Kenwood PW-A series User Manual

PW-A
45
PARTS LIST
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
R25 R92-1061-05 1 RES. JUMPER
R26 R92-1061-05 1 RES. JUMPER
R27 R92-1061-05 1 RES. JUMPER
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
2
Ref. No
Name & Description
Parts No.
-07
-06
-05
-04
-03
-02
-01
-00
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
J73-0839-03 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 PCB(UNMOUNTED)
CN1 E40-3306-05 1 1 1 1 1 1 1 1 PIN CONNECTOR 9P
D1 1SS133 1 1 1 1 1 1 1 1 DIODE
D2 1SS133 1 1 1 1 1 1 1 1 DIODE
D3 MTZ3.6JB 1 1 1 1 1 1 1 1 DIODE, ZENER
D4 1SS133 1 1 1 1 DIODE
D5 1SS133 1 1 1 1 DIODE
D6 1SS133 1 1 1 1 DIODE
D7 1SS133 1 1 1 1 DIODE
D8 MTZ3.6JB 1 1 1 1 DIODE, ZENER
D9 MTZ3.6JB 1 1 1 1 DIODE, ZENER
D10 1SS133 1 DIODE
D11 1SS133 1 DIODE
D12 1SS133 1 1 1 DIODE
D13 1SS133 1 1 1 DIODE
D14 MTZ3.6JB 1 DIODE, ZENER
D15 MTZ3.6JB 1 1 1 DIODE, ZENER
D16 1SS133 1 DIODE
D17 1SS133 1 DIODE
D18 MTZ3.6JB 1 DIODE, ZENER
D19 1SS133 1 1 1 1 1 1 1 1 DIODE
D20 1SS133 1 1 1 1 DIODE
D21 1SS133 1 1 1 1 DIODE
D22 1SS133 1 DIODE
D23 1SS133 1 1 1 DIODE
D24 1SS133 1 DIODE
Q1 2SC5198(R) 1 1 1 1 1 1 1 1 TR.SI, NPN
Q2 2SA1941(R) 1 1 1 1 TR.SI, PNP
Q2 2SC5198(R) 1 1 1 1 TR.SI, NPN
Q3 2SA1941(R) 1 1 1 TR.SI, PNP
Q3 2SC5198(R) 1 TR.SI, NPN
Q4 2SA1941(R) 1 1 1 1 TR.SI, PNP
R1 RD14DB3A3R9J 1 1 1 1 RES. CARBON 3.9 5% 1W
R1 RD14DB3A5R6J 1 RES. CARBON 5.6 5% 1W
R1 RD14DB3A6R8J 1 1 1 RES. CARBON 6.8 5% 1W
R2 RD14BB2C821J 1 1 1 1 1 1 1 1 RES. CARBON 820 5% 1/6W
R3 RD14DB3A3R9J 1 1 1 1 1 RES. CARBON 3.9 5% 1W
R3 RD14DB3A5R6J 1 RES. CARBON 5.6 5% 1W
R3 RD14DB3A6R8J 1 1 RES. CARBON 6.8 5% 1W
R4 RD14BB2C821J 1 1 1 1 1 1 1 1 RES. CARBON 820 5% 1/6W
R5 RD14DB3A3R9J 1 1 1 1 RES. CARBON 3.9 5% 1W
R6 RD14BB2C821J 1 1 1 1 RES. CARBON 820 5% 1/6W
R7 RD14DB3A3R9J 1 RES. CARBON 3.9 5% 1W
R8 RD14BB2C821J 1 RES. CARBON 820 5% 1/6W
R9 R92-1061-05 1 RES. JUMPER 0
R10 R92-1061-05 1 1 1 RES. JUMPER 0
R20 R92-1061-05 1 RES. JUMPER 0
R21 R92-1061-05 1 RES. JUMPER
R22 R92-1061-05 1 RES. JUMPER
R23 R92-1061-05 1 RES. JUMPER
R24 R92-1061-05 1 RES. JUMPER
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
1
Ref. No
Name & Description
Parts No.
-07
-06
-05
-04
-03
-02
-01
-00
INPUT UNIT (X72-1620-XX)
