P.O BOX 22745, 2201 East Dominguez St., Long Beach, CA 90801-5745, U.S.A.
under differing local conditions. This manual is based on Europe (E) standard,
through use of parts list.
[Amplifier section]
(For U.K. and Europe)
Effective output power during STEREO operation
1 kHz, 10 % T.H.D., at 6 Ω .................... 20 W + 20 W
Rated output power during STEREO operation
1 kHz, 0.7 % T.H.D., at 6 Ω ........................ 15 W + 15 W
(For U.S.A. and Canada)
Rated output power during STEREO operation
(For other countries)
Rated output power during STEREO operation
1 kHz, 10 % T.H.D., at 6 Ω .................... 20 W + 20 W
Frequency response
AUX................................ 50 Hz~50 kHz (0 dB ~ -3dB)
[Tuner section]
FM tuner section
Tuning frequency range ............. 87.5 MHz ~ 108 MHz
MW (AM) tuner section
Tuning frequency range
(For U.S.A. and Canada)
............................................... 530 kHz ~ 1700 kHz
(For U.K., Europe and Australia)
.............................................. 531 kHz ~ 1,602 kHz
(For other countries)
9 kHz step ............................. 531 kHz ~ 1,602 kHz
10 kHz step ........................... 530 kHz ~ 1,610 kHz
Main unit
[Cassette deck section]
Track ......................................... 4-track, 2-channel stereo
Recording system .................................... AC bias system
(Frequency: 65 kHz)
Heads
Playback / recording head ......................................... 1
Erasing head .............................................................. 1
Motors ............................................................................. 1
Wow and flutter .................................... 0.2 % (W.R.M.S.)
Fast winding time ............................ Approx. 100 seconds
(C-60 tape)
[General]
Power consumption.................................................. 60 W
Dimensions W : 180 mm
H : 239 mm
D : 305 mm
Weight (net)............................................................ 5.4 kg
Speakers
Enclosure ............ Book shelf type, magnetically shielded
Speaker configuration
Woofer.......................................... 100 mm, cone type
Tweeter .......................................... 50 mm, cone type
Impedance ................................................................. 6 Ω
Maximum input level .................................................30 W
Dimensions W : 150 mm
H : 234 mm
D : 197 mm
Weight (net)............................................... 2.4 kg(1 piece)
KENWOOD follows a policy of continuous ad-
vancements in development. For this reason speci-
fications may be changed without notice.
÷ Sufficient performance may not be exhibited at
extremely cold locations (where water freezes).
14 watts per channel minimum RMS, both channels
driven, at 6 Ω from 90 Hz to 20 kHz with no more than
0.9 % total harmonic distortion. (FTC)
[CD player section]
Laser ................................................ Semiconductor laser
D/A Conversion .......................................................... 1 Bit
Wow and flutter .................. Less than unmeasurable limit
NotesNotes
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
AB 3A N09-3345-08 SCREW (2.6X16)
AF 2A N87-3010-46 SCREW TAPPING (3X10)
40 2B S74-0075-08 SWITCH LEAF
DM 3A T42-0907-08 MOTOR CHASSIS ASSY(MB)
FM 3A T42-0875-08 MOTOR GEAR ASSY(MB)
LM 2B T42-0873-08 MOTOR ASSY LOADING
PU 3B T25-0061-08 PICKUP ASSY KSS-213C(R)
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
(
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
