Kenwood PW-A series User Manual

PW-A
49
PARTS LIST
Ref. No
Parts No.
Name & Description
R42 1 1 1 1 RN73FH2A331D RES. METAL FILM 330 0.5P 1/10W
R42 1 RN73FH2A391D RES. METAL FILM 390 0.5P 1/10W
R42 1 RN73FH2A431D RES. METAL FILM 430 0.5P 1/10W
R43 1 1 1 1 RN73FH2A301D RES. METAL FILM 300 0.5P 1/10W
R43 1 1 1 1 RN73FH2A331D RES. METAL FILM 330 0.5P 1/10W
R43 1 RN73FH2A391D RES. METAL FILM 390 0.5P 1/10W
R43 1 RN73FH2A431D RES. METAL FILM 430 0.5P 1/10W
R44 1 1 1 1 1 1 1 1 1 1 RN73FH2A752D RES. METAL FILM 7.5k 0.5P 1/10W
R45 1 1 1 1 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R46 1 1 1 1 1 1 1 1 1 1 RN73FH2A752D RES. METAL FILM 7.5k 0.5P 1/10W
R47 1 1 1 1 1 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R48 1 1 1 1 1 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R49 1 1 1 1 1 1 1 1 1 1 RK73FB2A512J RES. CHIP (2✽1.25) 5.1k 5% 1/10W
R51 1 1 1 1 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R57 1 R92-0670-05 RES. JUMPER 0
R57 1 RN73FH2A102D RES. METAL FILM 1k 0.5P 1/10W
R57 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R57 1 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R57 1 RN73FH2A153D RES. METAL FILM 15k 0.5P 1/10W
R57 1 RN73FH2A473D RES. METAL FILM 47k 0.5P 1/10W
R58 1 1 R92-0670-05 RES. JUMPER 0
R58 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R58 1 1 1 1 RN73FH2A113D RES. METAL FILM 11k 0.5P 1/10W
R58 1 1 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R59 1 1 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R59 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R59 1 1 RN73FH2A153D RES. METAL FILM 15k 0.5P 1/10W
R60 1 1 1 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R60 1 1 RN73FH2A153D RES. METAL FILM 15k 0.5P 1/10W
R61 1 1 1 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R61 1 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R62 1 1 1 1 1 1 1 1 1 RN73FH2A153D RES. METAL FILM 15k 0.5P 1/10W
R63 1 1 1 1 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R63 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R64 1 1 1 1 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R65 1 1 1 1 1 1 1 1 1 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R66 1 1 1 1 1 1 1 1 1 1 RK73FB2A242J RES. CHIP (2✽1.25) 2.4k 5% 1/10W
R67 1 1 1 1 1 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R68 1 1 1 1 1 1 1 1 1 1 RK73FB2A511J RES. CHIP (2✽1.25) 510 5% 1/10W
R69 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R69 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R70 1 1 1 1 1 RK73FB2A512J RES. CHIP (2✽1.25) 5.1k 5% 1/10W
R71 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R71 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R72 1 1 1 1 1 1 1 1 1 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R73 1 1 1 1 1 1 1 1 1 1 RK73FB2A242J RES. CHIP (2✽1.25) 2.4k 5% 1/10W
R74 1 1 1 1 1 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R75 1 1 1 1 1 1 1 1 1 1 RK73FB2A511J RES. CHIP (2✽1.25) 510 5% 1/10W
R76 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R76 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R77 1 1 1 1 1 RK73FB2A512J RES. CHIP (2✽1.25) 5.1k 5% 1/10W
R78 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R78 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R79 1 1 1 1 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R80 1 1 1 1 1 1 1 1 1 1 RK73FB2A472J RES. CHIP (2✽1.25) 4.7k 5% 1/10W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
