PARTS LIST
Ref. No
Parts No.
Name & Description
R184 1 1 1 1 1 1 1 1 RK73FB2A100J RES. CHIP (2✽1.25) 10 5% 1/10W
R185 1 RD14DB3D1R2J RES. CARBON 1.2 5% 2W
R185 1 1 RD14DB3DR22J RES. CARBON 0.22 5% 2W
R185 1 1 RD14DB3DR51J RES. CARBON 0.51 5% 2W
R185 1 1 1 RD14DB3DR68J RES. CARBON 0.68 5% 2W
R186 1 1 1 1 1 1 1 1 1 1 RK73FB2A100J RES. CHIP (2✽1.25) 10 5% 1/10W
R187 1 1 1 RD14DB3D1R2J RES. CARBON 1.2 5% 2W
R187 1 1 RD14DB3DR22J RES. CARBON 0.22 5% 2W
R187 1 1 RD14DB3DR51J RES. CARBON 0.51 5% 2W
R187 1 1 1 RD14DB3DR68J RES. CARBON 0.68 5% 2W
R188 1 1 RD14DB3D221J RES. CARBON 220 5% 2W
R188 1 RD14DB3D331J RES. CARBON 330 5% 2W
R188 1 1 RD14DB3D680J RES. CARBON 68 5% 2W
R188 1 RD14DB3D681J RES. CARBON 680 5% 2W
R189 1 1 1 R92-4150-05 RES. SPECIAL 0.1 1% 3W
R189 1 1 1 R92-4151-05 RES. SPECIAL 0.22 1% 3W
R190 1 1 RN73FH2A271D RES. METAL FILM 270 0.5P 1/10W
R190 1 RN73FH2A331D RES. METAL FILM 330 0.5P 1/10W
R190 1 1 RN73FH2A431D RES. METAL FILM 430 0.5P 1/10W
R191 1 1 RN73FH2A271D RES. METAL FILM 270 0.5P 1/10W
R191 1 RN73FH2A331D RES. METAL FILM 330 0.5P 1/10W
R191 1 1 RN73FH2A431D RES. METAL FILM 430 0.5P 1/10W
R192 1 1 1 RN73FH2A752D RES. METAL FILM 7.5k 0.5P 1/10W
R192 1 1 RN73FH2A822D RES. METAL FILM 8.2k 0.5P 1/10W
R193 1 1 1 RN73FH2A752D RES. METAL FILM 7.5k 0.5P 1/10W
R193 1 1 RN73FH2A822D RES. METAL FILM 8.2k 0.5P 1/10W
R194 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R195 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R196 1 1 1 1 1 RK73FB2A512J RES. CHIP (2✽1.25) 5.1k 5% 1/10W
R197 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R198 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R199 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R200 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R200 1 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R200 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R201 1 R92-0670-05 RES. JUMPER 0
R201 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R201 1 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R202 1 R92-0670-05 RES. JUMPER 0
R202 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R202 1 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R203 1 1 1 R92-0670-05 RES. JUMPER 0
R203 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R204 1 1 1 1 R92-0670-05 RES. JUMPER 0
R205 1 RN73FH2A102D RES. METAL FILM 1k 0.5P 1/10W
R206 1 R92-0670-05 RES. JUMPER 0
R207 1 R92-0670-05 RES. JUMPER 0
R208 1 R92-0670-05 RES. JUMPER 0
R209 1 R92-0670-05 RES. JUMPER 0
R210 1 R92-0670-05 RES. JUMPER 0
R210 1 1 1 1 RN73FH2A153D RES. METAL FILM 15k 0.5P 1/10W
R211 1 1 1 1 RK73FB2A752J RES. CHIP (2✽1.25) 7.5k 5% 1/10W
R211 1 RN73FH2A153D RES. METAL FILM 15k 0.5P 1/10W
R212 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R213 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
@
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
–09
–08
–07
–06
–05
–04
–03
–02
–01
–00
Ref. No
Parts No.
Name & Description
R140 1 1 1 1 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R141 1 1 1 1 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R142 1 1 1 1 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R143 1 1 1 1 1 1 1 1 1 1 RK73FB2A511J RES. CHIP (2✽1.25) 510 5% 1/10W
R144 1 1 1 1 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R145 1 1 1 1 1 1 1 1 1 1 RK73FB2A152J RES. CHIP (2✽1.25) 1.5k 5% 1/10W
R151 1 1 1 1 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R152 1 1 1 1 1 RK73FB2A242J RES. CHIP (2✽1.25) 2.4k 5% 1/10W
R153 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R154 1 1 1 1 1 RK73FB2A511J RES. CHIP (2✽1.25) 510 5% 1/10W
R155 1 1 1 1 R92-0670-05 RES. JUMPER 0
R155 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R156 1 RK73FB2A512J RES. CHIP (2✽1.25) 5.1k 5% 1/10W
R157 1 1 1 1 R92-0670-05 RES. JUMPER 0
R157 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R158 1 1 1 1 1 RK73FB2A242J RES. CHIP (2✽1.25) 2.4k 5% 1/10W
R159 1 1 1 1 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R160 1 1 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R161 1 1 1 1 1 RK73FB2A511J RES. CHIP (2✽1.25) 510 5% 1/10W
R162 1 1 1 1 R92-0670-05 RES. JUMPER 0
R162 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R163 1 RK73FB2A512J RES. CHIP (2✽1.25) 5.1k 5% 1/10W
R164 1 1 1 1 R92-0670-05 RES. JUMPER 0
R164 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R165 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R166 1 1 1 1 1 RN73FH2A153D RES. METAL FILM 15k 0.5P 1/10W
R167 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R167 1 1 RK73FB2A471J RES. CHIP (2✽1.25) 470 5% 1/10W
R167 1 RK73FB2A751J RES. CHIP (2✽1.25) 750 5% 1/10W
R168 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R169 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R169 1 1 RK73FB2A471J RES. CHIP (2✽1.25) 470 5% 1/10W
R169 1 RK73FB2A562J RES. CHIP (2✽1.25) 5.6k 5% 1/10W
R169 1 RK73FB2A752J RES. CHIP (2✽1.25) 7.5k 5% 1/10W
R170 1 1 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R170 1 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R171 1 R92-0670-05 RES. JUMPER 0
R171 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R171 1 RN73FH2A202D RES. METAL FILM 2k 0.5P 1/10W
R171 1 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R172 1 1 R92-0670-05 RES. JUMPER 0
R172 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R172 1 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R173 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R173 1 1 1 RK73FB2A751J RES. CHIP (2✽1.25) 750 5% 1/10W
R174 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R175 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R176 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R177 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R178 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R179 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R180 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R181 1 1 1 1 1 RK73FB2A202J RES. CHIP (2✽1.25) 2k 5% 1/10W
R182 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R183 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
!
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
–09
–08
–07
–06
–05
–04
–03
–02
–01
–00
