Kenwood RXD-M32 User Manual

RXD-M32
39
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
- B58-0964-13 CAUTION CARD K
- B58-0965-13 CAUTION CARD XT
- B58-0966-13 CAUTION CARD MEE2
- B58-0967-03 CAUTION CARD P
- B58-1674-03 CAUTION CARD K
- ✽ B60-4726-08 INSTRUCTION MANUAL (EN) E2
- ✽ B60-4726-08 INSTRUCTION MANUAL (EN) KPMXT
- ✽ B60-4727-08 INSTRUCTION MANUAL (TC) M
- ✽ B60-4728-08 INSTRUCTION MANUAL (FR) EP
- ✽ B60-4729-08 INSTRUCTION MANUAL (GE) E
- ✽ B60-4730-08 INSTRUCTION MANUAL (NE) E
- ✽ B60-4731-08 INSTRUCTION MANUAL (IT) E
- ✽ B60-4732-08 INSTRUCTION MANUAL (ES) E
- ✽ B60-4732-08 INSTRUCTION MANUAL (ES) M
- ✽ B60-4772-08 INSTRUCTION MANUAL (PL) E2
- ✽ B60-4773-08 INSTRUCTION MANUAL (HU) E2
- ✽ B60-4774-08 INSTRUCTION MANUAL (CZ) E2
- ✽ B60-4775-08 INSTRUCTION MANUAL (RU) E2
- ✽ B60-4818-08 INSTRUCTION MANUAL (ARABIC) M
631 1D ✽ D40-1681-05 MECHANISM ASSY DECK,VOLTEX
BM 1D D16-0741-08 BELT(MAIN)
BS 1D D16-0705-08 BELT(SUB)
PF 1C D14-0380-08 PINCH ROLLER(FWD)
PR 1D D14-0381-08 PINCH ROLLER(RVS)
634 1C E03-0115-05 AC PLUG ADAPTER M
635 2E E30-2592-15 AC CORD MEE2
635 2E E30-2717-05 AC CORD X
635 2E E30-2721-05 AC CORD T
635 2E E30-2845-05 AC CORD H
635 2E E30-2924-05 AC CORD KP
636 2E ✽ E35-2576-08 FLAT CABLE DECK12PFFC
637 2D ✽ E35-2578-08 FLAT CABLE CD16PFFC
638 2D,2E ✽ E35-2579-08 FLAT CABLE CD25PFFC
639 2C,1E ✽ E35-2581-08 FLAT CABLE LCD7PFFC/7P
640 2C,1E ✽ E35-2582-08 FLAT CABLE LCD7PFFC/6P
641 2D,2E ✽ E35-2583-08 FLAT CABLE X14-X29,9P
642 2E ✽ E35-2637-08 FLAT CABLE SHIELD/FFC
- ✽ E35-2577-08 WIRING HARNESS DECK HEADLEAD
647 1E ✽ F07-1704-08 COVER KPX
647 1E ✽ F07-1705-08 COVER M
- ✽ F29-0127-08 INSULATING TUBE(AC CORD)
654 2D ✽ G11-2342-08 CUSHION
655 2C ✽ G11-2734-08 SOFT TAPE FORLCD
- ✽ H10-7669-08 POLYSTYRENE FOAMED FIXTURE L
- ✽ H10-7670-08 POLYSTYRENE FOAMED FIXTURE R
- H25-0232-04 PROTECTION BAG ACCESSORY MXHEE2
- H25-0651-04 PROTECTION BAG ACCESORY T
- H25-0661-04 PROTECTION BAG SET M
- H25-1516-04 PROTECTION BAG SET EE2
- H25-1516-04 PROTECTION BAG SET KPXH
- ✽ H50-3691-08 ITEM CARTON CASE GLAY-S KP S
- ✽ H50-3691-08 ITEM CARTON CASE GLAY-S X H
- ✽ H50-3740-08 ITEM CARTON CASE GLAY-S,M MH H
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
2
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
601 1C A09-1161-08 BATTERY COVER SURVICE
605 2C ✽ A21-3845-08 DRESSING PANEL CENTOR KPMX
605 2C ✽ A21-3847-08 DRESSING PANEL CENTOR TEE2H
609 2C ✽ A29-1099-08 PANEL CD
610 2C ✽ A29-1101-08 PANEL LID
