CIRCUIT DESCRIPTION
3. AUTO FAB adjusting mode
Step No. Setting Method Remarks Display
Step 1 Test mode STOP state
Step 2 Press the SKIP DOWN( ) button three times AUTO FAB adjustment menu [_AUT_FAB_ _]
Step 3 Press the MD PLAY button 1 time
End of automatic adj. step 4
High reflection disc step 5
Step 4 Press the MD STOP button AUTO FAB adjustment menu, step 2
Step 5
Message output for 1 sec. AUTO FAB.
Adjustment menu(high reflection disc)
• : measurement value : FAB value in measurement, : C1 error value in measurement, : FAB
value
• If the STOP button is pressed twice while the AUTO FAB adjustment is displayed, the state is change to the TEST mode
STOP state.
Step 1 Test mode STOP state [ t s m e ]
Step 2 Press the SKIP DOWN(4) button 4 times. RESULT sub-menu [ _ R S T _ Y O B I _ ]
Step 3 Press once the MD PLAY button. Indication of measurement value [ R F G : _ _ __ _ ]
Step 4 Press once the SKIP DOWN(4) button. Indication of measurement value [ R C G : _ _ __ _ ]
Step 5 Press once the SKIP DOWN(4) button. Indication of measurement value [ P T G : _ _ _ _ _ ]
Step 6 Press once the SKIP DOWN(4) button. Indication of measurement value [ G T G : _ _ _ _ _ ]
Step 7 Press once the SKIP DOWN(4) button. Indication of measurement value [ P C H : _ _ _ _ ]
Step 8 Press once the SKIP DOWN(4) button. Indication of measurement value [ G C H : _ _ _ _ ]
Step 9 Press once the SKIP DOWN(4) button. Indication of measurement value [ S A G : _ _ _ ]
Step 10 Press once the SKIP DOWN(4) button. Indication of measurement value [ S B G : _ _ _ ]
Step 11 Press once the SKIP DOWN(4) button. Indication of measurement value [ S E G : _ _ _ ]
Step 12 Press once the SKIP DOWN(4) button. Indication of measurement value [ S F G : _ _ _ ]
Step 13 Press once the SKIP DOWN(4) button. Indication of measurement value [ H A O : _ _ _]
Step 14 Press once the SKIP DOWN(4) button. Indication of measurement value [ H B O : _ _ _]
Step 15 Press once the SKIP DOWN(4) button. Indication of measurement value [ H E O : _ _ _]
Step 16 Press once the SKIP DOWN(4) button. Indication of measurement value [ H F O : _ _ _]
Step 17 Press once the SKIP DOWN(4) button. Indication of measurement value [ L A O : _ _ _]
Step 18 Press once the SKIP DOWN(4) button. Indication of measurement value [ L B O : _ _ _]
Step 19 Press once the SKIP DOWN(4) button. Indication of measurement value [ L E O : _ _ _]
Step 20 Press once the SKIP DOWN(4) button. Indication of measurement value [ L F O : _ _ _]
Step 21 Press once the SKIP DOWN(4) button. Indication of measurement value [ T C O : _ _ _ _]
Step 22 Press once the SKIP DOWN(4) button. Indication of adjustment error sequence No. [ Y O B : _ _ _ _]
Step 23 Press once the SKIP DOWN(4) button. Indication of adjustment status [ D I F : _ _ _ _]
Step 24 Press once the SKIP DOWN(4) button. Indication of pre-adjustment not completed (00)/completed (4B) [ A D J : _ _ _ _]
Step 25 Press once the MD STOP button. RESULT sub-menu state [ _ R S T _ Y O B I _ ]
4. RESULT sub-mode
Step No.
Setting Method
Remarks Display
: Measurement value, : Adjustment value, : Other various informations
When the (¡)button in remote controller is pressed while the setting is displayed, the setting increases,
and a new setting is stored in RAM.
When the (1)button in remote controller is pressed while the setting is displayed, the setting increases,
and a new setting is stored in RAM.
When the (¡) or (1)button in remote controller is pressed continously, steps is change by 100ms period.
