Kenwood PW-A series User Manual

PW-A
53
PARTS LIST
Ref. No
Parts No.
Name & Description
R332 1 1 1 1 R92-0670-05 RES. JUMPER 0
R333 1 1 1 1 R92-0670-05 RES. JUMPER 0
R334 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R335 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R336 1 R92-0670-05 RES. JUMPER 0
R337 1 R92-0670-05 RES. JUMPER 0
R338 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R339 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R340 1 R92-0670-05 RES. JUMPER 0
R341 1 R92-0670-05 RES. JUMPER 0
R342 1 1 1 1 R92-0670-05 RES. JUMPER 0
R343 1 1 1 1 R92-0670-05 RES. JUMPER 0
R344 1 1 1 1 R92-0670-05 RES. JUMPER 0
R345 1 1 1 1 R92-0670-05 RES. JUMPER 0
R346 1 1 1 1 1 1 1 1 1 1 RK73FB2A100J RES. CHIP (2✽1.25) 10 5% 1/10W
R347 1 1 1 1 1 1 1 1 1 RK73FB2A100J RES. CHIP (2✽1.25) 10 5% 1/10W
R348 1 1 1 1 1 1 1 1 1 RK73FB2A100J RES. CHIP (2✽1.25) 10 5% 1/10W
R351 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R352 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R353 1 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R354 1 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R355 1 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R356 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R357 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R358 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R359 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R360 1 1 1 1 R92-0670-05 RES. JUMPER 0
R361 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R362 1 1 1 R92-0670-05 RES. JUMPER 0
R363 1 1 1 R92-0670-05 RES. JUMPER 0
R364 1 R92-0670-05 RES. JUMPER 0
R365 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R366 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R367 1 R92-0670-05 RES. JUMPER 0
R368 1 R92-0670-05 RES. JUMPER 0
R369 1 RN73FH2A123D RES. METAL FILM 12k 0.5P 1/10W
R373 1 1 1 1 1 1 RK73FB2A473J RES. CHIP (2✽1.25) 47k 5% 1/10W
R374 1 1 1 1 1 1 RK73FB2A473J RES. CHIP (2✽1.25) 47k 5% 1/10W
R375 1 1 1 1 1 1 RK73FB2A473J RES. CHIP (2✽1.25) 47k 5% 1/10W
R376 1 1 1 1 1 1 1 RK73FB2A473J RES. CHIP (2✽1.25) 47k 5% 1/10W
R377 1 1 1 1 1 1 1 RK73FB2A473J RES. CHIP (2✽1.25) 47k 5% 1/10W
R378 1 1 1 1 1 1 1 RK73FB2A473J RES. CHIP (2✽1.25) 47k 5% 1/10W
R379 1 1 1 1 1 1 RK73FB2A473J RES. CHIP (2✽1.25) 47k 5% 1/10W
R380 1 1 1 1 RK73FB2A473J RES. CHIP (2✽1.25) 47k 5% 1/10W
R381 1 1 1 1 1 1 RK73FB2A473J RES. CHIP (2✽1.25) 47k 5% 1/10W
R382 1 1 1 RK73FB2A473J RES. CHIP (2✽1.25) 47k 5% 1/10W
R500 1 R92-0670-05 RES. JUMPER 0
R501 1 R92-0670-05 RES. JUMPER 0
R502 1 R92-0670-05 RES. JUMPER 0
R503 1 R92-0670-05 RES. JUMPER 0
R504 1 R92-0670-05 RES. JUMPER 0
R505 1 R92-0670-05 RES. JUMPER 0
R506 1 R92-0670-05 RES. JUMPER 0
R507 1 R92-0670-05 RES. JUMPER 0
R508 1 R92-0670-05 RES. JUMPER 0
R509 1 R92-0670-05 RES. JUMPER 0
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
%
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
–09
–08
–07
–06
–05
–04
–03
–02
–01
–00