611 2C ✽ A29-1121-08 PANEL ASSY LID
612 1C ✽ A50-1354-08 SIDE PLATE L,BLUE MXH L
612 1C ✽ A50-1354-08 SIDE PLATE L,BLUE TEE2 L
612 1C ✽ A50-1355-08 SIDE PLATE L,SILVER KPMXH S
612 1C ✽ A50-1355-08 SIDE PLATE L,SILVER TEE2 S
612 1C ✽ A50-1357-08 SIDE PLATE L,GRAY-S MXH H
612 1C ✽ A50-1357-08 SIDE PLATE L,GRAY-S TEE2 H
612 1C ✽ A50-1358-08 SIDE PLATE L,YELLOW-S E2 Y
612 1C ✽ A50-1358-08 SIDE PLATE L,YELLOW-S M1T1E1 Y
612 1C ✽ A50-1359-08 SIDE PLATE L,BLUE-S KP LS
612 1C ✽ A50-1372-08 SIDE PLATE L,WHITE-S EE2 W
613 1C ✽ A50-1361-08 SIDE PLATE R,BLUE MXH L
613 1C ✽ A50-1361-08 SIDE PLATE R,BLUE TEE2 L
613 1C ✽ A50-1362-08 SIDE PLATE R,SILVER EE2 S
613 1C ✽ A50-1362-08 SIDE PLATE R,SILVER KPMXH S
613 1C ✽ A50-1364-08 SIDE PLATE R,GRAY-S MXH H
613 1C ✽ A50-1364-08 SIDE PLATE R,GRAY-S TEE2 H
613 1C ✽ A50-1365-08 SIDE PLATE R,YELLOW-S E2 Y
613 1C ✽ A50-1365-08 SIDE PLATE R,YELLOW-S M1T1E1 Y
613 1C ✽ A50-1366-08 SIDE PLATE R,BLUE-S KP LS
613 1C ✽ A50-1373-08 SIDE PLATE R,WHITE-S EE2 W
614 1C ✽ A52-0387-08 TOP PLATE
615 2D ✽ A60-1916-08 PANEL ASSY BLUE
MXHTEE2
L
615 2D ✽ A60-1923-08 PANEL ASSY BLUE-S KP LS
615 2D ✽ A60-1919-08 PANEL ASSY GRAY-S
MXHTEE2 H
615 2D ✽ A60-1924-08 PANEL ASSY SILVER KP S
615 2D ✽ A60-1917-08 PANEL ASSY SILVER MXHTEE2 S
615 2D ✽ A60-1922-08 PANEL ASSY WHITE-S EE2 W
615 2D ✽ A60-1920-08 PANEL ASSY YELLOW-S T1E1M1E3 Y
616 1C ✽ A70-1380-08 REMOTE CONTROL ASSY 38,BLUE KP LS
616 1C ✽ A70-1380-08 REMOTE CONTROL ASSY 38,BLUE KPMX L
616 1C ✽ A70-1381-08 REMOTE CONTROL ASSY 46,BLUE HTEE2 L
616 1C ✽ A70-1394-08 REMOTE CONTROL ASSY 38,WHITE KPX S
616 1C ✽ A70-1395-08 REMOTE CONTROL ASSY 38,SILVER M S
616 1C ✽ A70-1395-08 REMOTE CONTROL ASSY 38,SILVER MX H
616 1C ✽ A70-1396-08 REMOTE CONTROL ASSY 46,YELLOW T1E1E2 Y
616 1C ✽ A70-1397-08 REMOTE CONTROL ASSY 46,SILVER EE2 W
616 1C ✽ A70-1397-08 REMOTE CONTROL ASSY 46,SILVER HTEE2 S
616 1C ✽ A70-1397-08 REMOTE CONTROL ASSY 46,SILVER HTEE2 H
616 1C ✽ A70-1398-08 REMOTE CONTROL ASSY38,YELLOW-S M1 Y
621 2D ✽ B07-2517-08 ESCUTCHEON
623 2C ✽ B10-3591-08 FRONT GLASS DECK
624 2D ✽ B12-0396-08 INDICATOR POWER
625 2C ✽ B12-0397-08 INDICATOR REMOCON
- B46-0096-53 WARRANTY CARD X
- B46-0310-03 WARRANTY CARD EE2
- B46-0328-03 WARRANTY CARD K
- B46-0347-03 WARRANTY CARD P
- B46-0350-00 QUESTIONAIRE CARD T
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
1
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
RXD-M32
Remarks: Refer to page2 and 18.
