RXD-M32
40
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
688 1D ✽ D15-0430-08 PULLEY
689 1D ✽ D15-0431-08 PULLEY
690 1D ✽ D16-0747-08 BELT
691 1E ✽ D23-0337-08 RETAINER
692 1D ✽ J19-6073-08 HOLDER
693 1D ✽ G02-1712-08 FLAT SPRING
695 1D S64-0026-05 LEVER SWITCH
696 1D T42-0955-05 DC MOTOR
D N89-3008-46 BINDING HEAD TAPTITE SCREW
G N86-2605-46 BINDING HEAD TAPTITE SCREW
H N82-2605-45 BINDING HEAD TAPTITE SCREW
K ✽ N09-5190-08 SET SCREW
L N82-2608-46 BINDING HEAD TAPTITE SCREW
M N09-5131-05 MACHINE SCREW
- ✽ B11-1509-08 COLOR FILTER (BLUE) KPMTEH
- ✽ B11-1509-08 COLOR FILTER (BLUE) XE2
- ✽ B11-1510-08 COLOR FILTER (YELLOW) E3
- ✽ B11-1510-08 COLOR FILTER (YELLOW) M1E1T1
D104 ✽ B30-2574-05 LED(GRN3(80))
D105 B30-2567-05 LED(RED(80) HI-BR)
ED100 ✽ B38-0233-08 LCD DISPLAY ASSY
C1 CK73FB1H223K CHIP C 0.022UF K
C2 CK73FB1H103K CHIP C 0.010UF K EE1TT1
C2 CK73FB1H103K CHIP C 0.010UF K HE2E3
C3 CK73FB1H103K CHIP C 0.010UF K
C5 ,6 CK73FB1H103K CHIP C 0.010UF K
C7 CE04LW1C470M ELECTRO 47UF 16WV
C10 CE04LW1C470M ELECTRO 47UF 16WV
C11 ,12 CK73FB1H473K CHIP C 0.047UF K
C14 CE04LW1C100M ELECTRO 10UF 16WV
C15 CE04LW1H010M ELECTRO 1.0UF 50WV
C16 CE04RW1HR47M ELECTRO 0.47UF 50WV
C17 CE04LW1H010M ELECTRO 1.0UF 50WV
C18 CC73FCH1H470J CHIP C 47PF J
C19 CE04RW1A100M ELECTRO 10UF 10WV
C20 CK73FB1H473K CHIP C 0.047UF K
C21 CE04RW1V3R3M ELECTRO 3.3UF 35WV
C22 CK73FB1H473K CHIP C 0.047UF K
C23 CE04LW1C100M ELECTRO 10UF 16WV
C24 CK73FB1H331K CHIP C 330PF K
C25 CC73FCH1H181J CHIP C 180PF J EE1TT1
C25 CC73FCH1H181J CHIP C 180PF J HE2E3
C25 CC73FCH1H471J CHIP C 470PF J KPMM1X
C26 CK73FB1H183K CHIP C 0.018UF K EE1TT1
C26 CK73FB1H183K CHIP C 0.018UF K HE2E3
C26 CK73FB1H223K CHIP C 0.022UF K KPMM1X
C27 CE04HW1E4R7M NP-ELEC 4.7UF 25WV
C28 ,29 CE04LW1H2R2M ELECTRO 2.2UF 50WV
C30 ,31 CK73FB1H223K CHIP C 0.022UF K E1TT1H
C30 ,31 CK73FB1H223K CHIP C 0.022UF K E2E3
C30 ,31 CK73FB1H223K CHIP C 0.022UF K MM1XE
C30 ,31 CK73FB1H333K CHIP C 0.033UF K KP
C32 CE04LW1V4R7M ELECTRO 4.7UF 35WV
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
4
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
- ✽ H50-3741-08 ITEM CARTON CASE BLUE-S KP LS
- ✽ H50-3742-08 ITEM CARTON CASE YELLOW M1 Y
- ✽ H50-3743-08 ITEM CARTON CASE BLUE X L
- ✽ H50-3744-08 ITEM CARTON CASE BLUE,M H S
- ✽ H50-3744-08 ITEM CARTON CASE BLUE,M MH L
- ✽ H50-3745-08 ITEM CARTON CASE BLUE TE L
- ✽ H50-3746-08 ITEM CARTON CASE YELLOW-S T1E1 Y
- ✽ H50-3747-08 ITEM CARTON CASE BLUE,M TE H
- ✽ H50-3794-08 ITEM CARTON CASE SILVER X S
- ✽ H50-3839-08 ITEM CARTON CASE BLUE M S
- ✽ H50-3840-08 ITEM CARTON CASE SILVER TE S
- ✽ H50-3841-08 ITEM CARTON CASE WHITE^S E W
- ✽ H50-3847-08 ITEM CARTON CASE BLUE E2 L
- ✽ H50-3848-08 ITEM CARTON CASE YELLOW-S E2 Y
- ✽ H50-3849-08 ITEM CARTON CASE GLAY-S E2 H
- ✽ H50-3851-08 ITEM CARTON CASE SILVER E2 S
- ✽ H50-3852-08 ITEM CARTON CASE WHITE-S E2 W
659 2E J02-0370-05 FOOT
667 2E J42-0083-05 POWER CORD BUSHING
- J61-0307-05 WIRE BAND
669 2C ✽ K29-7780-08 KNOB (LID)
670 2C ✽ K29-7786-08 KNOB PPB5-6 S
670 2C ✽ K29-7786-08 KNOB PPB5-6 KP LS
670 2C ✽ K29-7786-08 KNOB PPB5-6 MXH L
670 2C ✽ K29-7786-08 KNOB PPB5-6 TEE2 L
670 2C ✽ K29-7787-08 KNOB PY8-2(Y) E2 Y
670 2C ✽ K29-7787-08 KNOB PY8-2(Y) T1E1M1 Y
670 2C ✽ K29-7788-08 KNOB PN9-1 E2 W
670 2C ✽ K29-7788-08 KNOB PN9-1 HTEE2 H
670 2C ✽ K29-7788-08 KNOB PN9-1 MX H
671 2D ✽ K29-7789-08 KNOB
672 2E ✽ L07-2868-08 POWER TRANSFORMER M
672 2E ✽ L07-2869-08 POWER TRANSFORMER HTEE2
672 2E ✽ L07-2870-08 POWER TRANSFORMER X
672 2E ✽ L07-2871-08 POWER TRANSFORMER KP
P ✽ N09-5201-08 TAPTITE SCREW A29(DECK)
673 2D S74-0065-05 LEAF SWITCH (S1)
674 1C T90-0852-05 LOOP ANTENNA
675 1C ✽ T90-0861-05 LEAD WIRE ANTENNA
676 1D ✽ A10-3515-08 CHASSIS
677 1D ✽ A10-3516-08 CHASSIS
678 1D ✽ A53-2194-08 CASSETTE HOLDER
679 1D ✽ D10-3934-08 SLIDER
680 1D ✽ D10-3935-08 SLIDER
681 1D ✽ D10-3936-08 ARM
682 1E ✽ D10-3937-08 SLIDER
683 1E ✽ D10-3938-08 ARM
684 1D ✽ D10-3940-08 ROD
685 1D ✽ D13-1989-08 GEAR
686 1D ✽ D13-1990-08 GEAR
687 1E ✽ D13-1991-08 GEAR
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
3
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
DISPLAY UNIT (X14-714X-XX)
