Kenwood RXD-M32 User Manual

RXD-M32
41
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
E1 ✽ F10-1165-08 SHIELDING PLATE KPMM1X
E1 ✽ F10-1166-08 SHIELDING PLATE EE1TT1
E1 ✽ F10-1166-08 SHIELDING PLATE HE2E3
- ✽ G11-2733-08 SOFT TAPE (LCD)
- ✽ J19-6072-08 HOLDER (LCD)
- ✽ J19-6074-08 HOLDER (LCD)
P100 J21-5845-04 MOUNTING HARDWARE
CF1 ,2 L72-0531-05 CERAMIC FILTER MM1X
CF1 ,2 L72-0536-05 CERAMIC FILTER EE1TT1
CF1 ,2 L72-0536-05 CERAMIC FILTER HE2E3
CF1 ,2 L72-0596-05 CERAMIC FILTER KP
CF3 L72-0607-05 CERAMIC FILTER MM1X
L1 L39-1384-05 COMBINATION COIL
L2 L40-1091-17 SMALL FIXED INDUCTOR(1UH)
L3 L30-0911-05 AM IFT
L4 L30-0933-05 FM IFT KP
L4 L30-0950-05 FM IFT EE1TT1
L4 L30-0950-05 FM IFT HE2E3
L5 L30-0951-05 FM IFT EE1TT1
L5 L30-0951-05 FM IFT HE2E3
L6 ,7 L79-1236-05 LC FILTER EE1TT1
L6 ,7 L79-1236-05 LC FILTER HE2E3
X1 L77-2232-05 CRYSTAL RESONATOR
R1 RK73GB1J101J CHIP R 100 J 1/16W
R4 RK73GB1J681J CHIP R 680 J 1/16W
R5 RK73FB2A332J CHIP R 3.3K J 1/10W
R6 RK73GB1J221J CHIP R 220 J 1/16W
R7 RK73FB2A821J CHIP R 820 J 1/10W
R8 RK73GB1J100J CHIP R 10 J 1/16W EE1TT1
R8 RK73GB1J100J CHIP R 10 J 1/16W HE2E3
R8 RK73GB1J330J CHIP R 33 J 1/16W KPMM1X
R9 RK73FB2A391J CHIP R 390 J 1/10W
R10 RK73FB2A102J CHIP R 1.0K J 1/10W
R11 RK73GB1J220J CHIP R 22 J 1/16W EE1TT1
R11 RK73GB1J220J CHIP R 22 J 1/16W HE2E3
R11 RK73GB1J330J CHIP R 33 J 1/16W KPMM1X
R12 RK73FB2A101J CHIP R 100 J 1/10W
R14 RK73FB2A101J CHIP R 100 J 1/10W E3
R14 RK73FB2A101J CHIP R 100 J 1/10W KPEE1T
R14 RK73FB2A101J CHIP R 100 J 1/10W T1HE2
R14 RK73FB2A271J CHIP R 270 J 1/10W MM1X
R15 RK73GB1J333J CHIP R 33K J 1/16W EE1TT1
R15 RK73GB1J333J CHIP R 33K J 1/16W HE2E3
R15 RK73GB1J472J CHIP R 4.7K J 1/16W KP
R16 RK73GB1J220J CHIP R 22 J 1/16W
R17 RK73FB2A362J CHIP R 3.6K J 1/10W
R18 RK73GB1J302J CHIP R 3.0K J 1/16W
R19 RK73GB1J822J CHIP R 8.2K J 1/16W
R20 RK73GB1J392J CHIP R 3.9K J 1/16W
R23 RK73GB1J153J CHIP R 15K J 1/16W EE1TT1
R23 RK73GB1J153J CHIP R 15K J 1/16W HE2E3
R23 RK73GB1J332J CHIP R 3.3K J 1/16W MM1X
R23 RK73GB1J822J CHIP R 8.2K J 1/16W KP
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
6
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
C33 ,34 CK73FB1H103K CHIP C 0.010UF K MM1
C35 CK73FB1H332K CHIP C 3300PF K KPMM1X
C36 CK73FB1H103K CHIP C 0.010UF K
C37 ,38 CE04LW1C100M ELECTRO 10UF 16WV
C41 CC73FCH1H470J CHIP C 47PF J
C42 CC73FCH1H120J CHIP C 12PF J
C43 CC73FCH1H100D CHIP C 10PF D
C44 CK73FB1H471K CHIP C 470PF K
C45 CC73FCH1H220J CHIP C 22PF J
C46 CE04LW1C100M ELECTRO 10UF 16WV
C47 CK73FB1H102K CHIP C 1000PF K
C48 CE04LW1C470M ELECTRO 47UF 16WV
C49 CE04LW1H2R2M ELECTRO 2.2UF 50WV
C50 CC73FSL1H101J CHIP C 100PF J
C51 CK73FB1H471K CHIP C 470PF K
C52 CC73FSL1H101J CHIP C 100PF J
C70 ,71 CK73FB1H682K CHIP C 6800PF K EE1TT1
C70 ,71 CK73FB1H682K CHIP C 6800PF K HE2E3
C72 CE04LW1H010M ELECTRO 1.0UF 50WV
C73 CE04LW1C470M ELECTRO 47UF 16WV
C74 CK73FB1H102K CHIP C 1000PF K KP
C75 CC73FCH1H030C CHIP C 3.0PF C
C76 CC73FCH1H470J CHIP C 47PF J
C78 CK73FB1H223K CHIP C 0.022UF K
C79 ,80 CK73FB1H332K CHIP C 3300PF K MM1X
C79 ,80 CK73FB1H472K CHIP C 4700PF K KP
C79 ,80 CK73FB1H682K CHIP C 6800PF K EE1HE2
C79 ,80 CK73FB1H682K CHIP C 6800PF K E3
C81 CK73FF1C105Z CHIP C 1.0UF Z
C82 CK73FB1H103K CHIP C 0.010UF K
C83 CC73FSL1H101J CHIP C 100PF J E2E3
C83 CC73FSL1H101J CHIP C 100PF J KPEE1H
C83 CK73FB1H223K CHIP C 0.022UF K MM1X
C84 ,85 CK73FB1H223K CHIP C 0.022UF K
C86 CK73FB1H471K CHIP C 470PF K
C88 CK73FB1H332K CHIP C 3300PF K
C89 ,90 CK73FB1H472K CHIP C 4700PF K KPMM1X
C91 CK73FF1C105Z CHIP C 1.0UF Z
C100 CK73EF1C105Z CHIP C 1.0UF Z
C101 CK73GB1C104K CHIP C 0.10UF K
C102,103 CK73EF1C105Z CHIP C 1.0UF Z
C104-106 CC73GCH1H470J CHIP C 47PF J
C110,111 CK73GB1H102K CHIP C 1000PF K
C112,113 CK73GB1C473K CHIP C 0.047UF K
C114,115 CK73GB1H103K CHIP C 0.010UF K
CN4 E40-4871-05 PIN ASSY E3
CN4 E40-4871-05 PIN ASSY KPEE1T
CN4 E40-4871-05 PIN ASSY T1HE2
CN100 ✽ E40-8613-05 FLAT CABLE CONNECTOR
CN101 ✽ E40-8635-05 FLAT CABLE CONNECTOR
CN102 ✽ E40-8612-05 FLAT CABLE CONNECTOR
J7 E20-0321-05 LOCK TERMINAL BOARD(2P,F)
J7 E70-0052-05 LOCK TERMINAL BOARD
J100 E11-0200-05 MINIATURE PHONE JACK(5P)
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
5
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
