Kenwood PW-A series User Manual

PW-A
46
PARTS LIST
Ref. No
Parts No.
Name & Description
C48 1 1 1 1 1 1 1 1 1 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C49 1 1 1 1 1 1 1 1 1 1 CK73GB1H103K CAP. CERAMIC 0.01µ 10% 50V
C50 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C51 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C52 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C53 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C54 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C55 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C56 1 1 1 1 1 1 1 1 1 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C57 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C58 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C59 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C60 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C61 1 1 1 1 1 1 1 1 1 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C62 1 1 1 1 1 1 1 1 1 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C63 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C69 1 1 1 1 1 1 1 1 1 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C70 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C71 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C72 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C73 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C74 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C75 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C76 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C77 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C78 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C79 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C80 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C81 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C82 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C83 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C84 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C85 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C86 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C87 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C88 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C89 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C90 1 1 1 1 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C91 1 1 1 1 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C92 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C93 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C94 1 1 1 1 1 CC73GCH1H471J CAP. CERAMIC 470p 5% 50V
C95 1 1 1 1 1 CK73GB1H104K CAP. CERAMIC 0.1µ 10% 50V
C96 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C97 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C98 1 CK73GB1H223K CAP. CERAMIC 0.022µ 10% 50V
C98 1 CK73GB1H473K CAP. CERAMIC 0.047µ 10% 50V
C98 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C99 1 1 1 1 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C100 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C101 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C102 1 1 1 1 1 CK73GB1H103K CAP. CERAMIC 0.01µ 10% 50V
C103 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C104 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C105 1 1 1 1 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
2
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
–09
–08
–07
–06
–05
–04
–03
–02
–01
–00
Ref. No
Parts No.
Name & Description
1 1 1 1 1 1 1 1 1 1 J73-0752-12 PCB(UNMOUNTED)
C1 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C2 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C3 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C4 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C5 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C6 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C7 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C8 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C9 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C10 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C11 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C12 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C13 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C14 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C15 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C16 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C17 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C18 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C19 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C20 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C21 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C22 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C23 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C24 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C25 1 1 1 1 1 1 1 1 1 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C26 1 1 1 1 1 1 1 1 1 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C27 1 1 1 1 1 1 1 1 1 1 CC73GCH1H471J CAP. CERAMIC 470p 5% 50V
C28 1 1 1 1 1 1 1 1 1 1 CK73GB1H104K CAP. CERAMIC 0.1µ 10% 50V
C29 1 CK73GB1H103K CAP. CERAMIC 0.01µ 10% 50V
C29 1 1 1 1 1 CK73GB1H223K CAP. CERAMIC 0.022µ 10% 50V
C29 1 1 1 CK73GB1H473K CAP. CERAMIC 0.047µ 10% 50V
C29 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C30 1 1 1 1 1 1 1 1 1 1 CK73GB1H103K CAP. CERAMIC 0.01µ 10% 50V
C31 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C32 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C33 1 1 1 1 1 1 1 1 1 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C34 1 1 1 1 1 1 1 1 1 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C35 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C36 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C37 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C38 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C39 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C40 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C41 1 1 1 1 1 1 1 1 1 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C42 1 1 1 1 1 1 1 1 1 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C43 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C44 1 1 1 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C45 1 1 1 1 1 1 1 1 1 1 CC73GCH1H471J CAP. CERAMIC 470p 5% 50V
C46 1 1 1 1 1 1 1 1 1 1 CK73GB1H104K CAP. CERAMIC 0.1µ 10% 50V
C47 1 1 1 1 CK73GB1H223K CAP. CERAMIC 0.022µ 10% 50V
C47 1 1 1 1 CK73GB1H473K CAP. CERAMIC 0.047µ 10% 50V
C47 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
1
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
–09
–08
–07
–06
–05
–04
–03
–02
–01
–00
AMP UNIT (X73-2320-XX)
