PARTS LIST
Ref. No
Parts No.
Name & Description
R269 1 R92-0670-05 RES. JUMPER 0
R275 1 1 1 1 R92-0670-05 RES. JUMPER 0
R275 1 RK73FB2A752J RES. CHIP (2✽1.25) 7.5k 5% 1/10W
R276 1 1 1 1 R92-0670-05 RES. JUMPER 0
R276 1 RN73FH2A153D RES. METAL FILM 15k 0.5P 1/10W
R277 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R278 1 1 1 1 1 RK73FB2A511J RES. CHIP (2✽1.25) 510 5% 1/10W
R279 1 1 1 1 RK73FB2A751J RES. CHIP (2✽1.25) 750 5% 1/10W
R280 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R281 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R282 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R283 1 1 1 1 1 RK73FB2A432J RES. CHIP (2✽1.25) 4.3k 5% 1/10W
R284 1 1 1 1 1 RK73FB2A432J RES. CHIP (2✽1.25) 4.3k 5% 1/10W
R285 1 1 1 1 1 RK73FB2A202J RES. CHIP (2✽1.25) 2k 5% 1/10W
R286 1 1 1 1 1 RK73FB2A511J RES. CHIP (2✽1.25) 510 5% 1/10W
R287 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R288 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R289 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R290 1 1 1 1 1 RK73FB2A152J RES. CHIP (2✽1.25) 1.5k 5% 1/10W
R291 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R292 1 R92-0670-05 RES. JUMPER 0
R294 1 1 1 1 R92-0670-05 RES. JUMPER 0
R295 1 1 1 1 R92-0670-05 RES. JUMPER 0
R300 1 1 1 1 R92-0670-05 RES. JUMPER 0
R301 1 1 1 1 R92-0670-05 RES. JUMPER 0
R302 1 1 1 1 R92-0670-05 RES. JUMPER 0
R303 1 1 1 1 R92-0670-05 RES. JUMPER 0
R304 1 1 1 1 R92-0670-05 RES. JUMPER 0
R305 1 1 1 1 R92-0670-05 RES. JUMPER 0
R306 1 1 1 1 R92-0670-05 RES. JUMPER 0
R307 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R308 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R309 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R310 1 R92-0670-05 RES. JUMPER 0
R311 1 R92-0670-05 RES. JUMPER 0
R312 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R313 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R314 1 R92-0670-05 RES. JUMPER 0
R315 1 R92-0670-05 RES. JUMPER 0
R316 1 1 1 1 R92-0670-05 RES. JUMPER 0
R317 1 1 1 1 R92-0670-05 RES. JUMPER 0
R318 1 1 1 1 R92-0670-05 RES. JUMPER 0
R319 1 1 1 1 R92-0670-05 RES. JUMPER 0
R320 1 1 1 1 R92-0670-05 RES. JUMPER 0
R321 1 R92-0670-05 RES. JUMPER 0
R322 1 1 1 1 R92-0670-05 RES. JUMPER 0
R323 1 R92-0670-05 RES. JUMPER 0
R324 1 R92-0670-05 RES. JUMPER 0
R325 1 R92-0670-05 RES. JUMPER 0
R326 1 R92-0670-05 RES. JUMPER 0
R327 1 R92-0670-05 RES. JUMPER 0
R328 1 1 1 R92-4150-05 RES. SPECIAL 0.1 1% 3W
R329 1 1 1 1 R92-0670-05 RES. JUMPER 0
R330 1 1 1 1 R92-0670-05 RES. JUMPER 0
R331 1 1 1 1 R92-0670-05 RES. JUMPER 0
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
$
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
–09
–08
–07
–06
–05
–04
–03
–02
–01
–00
Ref. No
Parts No.
Name & Description
R214 1 RK73FB2A242J RES. CHIP (2✽1.25) 2.4k 5% 1/10W
R215 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R216 1 RK73FB2A511J RES. CHIP (2✽1.25) 510 5% 1/10W
R217 1 R92-0670-05 RES. JUMPER 0
R219 1 R92-0670-05 RES. JUMPER 0
R220 1 RK73FB2A242J RES. CHIP (2✽1.25) 2.4k 5% 1/10W
R221 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R222 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R223 1 RK73FB2A511J RES. CHIP (2✽1.25) 510 5% 1/10W
R224 1 R92-0670-05 RES. JUMPER 0
R226 1 R92-0670-05 RES. JUMPER 0
R227 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R228 1 1 1 1 1 RK73FB2A472J RES. CHIP (2✽1.25) 4.7k 5% 1/10W
R229 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R230 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R231 1 RN73FH2A153D RES. METAL FILM 15k 0.5P 1/10W
R232 1 RK73FB2A751J RES. CHIP (2✽1.25) 750 5% 1/10W
R233 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R234 1 RK73FB2A471J RES. CHIP (2✽1.25) 470 5% 1/10W
R235 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R236 1 RN73FH2A202D RES. METAL FILM 2k 0.5P 1/10W
R237 1 R92-0670-05 RES. JUMPER 0
R238 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R239 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R240 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R241 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R244 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R245 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R246 1 RK73FB2A202J RES. CHIP (2✽1.25) 2k 5% 1/10W
R247 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R248 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R249 1 1 1 1 1 1 RK73FB2A100J RES. CHIP (2✽1.25) 10 5% 1/10W
R250 1 RD14DB3D1R2J RES. CARBON 1.2 5% 2W
R250 1 1 RD14DB3DR22J RES. CARBON 0.22 5% 2W
R250 1 1 1 RD14DB3DR68J RES. CARBON 0.68 5% 2W
R251 1 1 1 1 1 1 1 1 1 RK73FB2A100J RES. CHIP (2✽1.25) 10 5% 1/10W
R252 1 RD14DB3D0R1J RES. CARBON 0.1 5% 2W
R252 1 1 1 RD14DB3D1R2J RES. CARBON 1.2 5% 2W
R252 1 1 RD14DB3DR22J RES. CARBON 0.22 5% 2W
R252 1 1 1 RD14DB3DR68J RES. CARBON 0.68 5% 2W
R253 1 RD14DB3D331J RES. CARBON 330 5% 2W
R254 1 R92-4152-05 RES. SPECIAL 0.33 1% 3W
R255 1 RN73FH2A331D RES. METAL FILM 330 0.5P 1/10W
R256 1 RN73FH2A331D RES. METAL FILM 330 0.5P 1/10W
R257 1 RN73FH2A752D RES. METAL FILM 7.5k 0.5P 1/10W
R258 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R259 1 RN73FH2A752D RES. METAL FILM 7.5k 0.5P 1/10W
R260 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R261 1 RN73FH2A103D RES. METAL FILM 10k 0.5P 1/10W
R262 1 RK73FB2A512J RES. CHIP (2✽1.25) 5.1k 5% 1/10W
R263 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R265 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R266 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R267 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
R268 1 RN73FH2A302D RES. METAL FILM 3k 0.5P 1/10W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
#
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
–09
–08
–07
–06
–05
–04
–03
–02
–01
–00
