Kenwood PW-A series User Manual

PW-A
50
PARTS LIST
Ref. No
Parts No.
Name & Description
R107 1 RD14DB3D681J RES. CARBON 680 5% 2W
R108 1 1 1 R92-4150-05 RES. SPECIAL 0.1 1% 3W
R108 1 1 1 1 R92-4151-05 RES. SPECIAL 0.22 1% 3W
R108 1 1 R92-4152-05 RES. SPECIAL 0.33 1% 3W
R109 1 1 1 1 1 1 1 1 1 1 RN73FH2A752D RES. METAL FILM 7.5k 0.5P 1/10W
R110 1 RN73FH2A271D RES. METAL FILM 270 0.5P 1/10W
R110 1 1 1 RN73FH2A301D RES. METAL FILM 300 0.5P 1/10W
R110 1 1 1 RN73FH2A331D RES. METAL FILM 330 0.5P 1/10W
R110 1 RN73FH2A391D RES. METAL FILM 390 0.5P 1/10W
R110 1 1 RN73FH2A431D RES. METAL FILM 430 0.5P 1/10W
R111 1 RN73FH2A271D RES. METAL FILM 270 0.5P 1/10W
R111 1 1 1 RN73FH2A301D RES. METAL FILM 300 0.5P 1/10W
R111 1 1 1 RN73FH2A331D RES. METAL FILM 330 0.5P 1/10W
R111 1 RN73FH2A391D RES. METAL FILM 390 0.5P 1/10W
R111 1 1 RN73FH2A431D RES. METAL FILM 430 0.5P 1/10W
R112 1 1 1 1 1 1 1 1 1 1 RN73FH2A752D RES. METAL FILM 7.5k 0.5P 1/10W
R113 1 1 1 1 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R114 1 1 1 1 1 1 1 1 1 1 RK73FB2A512J RES. CHIP (2✽1.25) 5.1k 5% 1/10W
R115 1 1 1 1 1 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R116 1 1 1 1 1 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R117 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R118 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R119 1 1 1 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R119 1 RN73FH2A203D RES. METAL FILM 20k 0.5P 1/10W
R120 1 1 1 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R120 1 RN73FH2A203D RES. METAL FILM 20k 0.5P 1/10W
R121 1 1 1 1 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R122 1 1 1 1 R92-0670-05 RES. JUMPER 0
R122 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R123 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R124 1 RN73FH2A102D RES. METAL FILM 1k 0.5P 1/10W
R124 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R124 1 RN73FH2A153D RES. METAL FILM 15k 0.5P 1/10W
R124 1 RN73FH2A473D RES. METAL FILM 47k 0.5P 1/10W
R125 1 R92-0670-05 RES. JUMPER 0
R125 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R125 1 1 RN73FH2A113D RES. METAL FILM 11k 0.5P 1/10W
R125 1 RN73FH2A202D RES. METAL FILM 2k 0.5P 1/10W
R126 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R127 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R128 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R129 1 1 1 1 1 RK73FB2A752J RES. CHIP (2✽1.25) 7.5k 5% 1/10W
R129 1 1 1 1 1 RN73FH2A153D RES. METAL FILM 15k 0.5P 1/10W
R130 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R130 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R130 1 1 1 1 RN73FH2A153D RES. METAL FILM 15k 0.5P 1/10W
R131 1 1 1 1 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R132 1 1 1 1 1 1 1 1 1 1 RK73FB2A511J RES. CHIP (2✽1.25) 510 5% 1/10W
R133 1 1 1 1 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R134 1 1 1 1 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R135 1 1 1 1 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R136 1 1 1 1 1 1 1 1 1 1 RK73FB2A751J RES. CHIP (2✽1.25) 750 5% 1/10W
R137 1 1 1 1 1 1 1 1 1 1 RK73FB2A432J RES. CHIP (2✽1.25) 4.3k 5% 1/10W
R138 1 1 1 1 1 1 1 1 1 1 RK73FB2A202J RES. CHIP (2✽1.25) 2k 5% 1/10W
R139 1 1 1 1 1 1 1 1 1 1 RK73FB2A432J RES. CHIP (2✽1.25) 4.3k 5% 1/10W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
0
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
–09
–08
–07
–06
–05
–04
–03
–02
–01
–00
Ref. No
Parts No.
