Kenwood PW-A series User Manual

PW-A
48
PARTS LIST
Ref. No
Parts No.
Name & Description
Q13 1 1 2SC5200(R) TR.SI, NPN
Q14 1 2SA1941(O) TR.SI, PNP
Q14 1 1 1 2SA1943(R) TR.SI, PNP
Q14 1 1 2SC5198(O) TR.SI, NPN
Q14 1 1 2SC5200(R) TR.SI, NPN
Q15 1 1 1 1 1 1 2SA1202(Y) TR.SI, PNP
Q15 1 1 1 1 2SC2882(Y) TR.SI, NPN
Q16 1 1 1 1 2SA1202(Y) TR.SI, PNP
Q16 1 1 1 1 2SC2882(Y) TR.SI, NPN
Q17 1 1 1 2SA1943(R) TR.SI, PNP
Q17 1 1 1 2SC5198(O) TR.SI, NPN
Q17 1 1 1 2SC5200(R) TR.SI, NPN
Q18 1 1 2SA1943(R) TR.SI, PNP
Q18 1 1 2SC5198(O) TR.SI, NPN
Q18 1 1 2SC5200(R) TR.SI, NPN
Q19 1 1 1 2SA1202(Y) TR.SI, PNP
Q19 1 1 1 1 1 1 2SC2882(Y) TR.SI, NPN
Q20 1 1 2SA1202(Y) TR.SI, PNP
Q20 1 1 1 1 2SC2882(Y) TR.SI, NPN
Q22 1 1 1 1 1 1 1 1 1 1 RN1401 TR.SI, NPN
Q23 1 1 1 1 1 RN2401 TR.SI, PNP
Q24 1 1 1 1 1 RN1401 TR.SI, NPN
Q25 1 1 1 1 1 1 1 1 1 1 RN1401 TR.SI, NPN
Q26 1 1 1 1 1 1 1 1 1 1 RN1401 TR.SI, NPN
Q27 1 1 1 1 1 1 1 1 1 1 RN1401 TR.SI, NPN
Q28 1 1 1 1 1 1 1 1 1 1 RN1401 TR.SI, NPN
Q29 1 1 1 1 1 1 1 1 1 1 RN1401 TR.SI, NPN
Q30 1 1 1 1 1 1 1 1 1 1 RN1401 TR.SI, NPN
Q31 1 1 1 1 RN2401 TR.SI, PNP
Q32 1 RN1401 TR.SI, NPN
Q33 1 RN2401 TR.SI, PNP
Q35 1 RN1401 TR.SI, NPN
Q36 1 1 1 1 1 RN1401 TR.SI, NPN
Q37 1 1 1 1 1 RN1401 TR.SI, NPN
Q38 1 1 1 1 1 RN1401 TR.SI, NPN
Q39 1 1 1 1 1 RN1401 TR.SI, NPN
Q40 1 1 1 1 1 RN1401 TR.SI, NPN
R1 1 1 1 1 1 1 1 1 1 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R2 1 1 1 1 1 1 1 1 1 1 RK73FB2A242J RES. CHIP (2✽1.25) 2.4k 5% 1/10W
R3 1 1 1 1 1 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R4 1 1 1 1 1 1 1 1 1 1 RK73FB2A511J RES. CHIP (2✽1.25) 510 5% 1/10W
R5 1 1 1 1 1 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R6 1 1 1 1 1 1 1 1 1 1 RK73FB2A512J RES. CHIP (2✽1.25) 5.1k 5% 1/10W
R7 1 1 1 1 1 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R8 1 1 1 1 1 1 1 1 1 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R9 1 1 1 1 1 1 1 1 1 1 RK73FB2A242J RES. CHIP (2✽1.25) 2.4k 5% 1/10W
R10 1 1 1 1 1 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R11 1 1 1 1 1 1 1 1 1 1 RK73FB2A511J RES. CHIP (2✽1.25) 510 5% 1/10W
R12 1 1 1 1 1 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R13 1 1 1 1 1 1 1 1 1 1 RK73FB2A512J RES. CHIP (2✽1.25) 5.1k 5% 1/10W
R14 1 1 1 1 1 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R15 1 1 1 1 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R16 1 1 1 1 1 1 1 1 1 1 RN73FH2A153D RES. METAL FILM 15k 0.5P 1/10W
R17 1 RK73FB2A122J RES. CHIP (2✽1.25) 1.2k 5% 1/10W
R17 1 RK73FB2A271J RES. CHIP (2✽1.25) 270 5% 1/10W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
6
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
–09
–08
–07
–06
–05
–04
–03
–02
–01
–00
Ref. No
Parts No.
