CIRCUIT DESCRIPTION
SINGLE CD
MECHA.
KSL213CCM
CASSETTE DOOR
MECHA.
A/D KEY
INPUT
TYPE
STANDBY/
TIMER
LED
MUTING
CONTROL
CIRCUIT
CD D.S.P IC
CDX3017Q
X32,IC3
DECK
MECHA.
CIRCUIT
AUTO REVERSE
CASSETTE
ADR-2176TR3
DECK CONTROL
CIRCUIT
HA12219NT
M30622MA-1A5FP
M30624MG-307FP
M-COM
TUNER PLL IC
LC72131
X14,IC2
X29,IC114
X29,IC106
X29,IC105
RDS IC
SAA6579T
X14X29
BACK LIGHT
CIRCUIT
AMP
AUDIO
OUTPUT
CIRCUIT
(MD VERSION ONLY)
LCD MODULE
REMOTE
CONTROL
SELECTOR IC
M62498AFP
MD MECHA. UNIT
MDM99D
5. Main Microprocessor : X29(IC104) M30622MA-1A5FP (DECK VERSION)
M30624MG-307FP (MD VERSION)
5-1 Main Microprocessor Periphery Block Diagram
INPUT KEY1 KEY2
VOLTAGE(V) Pin90 Pin91
0.00 0.23 TUNER/BAND SET/ DEMO
0.24 0.67 STOP MENU
0.68 1.12 TAPE REC SKIP UP
1.13 1.60 TAPE PLAY (F PLAY) SKIP DOWN
1.61 2.02 MD REC (TAPE O.T.E.) SOUND
2.03 2.74 MD PLAY (R PLAY) AUX
2.75 2.47 MD EJECT (TAPE EQ) -
2.48 3.37 CD PLAY -
3.38 3.82 CD OPEN/CLOSE -
3.83 4.27 POWER -
4.28 4.74 TAPE OPEN/CLOSE -
4.75
5.00 KEY OFF KEY OFF
5-2. Key Matrix
Vref=5V
( ) Deck Version