8
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
–09
–08
–07
–06
–05
–04
–03
–02
–01
–00
Ref. No
Parts No.
Name & Description
R17 1 1 1 1 1 1 RK73FB2A471J RES. CHIP (2✽1.25) 470 5% 1/10W
R17 1 1 RK73FB2A751J RES. CHIP (2✽1.25) 750 5% 1/10W
R18 1 1 1 1 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R19 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R19 1 RK73FB2A153J RES. CHIP (2✽1.25) 15k 5% 1/10W
R19 1 1 RK73FB2A222J RES. CHIP (2✽1.25) 2.2k 5% 1/10W
R19 1 RK73FB2A472J RES. CHIP (2✽1.25) 4.7k 5% 1/10W
R19 1 1 1 1 1 RK73FB2A562J RES. CHIP (2✽1.25) 5.6k 5% 1/10W
R20 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R20 1 1 1 1 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R20 1 RN73FH2A203D RES. METAL FILM 20k 0.5P 1/10W
R20 1 1 1 RN73FH2A243D RES. METAL FILM 24k 0.5P 1/10W
R21 1 R92-0670-05 RES. JUMPER 0
R21 1 1 1 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R21 1 RN73FH2A203D RES. METAL FILM 20k 0.5P 1/10W
R21 1 1 1 RN73FH2A243D RES. METAL FILM 24k 0.5P 1/10W
R21 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R22 1 R92-0670-05 RES. JUMPER 0
R22 1 1 1 1 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R22 1 1 1 RN73FH2A243D RES. METAL FILM 24k 0.5P 1/10W
R22 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R23 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R23 1 1 1 1 1 1 1 1 1 RK73FB2A751J RES. CHIP (2✽1.25) 750 5% 1/10W
R24 1 1 1 1 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R25 1 1 1 1 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R26 1 1 1 1 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R27 1 1 1 1 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R28 1 1 1 1 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R31 1 1 1 1 1 1 1 1 1 1 RK73FB2A202J RES. CHIP (2✽1.25) 2k 5% 1/10W
R32 1 1 1 1 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R33 1 1 1 1 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R34 1 1 1 1 1 1 1 1 1 RK73FB2A100J RES. CHIP (2✽1.25) 10 5% 1/10W
R35 1 1 RD14DB3D1R2J RES. CARBON 1.2 5% 2W
R35 1 1 RD14DB3D1R5J RES. CARBON 1.5 5% 2W
R35 1 1 RD14DB3DR51J RES. CARBON 0.51 5% 2W
R35 1 1 1 RD14DB3DR68J RES. CARBON 0.68 5% 2W
R36 1 1 1 1 1 1 1 1 1 1 RK73FB2A100J RES. CHIP (2✽1.25) 10 5% 1/10W
R37 1 1 RD14DB3D1R2J RES. CARBON 1.2 5% 2W
R37 1 1 RD14DB3D1R5J RES. CARBON 1.5 5% 2W
R37 1 1 RD14DB3DR51J RES. CARBON 0.51 5% 2W
R37 1 1 1 1 RD14DB3DR68J RES. CARBON 0.68 5% 2W
R38 1 1 1 1 1 1 1 1 1 1 RK73FB2A100J RES. CHIP (2✽1.25) 10 5% 1/10W
R39 1 1 RD14DB3D1R2J RES. CARBON 1.2 5% 2W
R39 1 1 RD14DB3D1R5J RES. CARBON 1.5 5% 2W
R39 1 1 RD14DB3DR51J RES. CARBON 0.51 5% 2W
R39 1 1 1 1 RD14DB3DR68J RES. CARBON 0.68 5% 2W
R40 1 RD14DB3D101J RES. CARBON 100 5% 2W
R40 1 1 1 1 RD14DB3D152J RES. CARBON 1.5k 5% 2W
R40 1 1 1 RD14DB3D331J RES. CARBON 330 5% 2W
R40 1 RD14DB3D391J RES. CARBON 390 5% 2W
R40 1 RD14DB3D681J RES. CARBON 680 5% 2W
R41 1 1 1 1 R92-4150-05 RES. SPECIAL 0.1 1% 3W
R41 1 1 1 R92-4151-05 RES. SPECIAL 0.22 1% 3W
R41 1 1 1 R92-4152-05 RES. SPECIAL 0.33 1% 3W
R42 1 1 1 1 RN73FH2A301D RES. METAL FILM 300 0.5P 1/10W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
7
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
–09
–08
–07
–06
–05
–04
–03
–02
–01
–00

Kenwood PW-A series Specifications

General

Brand	Kenwood
Model	PW-A series
Category	Power Supply
Language	English
