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C27 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C29 1 1 C92-1547-05 CAP.ELECTRO 100µ 20% 10V
C32 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C33 1 1 C92-1547-05 CAP.ELECTRO 100µ 20% 10V
C34 1 1 C92-1547-05 CAP.ELECTRO 100µ 20% 10V
C35 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C36 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C37 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
CN1 1 1 E40-7854-05 PIN CONNECTOR 19P
CN2 1 1 E40-7854-05 PIN CONNECTOR 19P
CN3 1 1 E40-7853-05 PIN CONNECTOR 5P
CN4 1 E40-7854-05 PIN CONNECTOR 19P
CN5 1 E40-7854-05 PIN CONNECTOR 19P
CN6 1 E40-7853-05 PIN CONNECTOR 5P
CN8 1 1 1 E40-3299-05 PIN CONNECTOR 2P
D1 1 1SS355 DIODE
IC1 1 1 1 HD6413007F20 IC
IC2 1 1 1 AT29C010A-12JI IC
IC3 1 1 1 GM76C256CLLFW7 IC
IC4 1 1 ML60851D IC
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
2
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
Ref. No
Name & Description
-00
-01
Parts No.
-02
IC5 1 1 1 TC74HC541AF IC
IC6 1 1 1 TC74HC541AF IC
IC7 1 1 1 TC74HC541AF IC
IC8 1 1 1 TC74HC245AF IC
IC10 1 NAT9914BPL IC
IC11 1 SN75160BDW IC
IC12 1 SN75161BDW IC
IC13 1 1 SN751178(NS) IC
IC14 1 1 BA033FP IC
IC15 1 1 1 TC74HC04AF IC
IC16 1 1 1 TC74HC08AF IC
IC17 1 1 1 TC74HC32AF IC
IC18 1 MAX232ECSE IC
J1 1 E58-0613-05 SQUARE SOCKET; GP-IB
J2 1 E59-0607-05 D-SUB PLUG
J3 1 E58-0606-05 MODULAR JACK
J4 1 1 E70-0660-05 TERMINAL BLOCK
J5 1 1 E58-0638-05 SQUARE SOCKET; USB-B
L1 1 1 L92-0226-05 FERRITE CHIP
L2 1 1 L92-0226-05 FERRITE CHIP
PH1 1 1 PC357NT IC, PHOTO COUPLER
Q1 1 RN1404 TR.SI, NPN
Q2 1 RN1401 TR.SI, NPN
Q3 1 RN1401 TR.SI, NPN
R1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R2 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R3 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R4 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R5 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R7 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R8 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R9 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R10 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R11 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R12 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R13 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R14 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R15 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R20 1 1 RK73FB2A513J RES. CHIP (2✽1.25) 51k 5% 1/10W
R21 1 1 RK73FB2A513J RES. CHIP (2✽1.25) 51k 5% 1/10W
R22 1 1 RK73FB2A513J RES. CHIP (2✽1.25) 51k 5% 1/10W
R23 1 1 RK73FB2A513J RES. CHIP (2✽1.25) 51k 5% 1/10W
R24 1 1 RK73FB2A472J RES. CHIP (2✽1.25) 4.7k 5% 1/10W
R25 1 1 RK73FB2A472J RES. CHIP (2✽1.25) 4.7k 5% 1/10W
R26 1 1 RK73FB2A472J RES. CHIP (2✽1.25) 4.7k 5% 1/10W
R27 1 1 RK73FB2A472J RES. CHIP (2✽1.25) 4.7k 5% 1/10W
R28 1 1 RK73FB2A152J RES. CHIP (2✽1.25) 1.5k 5% 1/10W
R29 1 1 RK73FB2A561J RES. CHIP (2✽1.25) 560 5% 1/10W
R30 1 1 RK73FB2A220J RES. CHIP (2✽1.25) 22 5% 1/10W
R31 1 1 RK73FB2A220J RES. CHIP (2✽1.25) 22 5% 1/10W
R32 1 1 RK73FB2A105J RES. CHIP (2✽1.25) 1M 5% 1/10W
R33 1 1 RK73FB2A302J RES. CHIP (2✽1.25) 3k 5% 1/10W
R34 1 1 RK73FB2A105J RES. CHIP (2✽1.25) 1M 5% 1/10W
R35 1 1 RS14DB2H151J RES.METAL OXIDE FILM 150 5% 1/2W
INTERFACE UNIT (X72-1540-XX)