Name & Description
IC6 1 1 1 1 1 NJM4558M IC
IC7 1 1 1 1 1 1 1 1 1 1 NJM4558M IC
IC8 1 1 1 1 1 1 1 1 1 1 NJM4558M IC
IC9 1 1 1 1 1 1 1 1 1 1 NJM4558M IC
IC10 1 1 1 1 1 1 1 1 1 1 NJM4558M IC
IC11 1 1 1 1 1 1 1 1 1 1 NJM4558M IC
IC12 1 1 1 1 1 1 1 1 1 1 NJM4558M IC
IC13 1 1 1 1 1 1 1 1 1 1 TC4051BF IC
IC14 1 1 1 1 1 1 1 1 1 1 NJM4558M IC
IC15 1 1 1 1 1 1 1 1 1 1 TC4051BF IC
IC16 1 1 1 1 1 1 1 1 1 1 NJM4558M IC
IC17 1 1 1 1 1 1 1 1 1 1 LTC2420CS8 IC
IC18 1 1 1 1 1 1 1 1 1 1 TC74HC4094AF IC
IC19 1 PCM1700U IC
IC20 1 1 1 1 1 PCM1700U IC
IC21 1 1 1 1 1 NJM4558M IC
IC22 1 NJM4558M IC
IC23 1 NJM4558M IC
IC25 1 1 1 1 1 NJM4558M IC
IC26 1 1 1 1 1 NJM4558M IC
IC27 1 NJM4558M IC
IC28 1 1 1 1 1 NJM4558M IC
IC29 1 1 1 1 1 NJM4558M IC
IC30 1 NJM4558M IC
IC31 1 1 1 1 1 TC4051BF IC
IC32 1 1 1 1 1 NJM4558M IC
IC33 1 1 1 1 1 TC4051BF IC
IC34 1 1 1 1 1 NJM4558M IC
IC35 1 1 1 1 1 LTC2420CS8 IC
IC36 1 1 1 1 1 TC74HC4094AF IC
IC37 1 1 1 1 1 1 1 1 1 1 TA7812S IC
IC39 1 1 1 1 1 1 1 1 1 1 TA79012S IC
IC40 1 1 1 1 1 TA7812S IC
IC41 1 1 1 1 1 TA79012S IC
Q1 1 1 1 1 1 1 1 1 1 1 2SA1943(R) TR.SI, PNP
Q2 1 1 1 1 1 1 1 1 1 1 2SA1943(R) TR.SI, PNP
Q3 1 1 1 1 1 1 1 1 1 2SA1943(R) TR.SI, PNP
Q4 1 1 1 1 1 1 1 1 1 1 2SA1202(Y) TR.SI, PNP
Q5 1 1 1 1 1 1 1 1 1 1 2SA1202(Y) TR.SI, PNP
Q6 1 1 1 1 1 1 1 1 1 2SA1202(Y) TR.SI, PNP
Q7 1 1 1 1 1 2SA1943(R) TR.SI, PNP
Q7 1 1 1 1 1 2SC5200(R) TR.SI, NPN
Q8 1 1 1 1 1 2SA1943(R) TR.SI, PNP
Q8 1 1 1 1 1 2SC5200(R) TR.SI, NPN
Q9 1 1 1 1 1 2SA1943(R) TR.SI, PNP
Q9 1 1 1 1 2SC5200(R) TR.SI, NPN
Q10 1 1 1 1 1 2SA1202(Y) TR.SI, PNP
Q10 1 1 1 1 1 2SC2882(Y) TR.SI, NPN
Q11 1 1 1 1 1 2SA1202(Y) TR.SI, PNP
Q11 1 1 1 1 1 2SC2882(Y) TR.SI, NPN
Q12 1 1 1 1 1 2SA1202(Y) TR.SI, PNP
Q12 1 1 1 1 2SC2882(Y) TR.SI, NPN
Q13 1 2SA1941(O) TR.SI, PNP
Q13 1 1 1 1 1 2SA1943(R) TR.SI, PNP
Q13 1 1 2SC5198(O) TR.SI, NPN
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
5
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
–09
–08
–07
–06
–05
–04
–03
–02
–01
–00