Name & Description
R81 1 1 1 1 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R82 1 1 1 1 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R83 1 1 1 1 1 1 1 1 1 1 RN73FH2A153D RES. METAL FILM 15k 0.5P 1/10W
R84 1 1 RK73FB2A122J RES. CHIP (2✽1.25) 1.2k 5% 1/10W
R84 1 RK73FB2A271J RES. CHIP (2✽1.25) 270 5% 1/10W
R84 1 1 1 1 1 RK73FB2A471J RES. CHIP (2✽1.25) 470 5% 1/10W
R84 1 1 RK73FB2A751J RES. CHIP (2✽1.25) 750 5% 1/10W
R85 1 1 1 1 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R86 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R86 1 RK73FB2A153J RES. CHIP (2✽1.25) 15k 5% 1/10W
R86 1 1 RK73FB2A222J RES. CHIP (2✽1.25) 2.2k 5% 1/10W
R86 1 RK73FB2A472J RES. CHIP (2✽1.25) 4.7k 5% 1/10W
R86 1 1 1 1 RK73FB2A562J RES. CHIP (2✽1.25) 5.6k 5% 1/10W
R87 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R87 1 1 1 1 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R87 1 1 RN73FH2A203D RES. METAL FILM 20k 0.5P 1/10W
R87 1 1 RN73FH2A243D RES. METAL FILM 24k 0.5P 1/10W
R88 1 1 1 1 1 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R88 1 RN73FH2A203D RES. METAL FILM 20k 0.5P 1/10W
R88 1 1 RN73FH2A243D RES. METAL FILM 24k 0.5P 1/10W
R88 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R89 1 R92-0670-05 RES. JUMPER 0
R89 1 1 1 1 1 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R89 1 1 RN73FH2A243D RES. METAL FILM 24k 0.5P 1/10W
R89 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R90 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R90 1 1 1 1 1 1 1 1 RK73FB2A751J RES. CHIP (2✽1.25) 750 5% 1/10W
R91 1 1 1 1 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R92 1 1 1 1 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R93 1 1 1 1 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R94 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R95 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R96 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R97 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R98 1 1 1 1 1 1 1 1 1 1 RK73FB2A202J RES. CHIP (2✽1.25) 2k 5% 1/10W
R99 1 1 1 1 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R100 1 1 1 1 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R101 1 1 1 1 1 1 1 1 1 RK73FB2A100J RES. CHIP (2✽1.25) 10 5% 1/10W
R102 1 1 RD14DB3D1R2J RES. CARBON 1.2 5% 2W
R102 1 RD14DB3D1R5J RES. CARBON 1.5 5% 2W
R102 1 RD14DB3DR51J RES. CARBON 0.51 5% 2W
R102 1 1 1 1 1 RD14DB3DR68J RES. CARBON 0.68 5% 2W
R103 1 1 1 1 1 1 1 1 1 1 RK73FB2A100J RES. CHIP (2✽1.25) 10 5% 1/10W
R104 1 1 RD14DB3D1R2J RES. CARBON 1.2 5% 2W
R104 1 RD14DB3D1R5J RES. CARBON 1.5 5% 2W
R104 1 RD14DB3DR51J RES. CARBON 0.51 5% 2W
R104 1 1 1 1 1 1 RD14DB3DR68J RES. CARBON 0.68 5% 2W
R105 1 1 1 1 1 1 1 1 1 1 RK73FB2A100J RES. CHIP (2✽1.25) 10 5% 1/10W
R106 1 1 RD14DB3D1R2J RES. CARBON 1.2 5% 2W
R106 1 RD14DB3D1R5J RES. CARBON 1.5 5% 2W
R106 1 RD14DB3DR51J RES. CARBON 0.51 5% 2W
R106 1 1 1 1 1 1 RD14DB3DR68J RES. CARBON 0.68 5% 2W
R107 1 1 1 RD14DB3D152J RES. CARBON 1.5k 5% 2W
R107 1 1 1 1 RD14DB3D331J RES. CARBON 330 5% 2W
R107 1 RD14DB3D391J RES. CARBON 390 5% 2W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
9
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
–09
–08
–07
–06
–05
–04
–03
–02
–01
–00
