Kenwood PW-A series User Manual

PW-A
54
PARTS LIST
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
CN6 1 1 1 1 1 1 E40-4290-05 PIN CONNECTOR 5P
CN7 1 1 1 1 1 1 E40-4290-05 PIN CONNECTOR 5P
CN8 1 1 1 1 1 1 E40-7860-05 PIN CONNECTOR 19P
CN9 1 1 1 1 1 1 E40-7860-05 PIN CONNECTOR 19P
CN10 1 1 1 1 1 1 E40-7861-05 PIN CONNECTOR 5P
CN11 1 1 1 1 1 1 J13-0547-05 FUSE CLIP
D1 1 1 1 1 1 1 DAP202K DIODE
D2 1 1 1 1 1 1 DAP202K DIODE
D3 1 1 1 1 1 1 DAP202K DIODE
D4 1 1 1 1 1 1 DAN202K DIODE
D5 1 1 1 1 1 1 DAN202K DIODE
D6 1 1 1 1 1 1 DAN202K DIODE
D7 1 1 1 1 1 1 1SS355 DIODE
D8 1 1 1 1 1 1 1SS355 DIODE
D9 1 1 1 1 1 1 1SS355 DIODE
IC1 1 1 1 1 1 1 HD6413007F20 IC
IC2 1 1 1 1 1 1 AT29C010A-12JI IC
IC3 1 1 1 1 1 1 GM76C256CLLFW7 IC
IC4 1 1 1 1 1 1 BR93LC56F-W IC
IC5 1 1 1 1 1 1 BR93LC56F-W IC
IC6 1 1 1 1 1 1 TC74HC138AF IC
IC7 1 1 1 1 1 1 TC74HC574AF IC
IC8 1 1 1 1 1 1 TC74HC574AF IC
IC9 1 1 1 1 1 1 TC74HC574AF IC
IC10 1 1 1 1 1 1 TC74HC374AF IC
IC11 1 1 1 1 1 1 MB3771PF-G-BND IC
IC12 1 1 1 1 1 1 TC74HC74AF IC
IC13 1 1 1 1 1 1 TC74HC32AF IC
IC14 1 1 1 1 1 1 TC74HC04AF IC
J1 1 1 1 1 1 1 E03-0229-05 AC INLET
PH1 1 1 1 1 1 1 PC410 IC, PHOTO COUPLER
PH2 1 1 1 1 1 1 PC410 IC, PHOTO COUPLER
PH3 1 1 1 1 1 1 PC410 IC, PHOTO COUPLER
PH4 1 1 1 1 1 1 PC410 IC, PHOTO COUPLER
PH5 1 1 1 1 1 1 PC410 IC, PHOTO COUPLER
PH6 1 1 1 1 1 1 PC410 IC, PHOTO COUPLER
PH7 1 1 1 1 1 1 PC357NT IC, PHOTO COUPLER
PH8 1 1 1 1 1 1 PC357NT IC, PHOTO COUPLER
PH9 1 1 1 1 1 1 PC357NT IC, PHOTO COUPLER
PH10 1 1 1 1 1 1 PC357NT IC, PHOTO COUPLER
PH11 1 1 1 1 1 1 PC357NT IC, PHOTO COUPLER
PH12 1 1 1 1 1 1 PC410 IC, PHOTO COUPLER
PH13 1 1 1 1 1 1 PC357NT IC, PHOTO COUPLER
PH14 1 1 1 1 1 1 PC357NT IC, PHOTO COUPLER
PH15 1 1 1 1 1 1 PC357NT IC, PHOTO COUPLER
PH16 1 1 1 PC410 IC, PHOTO COUPLER
PH17 1 1 1 PC410 IC, PHOTO COUPLER
PH18 1 1 1 PC410 IC, PHOTO COUPLER
PH19 1 PC410 IC, PHOTO COUPLER
PH20 1 1 1 PC410 IC, PHOTO COUPLER
PH21 1 1 1 PC410 IC, PHOTO COUPLER
PH22 1 1 1 PC357NT IC, PHOTO COUPLER
PH23 1 1 1 PC357NT IC, PHOTO COUPLER
PH24 1 1 1 PC357NT IC, PHOTO COUPLER
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
2
Ref. No
Name & Description
Parts No.
-05
-04
-03
-02
-01
-00
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
1
Ref. No
Name & Description
Parts No.
-05
-04
-03
-02
-01
-00
1 1 1 1 1 1 E02-0217-05 SOCKET
X X X X X X AT29C010A-KW3 PROGRAMED ROM
1 1 1 1 1 1 J73-0753-12 PCB(UNMOUNTED)
A1 1 1 1 1 1 1 W02-4057-04 SWITCH UNIT
C1 1 1 1 1 1 1 C92-1547-05 CAP.ELECTRO 100µ 20% 10V
C2 1 1 1 1 1 1 C92-1547-05 CAP.ELECTRO 100µ 20% 10V
C3 1 1 1 1 1 1 CC73GCH1H100J CAP.CERAMIC 10p 5% 50V
C4 1 1 1 1 1 1 CC73GCH1H100J CAP.CERAMIC 10p 5% 50V
C5 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C6 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C7 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C8 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C9 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C10 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C11 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C12 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C13 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C14 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C15 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C16 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C17 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C18 1 1 1 1 1 1 CK73GF1A105Z CAP.CERAMIC 1µ -20/80% 10V
C19 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C20 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C21 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C22 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C23 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C24 1 1 1 1 1 1 CC73GSL1H102J CAP.CERAMIC 0.001µ 5% 50V
C25 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C26 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C27 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C28 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C29 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C30 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C31 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C32 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C33 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C34 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C35 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C36 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C37 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C38 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
C39 1 1 1 1 1 1 C91-2889-05 CAP. HIGH POWER 1000p 250V
C40 1 1 1 1 1 1 C91-2889-05 CAP. HIGH POWER 1000p 250V
C41 1 1 1 1 1 1 C91-2889-05 CAP. HIGH POWER 1000p 250V
C67 1 1 1 1 1 1 CK73GF1E104Z CAP.CERAMIC 0.1µ -20/80% 25V
CN1 1 1 1 1 1 1 E40-5314-05 PIN CONNECTOR 25P
CN2 1 1 1 1 1 1 E40-5314-05 PIN CONNECTOR 25P
CN3 1 1 1 1 1 1 E40-5314-05 PIN CONNECTOR 25P
CN4 1 1 1 1 1 1 E40-4280-05 PIN CONNECTOR 7P
CN5 1 1 1 1 1 1 E40-3305-05 PIN CONNECTOR 8P
CPU UNIT (X77-2380-XX)
