Kenwood RXD-M32 User Manual

RXD-M32
17
ADJUSTMENT
L
R
AUX
IN
SPEAKERS(6–16Ω)
GND
AM
ANTENNA
FM
75Ω
+
-
LR
(A)
(B)
(C)
FM SG
FM SG
AG
MPX AG
AC voltmeter
Dummy antenna
Oscilloscope
Distortion meter
SYSTEM CONNECTIONS
No.
ITEM
INPUT
SETTINGS
OUTPUT
SETTINGS
RECEIVER
SETTINGS
ALIGNMENT
POINTS
ALIGN FOR
FIG.
1 DISCRIMINATOR
(A)
98.0MHz 1kHz,
±40kHz dev.
70dBf (ANT. input)
Connect a
DC voltmeter
between CN4 1
and CN4 2 (X14)
MONO
98.0MHz
L4
(X14-)
0V
2
DISTORTION
(MONO)
(A)
98.0MHz 1kHz,
±40kHz dev. MONO
70dBf (ANT. input)
(B)
MONO
98.0MHz
L5
(X14-)
Minimum
distortion
3
DISTORTION
(STEREO)
(C)
98.0MHz 1kHz,
±40kHz dev.
Selector : L or R Pilot
: ±6kHz dev.
70dBf (ANT. input)
(B)
AUTO
98.0MHz
IFT(RF
FRONTEND
: A1)
(X14-)
Minimum
distortion
(L or R)
4 TUNING LEVEL
(A)
98.0MHz MONO
1kHz, ±40kHz dev.
30dBf (ANT. input)
MONO
98.0MHz
VR1
(X14-)
Adjust VR1
and stop at the
point where ED1
(TUNED) goes
on.
FM SECTION : SELECTOR : FM *Adjust NO.1 and NO.2 repeat.
Tuner adjustment
