Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
C41 CC73FCH1H470J CHIP C 47PF J
C42 CC73FCH1H120J CHIP C 12PF J
C43 CC73FCH1H100D CHIP C 10PF D
C44 CK73FB1H471K CHIP C 470PF K
C45 CC73FCH1H220J CHIP C 22PF J
C46 CE04LW1C100M ELECTRO 10UF 16WV
C47 CK73FB1H102K CHIP C 1000PF K
C48 CE04LW1C470M ELECTRO 47UF 16WV
C49 CE04LW1H2R2M ELECTRO 2.2UF 50WV
C50 CC73FSL1H101J CHIP C 100PF J
C51 CK73FB1H471K CHIP C 470PF K
C52 CC73FSL1H101J CHIP C 100PF J
C70 ,71 CK73FB1H682K CHIP C 6800PF K TEHH1
C72 CE04LW1H010M ELECTRO 1.0UF 50WV
C73 CE04LW1C470M ELECTRO 47UF 16WV
C75 CC73FCH1H030C CHIP C 3.0PF C
C76 CC73FCH1H470J CHIP C 47PF J
C78 CK73FB1H223K CHIP C 0.022UF K
C79 ,80 CK73FB1H332K CHIP C 3300PF K MM1X
C79 ,80 CK73FB1H682K CHIP C 6800PF K TEHH1
C81 CK73FF1C105Z CHIP C 1.0UF Z
C82 CK73FB1H103K CHIP C 0.010UF K TEHH1
C83 CC73FSL1H101J CHIP C 100PF J TEHH1
C83 CK73FB1H223K CHIP C 0.022UF K MM1X
C84 ,85 CK73FB1H223K CHIP C 0.022UF K
C86 CK73FB1H471K CHIP C 470PF K
C88 CK73FB1H332K CHIP C 3300PF K
C89 ,90 CK73FB1H472K CHIP C 4700PF K MM1X
C91 CK73FF1C105Z CHIP C 1.0UF Z
C100 CK73EF1C105Z CHIP C 1.0UF Z
C101 CK73GB1C104K CHIP C 0.10UF K
C102,103 CK73EF1C105Z CHIP C 1.0UF Z
C104-106 CC73GCH1H470J CHIP C 47PF J
C110,111 CK73GB1H102K CHIP C 1000PF K
C112,113 CK73GB1C473K CHIP C 0.047UF K
C114,115 CK73GB1H103K CHIP C 0.010UF K
CN4 E40-4871-05 PIN ASSY TEHH1
CN100 ✽ E40-8613-05 FLAT CABLE CONNECTOR
CN101 ✽ E40-8635-05 FLAT CABLE CONNECTOR
CN102 ✽ E40-8612-05 FLAT CABLE CONNECTOR
J7 E20-0321-05 LOCK TERMINAL BOARD(2P,F)
J7 E70-0052-05 LOCK TERMINAL BOARD
J100 E11-0200-05 MINIATURE PHONE JACK(5P)
E1 ✽ F10-1165-08 SHIELDING PLATE MM1X
E1 ✽ F10-1166-08 SHIELDING PLATE TEHH1
- ✽ G11-2733-08 SOFT TAPE (LCD)
- ✽ J19-6072-08 HOLDER (LCD)
- ✽ J19-6074-08 HOLDER (LCD)
P100 J21-5845-04 MOUNTING HARDWARE
CF1 ,2 L72-0531-05 CERAMIC FILTER MM1X
CF1 ,2 L72-0536-05 CERAMIC FILTER TEHH1
CF3 L72-0607-05 CERAMIC FILTER MM1X
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
4
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
684 1F ✽ D10-3940-08 ROD
685 1F ✽ D13-1989-08 GEAR
686 1F ✽ D13-1990-08 GEAR
687 1G ✽ D13-1991-08 GEAR
688 1F ✽ D15-0430-08 PULLEY
689 1F ✽ D15-0431-08 PULLEY
690 1F ✽ D16-0747-08 BELT
691 1G ✽ D23-0337-08 RETAINER
692 2E ✽ J19-6073-08 HOLDER
693 1G ✽ G02-1712-08 FLAT SPRING
695 1F S64-0026-05 LEVER SWITCH
696 1F T42-0955-05 DC MOTOR
D N89-3008-46 BINDING HEAD TAPTITE SCREW
G N86-2605-46 BINDING HEAD TAPTITE SCREW
H N82-2605-45 BINDING HEAD TAPTITE SCREW
K N09-5190-08 SET SCREW
L N82-2608-46 BINDING HEAD TAPTITE SCREW
M N09-5131-05 MACHINE SCREW
B11-1509-08 COLOR FILTER (BLUE) MTEHX
B11-1510-08 COLOR FILTER (YELLOW) M1H1
D104 B30-2574-05 LED(GRN3(80))
D105 B30-2567-05 LED(RED(80) HI-BR)
ED100 B38-0233-08 LCD DISPLAY ASSY
C1 CK73FB1H223K CHIP C 0.022UF K
C2 CK73FB1H103K CHIP C 0.010UF K TEHH1
C3 CK73FB1H103K CHIP C 0.010UF K
C5 ,6 CK73FB1H103K CHIP C 0.010UF K
C7 CE04LW1C470M ELECTRO 47UF 16WV
C10 CE04LW1C470M ELECTRO 47UF 16WV
C11 ,12 CK73FB1H473K CHIP C 0.047UF K
C14 CE04LW1C100M ELECTRO 10UF 16WV
C15 CE04LW1H010M ELECTRO 1.0UF 50WV
C16 CE04RW1HR47M ELECTRO 0.47UF 50WV
C17 CE04LW1H010M ELECTRO 1.0UF 50WV
C18 CC73FCH1H470J CHIP C 47PF J
C19 CE04RW1A100M ELECTRO 10UF 10WV
C20 CK73FB1H473K CHIP C 0.047UF K
C21 CE04RW1V3R3M ELECTRO 3.3UF 35WV
C22 CK73FB1H473K CHIP C 0.047UF K
C23 CE04LW1C100M ELECTRO 10UF 16WV
C24 CK73FB1H331K CHIP C 330PF K
C25 CC73FCH1H181J CHIP C 180PF J TEHH1
C25 CC73FCH1H471J CHIP C 470PF J MM1X
C26 CK73FB1H183K CHIP C 0.018UF K TEHH1
C26 CK73FB1H223K CHIP C 0.022UF K MM1X
C27 CE04HW1E4R7M NP-ELEC 4.7UF 25WV
C28 ,29 CE04LW1H2R2M ELECTRO 2.2UF 50WV
C30 ,31 CK73FB1H223K CHIP C 0.022UF K
C32 CE04LW1V4R7M ELECTRO 4.7UF 35WV
C33 ,34 CK73FB1H103K CHIP C 0.010UF K MM1
C35 CK73FB1H332K CHIP C 3300PF K MM1X
C36 CK73FB1H103K CHIP C 0.010UF K
C37 ,38 CE04LW1C100M ELECTRO 10UF 16WV
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
3
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
DISPLAY UNIT (X14-714X-XX)
RXD-M32MD
47
PARTS LIST
