PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
D111 1SS133 DIODE
D115 MA111 DIODE
D116 MTZJ5.6(B) ZENER DIODE
D116 RD5.6ES(B2) ZENER DIODE
IC1 ✽ LM4766T ANALOGUE IC
IC2 TA7812S ANALOGUE IC
IC91 XC62HR5102P ANALOGUE IC
IC92 ✽ NJM2930F05 ANALOGUE IC MM1
IC101 S-80840ANY ANALOGUE IC
IC103 TA8409S MOS-IC
IC104 M30622MA-1A5FP MI-COM IC
IC105 ✽ M62498AFP ANALOGUE IC
IC106 HA12219NT ANALOGUE IC
IC107 BA3126N ANALOGUE IC
IC111 TA8409S MOS-IC
IC112 L88M33T ANALOGUE IC
IC114 SAA6579T/R ANALOGUE IC EE1TT1
IC114 SAA6579T/R ANALOGUE IC HE2E3
Q1 ,2 2SC2878(B) TRANSISTOR
Q3 -5 ✽ 2SC2362(G,H) TRANSISTOR
Q7 2SA933AS(Q,R) TRANSISTOR
Q8 ✽ 2SA1016(G,H) TRANSISTOR
Q9 2SC4081(R,S) TRANSISTOR
Q9 2SC4116(Y,GR) TRANSISTOR
Q10 2SD2012 TRANSISTER
Q10 2SD2061 TRANSISTER
Q11 ,12 ✽ 2SC2362(G,H) TRANSISTOR
Q13 ✽ 2SA1016(G,H) TRANSISTOR
Q21 2SB1640 TRANSISTOR
Q91 ✽ 2SC2362(G,H) TRANSISTOR
Q92 ✽ 2SA1016(G,H) TRANSISTOR
Q101 2SC2458(Y,GR) TRANSISTOR
Q101 2SC2785(F,E) TRANSISTOR
Q102 2SC2003(L,K) TRANSISTOR
Q103 2SB764(E,F) TRANSISTOR
Q104 2SA1286-T11 TRANSISTOR
Q105,106 DTC124ESA DIGITAL TRANSISTOR
Q105,106 UN4212 DIGITAL TRANSISTOR
Q107 2SC2458(Y,GR) TRANSISTOR
Q107 2SC2785(F,E) TRANSISTOR
Q108 2SC4081(R,S) TRANSISTOR
Q108 2SC4116(Y,GR) TRANSISTOR
Q109 2SD863(E,F) TRANSISTOR
Q110 DTA124ESA DIGITAL TRANSISTOR
Q110 UN4112 DIGITAL TRANSISTOR
Q111,112 DTC124ESA DIGITAL TRANSISTOR
Q111,112 UN4212 DIGITAL TRANSISTOR
Q113 DTA124ESA DIGITAL TRANSISTOR
Q113 UN4112 DIGITAL TRANSISTOR
Q114 DTC124ESA DIGITAL TRANSISTOR
Q114 UN4212 DIGITAL TRANSISTOR
Q118 2SA1286-T11 TRANSISTOR
Q119 DTC124ESA DIGITAL TRANSISTOR
Q119 UN4212 DIGITAL TRANSISTOR
Q120 2SC3246 TRANSISTOR
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
^
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
W502-504 R92-0670-05 CHIP R 0 OHM
W508 R92-0670-05 CHIP R 0 OHM E1E2
W508-510 R92-0670-05 CHIP R 0 OHM K1M1M2
W508-510 R92-0670-05 CHIP R 0 OHM X1X2
W510 R92-0670-05 CHIP R 0 OHM E1E2
W512-517 R92-0679-05 CHIP R 0 OHM
W518,519 R92-0670-05 CHIP R 0 OHM K1M1M2
W518,519 R92-0670-05 CHIP R 0 OHM X1X2
W519 R92-0670-05 CHIP R 0 OHM E1E2
W520 R92-0679-05 CHIP R 0 OHM M1X1E1
W522,523 R92-0679-05 CHIP R 0 OHM
K1 S76-0076-05 MAGNETIC RELAY
K91 S76-0099-05 MAGNETIC RELAY
S91 S62-0001-05 SLIDE SWITCH MM1
D1 D3SBA20F03 DIODE
D2 D2SBA20F03 DIODE
D3 D4SBL20UF03 DIODE
D4 MTZJ3.9(B) ZENER DIODE
D4 RD3.9ES(B2) ZENER DIODE
D5 MTZJ5.1(B) ZENER DIODE
D5 RD5.1ES(B2) ZENER DIODE
D6 ,7 MA111 DIODE
D8 HSS104A DIODE
D8 1SS133 DIODE
D9 ,10 MA111 DIODE
D13 -16 MA111 DIODE
D21 MTZJ10(B) ZENER DIODE
D21 RD10ES(B2) ZENER DIODE
D22 MTZJ6.8(B) ZENER DIODE
D22 RD6.8ES(B2) ZENER DIODE
D23 MTZJ10(B) ZENER DIODE
D23 RD10ES(B2) ZENER DIODE
D24 MTZJ8.2(B) ZENER DIODE
D24 RD8.2ES(B2) ZENER DIODE
D43 ✽ MTZJ9.1(B) ZENER DIODE
D43 RD9.1ES(B2) ZENER DIODE
D44 ✽ DSK10B-AT DIODE
D90 MA111 DIODE MM1
D91 S1ZB20(4072) DIODE
D92 -94 MA111 DIODE
D95 ,96 MA111 DIODE HE2E3
D95 ,96 MA111 DIODE KPXEE1
D97 ,98 MA111 DIODE
D99 MA111 DIODE MM1
D101 1SS402 DIODE
D102 HSS104A DIODE
D102 1SS133 DIODE
D103 MTZJ5.6(B) ZENER DIODE
D103 RD5.6ES(B2) ZENER DIODE
D105 MTZJ5.6(B) ZENER DIODE
D105 RD5.6ES(B2) ZENER DIODE
D106,107 HSS104A DIODE
D106,107 1SS133 DIODE
D111 HSS104A DIODE
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
%
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
