Kenwood PW-A series User Manual

PW-A
55
PARTS LIST
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
R53 1 1 1 RK73FB2A302J RES. CHIP (2✽1.25) 3k 5% 1/10W
R54 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R55 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R56 1 1 1 RK73FB2A202J RES. CHIP (2✽1.25) 2k 5% 1/10W
R57 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R58 1 1 1 RK73FB2A202J RES. CHIP (2✽1.25) 2k 5% 1/10W
R59 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R60 1 1 1 RK73FB2A202J RES. CHIP (2✽1.25) 2k 5% 1/10W
R61 1 R92-0670-05 RES. JUMPER 0
R62 1 1 RK73FB2A472J RES. CHIP (2✽1.25) 4.7k 5% 1/10W
R63 1 1 R92-0670-05 RES. JUMPER 0
R64 1 RK73FB2A472J RES. CHIP (2✽1.25) 4.7k 5% 1/10W
R65 1 1 1 RK73FB2A471J RES. CHIP (2✽1.25) 470 5% 1/10W
R67 1 RK73FB2A472J RES. CHIP (2✽1.25) 4.7k 5% 1/10W
R68 1 R92-0670-05 RES. JUMPER 0
R70 1 RK73FB2A471J RES. CHIP (2✽1.25) 470 5% 1/10W
R71 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R72 1 1 1 RK73FB2A302J RES. CHIP (2✽1.25) 3k 5% 1/10W
R73 1 1 R92-0670-05 RES. JUMPER 0
R74 1 R92-0670-05 RES. JUMPER 0
R75 1 R92-0670-05 RES. JUMPER 0
R76 1 1 R92-0670-05 RES. JUMPER 0
R77 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R78 1 R92-0670-05 RES. JUMPER 0
R81 1 R92-0670-05 RES. JUMPER 0
R82 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R160 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R161 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R162 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R163 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R164 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R165 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R166 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R167 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R200 1 R92-0670-05 RES. JUMPER 0
R201 1 R92-0670-05 RES. JUMPER 0
R202 1 R92-0670-05 RES. JUMPER 0
R203 1 R92-0670-05 RES. JUMPER 0
R204 1 R92-0670-05 RES. JUMPER 0
R205 1 R92-0670-05 RES. JUMPER 0
R250 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R251 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R252 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R253 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R254 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R255 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R256 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R257 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R258 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R259 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R260 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R261 1 1 1 1 1 1 RK73FB2A101J RES. CHIP (2✽1.25) 100 5% 1/10W
R264 1 1 1 1 1 1 RK73FB2A202J RES. CHIP (2✽1.25) 2k 5% 1/10W
R265 1 1 1 1 1 1 RK73FB2A202J RES. CHIP (2✽1.25) 2k 5% 1/10W
R266 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
4
Ref. No
Name & Description
Parts No.
-05
-04
-03
-02
-01
-00
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
PH25 1 1 1 PC357NT IC, PHOTO COUPLER
PH26 1 PC357NT IC, PHOTO COUPLER
PH27 1 1 1 PC410 IC, PHOTO COUPLER
PH28 1 1 1 PC357NT IC, PHOTO COUPLER
PH29 1 PC357NT IC, PHOTO COUPLER
Q1 1 1 1 1 1 1 2SC2714(O) TR.SI, NPN
Q2 1 1 1 1 1 1 2SC2714(O) TR.SI, NPN
R1 1 1 1 1 1 1 RK73FB2A302J RES. CHIP (2✽1.25) 3k 5% 1/10W
R2 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R3 1 1 1 1 1 1 RK73FB2A302J RES. CHIP (2✽1.25) 3k 5% 1/10W
R4 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R5 1 1 1 1 1 1 RK73FB2A302J RES. CHIP (2✽1.25) 3k 5% 1/10W
R6 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R7 1 1 1 1 1 1 RK73FB2A302J RES. CHIP (2✽1.25) 3k 5% 1/10W
R8 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R9 1 1 1 1 1 1 RK73FB2A302J RES. CHIP (2✽1.25) 3k 5% 1/10W
R10 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R11 1 1 1 1 1 1 RK73FB2A302J RES. CHIP (2✽1.25) 3k 5% 1/10W
R12 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R13 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R14 1 1 1 1 1 1 RK73FB2A202J RES. CHIP (2✽1.25) 2k 5% 1/10W
R15 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R16 1 1 1 1 1 1 RK73FB2A202J RES. CHIP (2✽1.25) 2k 5% 1/10W
R17 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R18 1 1 1 1 1 1 RK73FB2A202J RES. CHIP (2✽1.25) 2k 5% 1/10W
R19 1 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R22 1 1 1 1 1 1 RK73FB2A472J RES. CHIP (2✽1.25) 4.7k 5% 1/10W
R23 1 1 1 1 1 1 RK73FB2A471J RES. CHIP (2✽1.25) 470 5% 1/10W
R24 1 1 R92-0670-05 RES. JUMPER 0
R25 1 1 1 1 RK73FB2A472J RES. CHIP (2✽1.25) 4.7k 5% 1/10W
R26 1 1 1 1 R92-0670-05 RES. JUMPER 0
R27 1 1 RK73FB2A472J RES. CHIP (2✽1.25) 4.7k 5% 1/10W
R28 1 1 1 1 1 1 RK73FB2A471J RES. CHIP (2✽1.25) 470 5% 1/10W
R29 1 1 1 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R30 1 1 1 1 1 1 RK73FB2A302J RES. CHIP (2✽1.25) 3k 5% 1/10W
R32 1 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R33 1 1 1 1 1 1 R92-0670-05 RES. JUMPER 0
R35 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R36 1 1 1 1 R92-0670-05 RES. JUMPER 0
R37 1 1 R92-0670-05 RES. JUMPER 0
R38 1 1 R92-0670-05 RES. JUMPER 0
R39 1 1 1 1 R92-0670-05 RES. JUMPER 0
R40 1 1 1 1 1 1 RK73FB2A103J RES. CHIP (2✽1.25) 10k 5% 1/10W
R41 1 1 1 1 1 1 RK73FB2A302J RES. CHIP (2✽1.25) 3k 5% 1/10W
R42 1 1 1 1 1 1 RK73FB2A302J RES. CHIP (2✽1.25) 3k 5% 1/10W
R43 1 1 1 RK73FB2A302J RES. CHIP (2✽1.25) 3k 5% 1/10W
R44 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R45 1 1 1 RK73FB2A302J RES. CHIP (2✽1.25) 3k 5% 1/10W
R46 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R47 1 1 1 RK73FB2A302J RES. CHIP (2✽1.25) 3k 5% 1/10W
R48 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R49 1 RK73FB2A302J RES. CHIP (2✽1.25) 3k 5% 1/10W
R50 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
R51 1 1 1 RK73FB2A302J RES. CHIP (2✽1.25) 3k 5% 1/10W
R52 1 1 1 RK73FB2A102J RES. CHIP (2✽1.25) 1k 5% 1/10W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
3
Ref. No
Name & Description
Parts No.
-05
-04
-03
-02
-01
-00
