Kenwood PW-A series User Manual

PW-A
47
PARTS LIST
Ref. No
Parts No.
Name & Description
D5 1 1 1 1 1 1 1 1 1 1 1SZ52 DIODE, ZENER
D6 1 1 1 1 1 1 1 1 1 1 DAP202K DIODE
D7 1 1 1 1 1 1 1 1 1 1 DAP202K DIODE
D8 1 1 1 1 1 1 1 1 1 1 DAP202K DIODE
D9 1 1 1 1 1 1 1 1 1 1 DAP202K DIODE
D10 1 1 1 1 1 1SS300 DIODE
D10 1 1 1 1 1 1SS301 DIODE
D11 1 1 1 1 1 1 1 1 1 1 1SS300 DIODE
D12 1 1 1 1 1 UDZS5.6B DIODE, ZENER
D12 1 1 1 1 1 1SS355 DIODE
D13 1 1 1 1 1 1 1 1 1 1 UDZS5.6B DIODE, ZENER
D14 1 1 1 1 1 UDZS5.6B DIODE, ZENER
D14 1 1 1 1 1 1SS355 DIODE
D15 1 1 1 1 1 1 1 1 1 1 1SS355 DIODE
D16 1 1 1 1 1 1 1 1 1 1 1SS301 DIODE
D17 1 1 1 1 1 1SS300 DIODE
D17 1 1 1 1 1 1SS301 DIODE
D19 1 1 1 1 1 1 1 1 1 1 1SS355 DIODE
D20 1 1 1 1 1 1SS355 DIODE
D21 1 1 1 1 1 1SS355 DIODE
D22 1 1 1 1 1 UDZS4.7B DIODE, ZENER
D23 1 1 1 1 1 1SS226 DIODE
D24 1 1 1 1 1 1SS355 DIODE
D25 1 1 1 1 1 1SS355 DIODE
D26 1 1 1 1 1SZ52 DIODE, ZENER
D27 1 1 1 1 1 DAP202K DIODE
D28 1 1 1 1 1 DAP202K DIODE
D29 1 1 1 1 1 DAP202K DIODE
D30 1 1 1 1 1 DAP202K DIODE
D31 1 1SS301 DIODE
D32 1 1SS300 DIODE
D32 1 1 1 1 1SS301 DIODE
D33 1 1SS355 DIODE
D34 1 UDZS5.6B DIODE, ZENER
D34 1 1 1 1 1SS355 DIODE
D35 1 UDZS5.6B DIODE, ZENER
D36 1 1 1 1 UDZS5.6B DIODE, ZENER
D36 1 1SS355 DIODE
D37 1 1 1 1 1SS300 DIODE
D37 1 1SS301 DIODE
D38 1 1SS300 DIODE
D39 1 1SS355 DIODE
D41 1 1 1 1 1SS355 DIODE
D42 1 1SS355 DIODE
D43 1 1 1 1 1 1 1 1 1 1 1SS355 DIODE
D44 1 1 1 1 1 1SS355 DIODE
D45 1 1 1 1 1 1SS355 DIODE
D46 1 1SS355 DIODE
D47 1 1 1 1 1SS355 DIODE
D48 1 MA704 DIODE
IC1 1 1 1 1 1 1 1 1 1 1 PCM1700U IC
IC2 1 1 1 1 1 1 1 1 1 1 PCM1700U IC
IC3 1 1 1 1 1 1 1 1 1 1 NJM4558M IC
IC4 1 1 1 1 1 1 1 1 1 1 NJM4558M IC
IC5 1 1 1 1 1 1 1 1 1 1 NJM4558M IC
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
4
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
–09
–08
–07
–06
–05
–04
–03
–02
–01
–00
Ref. No
Parts No.
Name & Description
C106 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C108 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C110 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C111 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C112 1 CC73GCH1H471J CAP. CERAMIC 470p 5% 50V
C113 1 CK73GB1H104K CAP. CERAMIC 0.1µ 10% 50V
C114 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C115 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C116 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C117 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C118 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C119 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C120 1 CK73GB1H103K CAP. CERAMIC 0.01µ 10% 50V
C121 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C122 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C123 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C124 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C125 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C126 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C127 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C128 1 1 1 1 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C129 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C130 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C131 1 1 1 1 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C132 1 1 1 1 1 CK73GF1A105Z CAP. CERAMIC 1µ -20/80% 10V
C133 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C134 1 1 1 1 1 1 1 1 1 1 C92-1527-05 CAP.ELECTRO 100µ 20% 16V
C135 1 1 1 1 1 1 1 1 1 1 C92-1527-05 CAP.ELECTRO 100µ 20% 16V
C136 1 1 1 1 1 C92-1527-05 CAP.ELECTRO 100µ 20% 16V
C137 1 1 1 1 1 C92-1527-05 CAP.ELECTRO 100µ 20% 16V
C138 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C139 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C140 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C141 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C142 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C143 1 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C144 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C145 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C147 1 1 1 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C148 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
CN1 1 1 1 1 1 1 1 1 1 1 E40-5233-05 PIN CONNECTOR 25P
CN2 1 1 1 1 1 1 1 1 1 1 E40-5233-05 PIN CONNECTOR 25P
CN3 1 1 1 1 1 1 1 1 1 1 E40-7809-05 BORDE CONNECTOR 17P
CN4 1 1 1 1 E40-7806-05 BORDE CONNECTOR 9P
CN5 1 1 1 1 1 1 1 1 1 1 E40-3367-05 PIN CONNECTOR 8P
CN6 1 1 1 1 1 1 E40-3367-05 PIN CONNECTOR 8P
CN7 1 1 1 1 1 1 1 1 1 1 E40-4291-05 PIN CONNECTOR 10P
CN8 1 1 1 1 1 1 E40-7292-05 PIN CONNECTOR 8P
CN9 1 1 1 1 1 1 1 1 1 1 E40-3240-05 PIN CONNECTOR 5P
CN10 1 1 1 1 1 1 1 1 1 1 E40-3239-05 PIN CONNECTOR 4P
CN11 1 1 1 1 1 1 1 1 1 1 E40-3237-05 PIN CONNECTOR 2P
D1 1 1 1 1 1 1 1 1 1 1 UDZS4.7B DIODE, ZENER
D2 1 1 1 1 1 1 1 1 1 1 1SS226 DIODE
D3 1 1 1 1 1 1 1 1 1 1 1SS355 DIODE
D4 1 1 1 1 1 1 1 1 1 1 1SS355 DIODE
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
3
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
–09
–08
–07
–06
–05
–04
–03
–02
–01
–00
