46
RXD-M32MD
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
638 2G ✽ E35-2579-08 FLAT CABLE CD25PFFC
639 1G,2E ✽ E35-2581-08 FLAT CABLE LCD7PFFC/7P
640 1G,2E ✽ E35-2582-08 FLAT CABLE LCD7PFFC/6P
641 2F,2G ✽ E35-2583-08 FLAT CABLE X14-X29,9P
642 2G ✽ E35-2637-08 FLAT CABLE SHIELD/FFC
- ✽ E35-2577-08 WIRING HARNESS DECK HEADLEAD
647 1G ✽ F07-1704-08 COVER XTEH
647 1G ✽ F07-1705-08 COVER M
- ✽ F29-0127-08 INSULATING TUBE (AC CORD)
653 2E ✽ G01-4198-08 EXTENSION SPRING MD
654 2F ✽ G11-2342-08 CUSHION FOOTS
655 2E ✽ G11-2734-08 SOFT TAPE FORLCD
- ✽ H10-7669-08 POLYSTYRENE FOAMED FIXTURE L
- ✽ H10-7670-08 POLYSTYRENE FOAMED FIXTURE R
- H25-0232-04 PROTECTION BAG ACCESSORY MXEH
- H25-0651-04 PROTECTION BAG ACCESSORY T
- H25-0661-04 PROTECTION BAG SET M
- H25-1516-04 PROTECTION BAG SET X
- ✽ H25-1561-04 PROTECTION BAG SET TEH
- ✽ H50-3685-08 ITEM CARTON CASE 1PACKAGE MH S
- ✽ H50-3686-08 ITEM CARTON CASE 1PACKAGE M1H1 Y
- ✽ H50-3687-08 ITEM CARTON CASE 1PACKAGE MH LS
- ✽ H50-3689-08 ITEM CARTON CASE SEP TE S
- ✽ H50-3795-08 ITEM CARTON CASE 1PACKAGE X LS
- ✽ H50-3875-08 ITEM CARTON CASE BLUE/M MH L
- ✽ H50-3876-08 ITEM CARTON CASE BLUE/X X L
659 2G J02-0370-05 FOOT
667 2G J42-0083-05 POWER CORD BUSHING
- J61-0307-05 WIRE BAND
669 2E ✽ K29-7780-08 KNOB
670 2E ✽ K29-7782-08 KNOB PPB5-6 MHTE S
670 2E ✽ K29-7782-08 KNOB PPB5-6 MXH LS
670 2E ✽ K29-7782-08 KNOB PPB5-6 MXH L
670 2E ✽ K29-7785-08 KNOB PY8-2 M1H1 Y
671 2F ✽ K29-7789-08 KNOB
672 2G ✽ L07-2868-08 POWER TRANSFORMER M
672 2G ✽ L07-2869-08 POWER TRANSFORMER TEH
672 2G ✽ L07-2870-08 POWER TRANSFORMER X
P ✽ N09-5201-08 TAPTITE SCREW A29(DECK)
673 2F S74-0065-05 LEAF SWITCH
674 1E T90-0852-05 LOOP ANTENNA
675 1E ✽ T90-0861-05 LEAD WIRE ANTENNA
676 1F ✽ A10-3515-08 CHASSIS
677 1F ✽ A10-3516-08 CHASSIS
678 2E ✽ A53-2194-08 CASSETTE HOLDER
679 1E ✽ D10-3934-08 SLIDER
680 1E ✽ D10-3935-08 SLIDER
681 1E ✽ D10-3936-08 ARM
682 1G ✽ D10-3937-08 SLIDER
683 1E ✽ D10-3938-08 ARM
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
2
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
601 1E ✽ A09-1161-08 BATTERY COVER SURVICE
605 2E ✽ A21-3843-08 DRESSING PANEL CENTOR MD MX
605 2E ✽ A21-3844-08 DRESSING PANEL CENTOR MD TEH
608 2E ✽ A29-1097-08 PANEL MD
609 2E ✽ A29-1099-08 PANEL CD
610 2E ✽ A29-1101-08 PANEL LID
611 2E ✽ A29-1121-08 PANEL ASSY LID
612 1E ✽ A50-1354-08 SIDE PLATE L,BLUE MXH L
612 1E ✽ A50-1355-08 SIDE PLATE L,SILVER MTEH S
612 1E ✽ A50-1358-08 SIDE PLATE L,YELLOW-S M1H1 Y
612 1E ✽ A50-1359-08 SIDE PLATE L,BLUE-S MXH LS
613 1E ✽ A50-1361-08 SIDE PLATE R,BLUE MXH L
613 1E ✽ A50-1362-08 SIDE PLATE R,SILVER MTEH S
613 1E ✽ A50-1365-08 SIDE PLATE R,YELLOW-S M1H1 Y
613 1E ✽ A50-1366-08 SIDE PLATE R,BLUE-S MXH LS
614 1E ✽ A52-0387-08 TOP PLATE
615 2F ✽ A60-1909-08 PANEL ASSY BLUE MXH L
615 2F ✽ A60-1914-08 PANEL ASSY BLUE-S MXH LS
615 2F ✽ A60-1910-08 PANEL ASSY SILVER MTEH S
615 2F ✽ A60-1913-08 PANEL ASSY YELLOW-S M1H1 Y
616 1E ✽ A70-1375-08 REMOTE CONTROL ASSY WHITE M S
616 1E ✽ A70-1376-08 REMOTE CONTROL ASSY 43,WHITE TEH
616 1E ✽ A70-1393-08 REMOTE CONTROL ASSY YELLOW M1 Y
616 1E ✽ A70-1416-08 REMOTE CONTROL ASSY BLUE MX L
616 1E ✽ A70-1416-08 REMOTE CONTROL ASSY BLUE MX LS
621 2F ✽ B07-2517-08 ESCUTCHEON
623 2E ✽ B10-3591-08 FRONT GLASS DECK
624 2F ✽ B12-0396-08 INDICATOR POWER
625 2E ✽ B12-0397-08 INDICATOR REMOCON
- B46-0096-53 WARRANTY CARD X
- B46-0310-03 WARRANTY CARD ET
- B46-0350-00 QUESTIONAIRE CARD T
- B58-0965-13 CAUTION CARD XT
- B58-0966-13 CAUTION CARD ME
- ✽ B60-4719-08 INSTRUCTION MANUAL (EN) MXT
- ✽ B60-4720-08 INSTRUCTION MANUAL (TC) M
- ✽ B60-4721-08 INSTRUCTION MANUAL (FR) E
- ✽ B60-4722-08 INSTRUCTION MANUAL (GE) E
- ✽ B60-4723-08 INSTRUCTION MANUAL (NE) E
- ✽ B60-4724-08 INSTRUCTION MANUAL (IT) E
- ✽ B60-4725-08 INSTRUCTION MANUAL (ES) E
631 1F ✽ D40-1681-05 MECHANISM ASSY DECK,VOLTEX
BM 1F D16-0741-08 BELT(MAIN)
BS 1F D16-0705-08 BELT(SUB)
PF 1F D14-0380-08 PINCH ROLLER(FWD)
PR 1F D14-0381-08 PINCH ROLLER(RVS)
634 1E E03-0115-05 AC PLUG ADAPTER M
635 2G E30-2592-15 AC CORD ME
635 2G E30-2717-05 AC CORD X
635 2G E30-2721-05 AC CORD T
635 2G E30-2845-05 AC CORD H
636 2G ✽ E35-2576-08 FLAT CABLE DECK12PFFC
637 2F ✽ E35-2578-08 FLAT CABLE CD16PFFC
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
1
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
