Kenwood RXD-M32MD User Manual

Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
R58 RK73FB2A123J CHIP R 12K J 1/10W
R59 RK73FB2A122J CHIP R 1.2K J 1/10W
R72 ,73 RK73GB1J392J CHIP R 3.9K J 1/16W
R79 RK73GB1J332J CHIP R 3.3K J 1/16W
R80 RK73FB2A223J CHIP R 22K J 1/10W TEHH1
R81 RS14KB3A820J FL-PROOF RS 82 J 1W
R82 RK73GB1J272J CHIP R 2.7K J 1/16W TEHH1
R83 RK73FB2A102J CHIP R 1.0K J 1/10W
R84 RK73EB2B102J CHIP R 1.0K J 1/8W
R85 -87 RK73GB1J105J CHIP R 1.0M J 1/16W
R88 RK73GB1J563J CHIP R 56K J 1/16W
R89 RK73GB1J333J CHIP R 33K J 1/16W
R101 RK73GB1J104J CHIP R 100K J 1/16W
R102 RK73GB1J113J CHIP R 11K J 1/16W
R103 RK73GB1J243J CHIP R 24K J 1/16W
R104 RK73GB1J433J CHIP R 43K J 1/16W
R105 RK73GB1J683J CHIP R 68K J 1/16W
R106 RK73GB1J104J CHIP R 100K J 1/16W
R108 RK73GB1J682J CHIP R 6.8K J 1/16W
R109,110 RK73GB1J133J CHIP R 13K J 1/16W
R111,112 RK73GB1J221J CHIP R 220 J 1/16W
R113 RK73GB1J332J CHIP R 3.3K J 1/16W
R120 RK73GB1J104J CHIP R 100K J 1/16W
R121 RK73GB1J113J CHIP R 11K J 1/16W
R122 RK73GB1J243J CHIP R 24K J 1/16W
R123 RK73GB1J433J CHIP R 43K J 1/16W
R124 RK73GB1J683J CHIP R 68K J 1/16W
R125 RK73GB1J104J CHIP R 100K J 1/16W
R126 RK73GB1J154J CHIP R 150K J 1/16W
R127 RK73GB1J244J CHIP R 240K J 1/16W
R132 RK73GB1J102J CHIP R 1.0K J 1/16W
R133 RK73GB1J101J CHIP R 100 J 1/16W
R134 RK73GB1J154J CHIP R 150K J 1/16W
R135 RK73GB1J244J CHIP R 240K J 1/16W
R136 RK73GB1J394J CHIP R 390K J 1/16W
R137 RK73GB1J331J CHIP R 330 J 1/16W
R138 RK73GB1J102J CHIP R 1.0K J 1/16W
VR1 R32-0037-05 SEMI FIXED VARIABLE RESISTOR
W651,652 R92-0670-05 CHIP R 0 OHM
W654-656 R92-0670-05 CHIP R 0 OHM M1M2
W654,655 R92-0670-05 CHIP R 0 OHM K1E1E2
W654,655 R92-0670-05 CHIP R 0 OHM X1
W659 R92-0670-05 CHIP R 0 OHM K1M1M2
W659 R92-0670-05 CHIP R 0 OHM X1
W659,660 R92-0670-05 CHIP R 0 OHM E1E2
W662 R92-0670-05 CHIP R 0 OHM
W680 R92-0679-05 CHIP R 0 OHM
W682-685 R92-0679-05 CHIP R 0 OHM K1M1M2
W682-685 R92-0679-05 CHIP R 0 OHM X1
W684,685 R92-0679-05 CHIP R 0 OHM E1E2
S100-116 S70-0031-05 TACT SWITCH
S117 T99-0602-05 ROTARY ENCODER
D1 DA204U DIODE
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
6
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
L1 L39-1384-05 COMBINATION COIL
L2 L40-1091-17 SMALL FIXED INDUCTOR(1UH)
L3 L30-0911-05 AM IFT
L4 L30-0950-05 FM IFT TEHH1
L5 L30-0951-05 FM IFT TEHH1
L6 ,7 L79-1236-05 LC FILTER TEHH1
X1 L77-2232-05 CRYSTAL RESONATOR
R1 RK73GB1J101J CHIP R 100 J 1/16W
R4 RK73GB1J681J CHIP R 680 J 1/16W
R5 RK73FB2A332J CHIP R 3.3K J 1/10W
R6 RK73GB1J221J CHIP R 220 J 1/16W
R7 RK73FB2A821J CHIP R 820 J 1/10W
R8 RK73GB1J100J CHIP R 10 J 1/16W TEHH1
R8 RK73GB1J330J CHIP R 33 J 1/16W MM1X
R9 RK73FB2A391J CHIP R 390 J 1/10W
R10 RK73FB2A102J CHIP R 1.0K J 1/10W
R11 RK73GB1J220J CHIP R 22 J 1/16W TEHH1
R11 RK73GB1J330J CHIP R 33 J 1/16W MM1X
R12 RK73FB2A101J CHIP R 100 J 1/10W
R14 RK73FB2A101J CHIP R 100 J 1/10W TEHH1
R14 RK73FB2A271J CHIP R 270 J 1/10W MM1X
R15 RK73GB1J333J CHIP R 33K J 1/16W TEHH1
R16 RK73GB1J220J CHIP R 22 J 1/16W
R17 RK73FB2A362J CHIP R 3.6K J 1/10W
R18 RK73GB1J302J CHIP R 3.0K J 1/16W
R19 RK73GB1J822J CHIP R 8.2K J 1/16W
R20 RK73GB1J392J CHIP R 3.9K J 1/16W
R23 RK73GB1J153J CHIP R 15K J 1/16W TEHH1
R23 RK73GB1J332J CHIP R 3.3K J 1/16W MM1X
R25 RK73GB1J183J CHIP R 18K J 1/16W MM1X
R25 RK73GB1J273J CHIP R 27K J 1/16W TEHH1
R27 ,28 RK73GB1J432J CHIP R 4.3K J 1/16W TEHH1
R27 ,28 RK73GB1J472J CHIP R 4.7K J 1/16W MM1X
R30 RK73GB1J561J CHIP R 560 J 1/16W MM1
R31 RK73GB1J473J CHIP R 47K J 1/16W MM1
R32 RK73FB2A272J CHIP R 2.7K J 1/10W MM1X
R33 ,34 RK73GB1J102J CHIP R 1.0K J 1/16W
R35 RK73GB1J101J CHIP R 100 J 1/16W TEHH1
R36 RK73GB1J102J CHIP R 1.0K J 1/16W TEHH1
R37 RK73GB1J392J CHIP R 3.9K J 1/16W TEHH1
R38 RK73GB1J102J CHIP R 1.0K J 1/16W TEHH1
R39 RK73GB1J103J CHIP R 10K J 1/16W TEHH1
R42 RK73GB1J103J CHIP R 10K J 1/16W
R43 RK73GB1J221J CHIP R 220 J 1/16W
R44 RD14NB2E271J RD 270 J 1/4W
R45 -48 RK73GB1J102J CHIP R 1.0K J 1/16W
R49 RK73GB1J103J CHIP R 10K J 1/16W
R50 RD14NB2E471J RD 470 J 1/4W
R51 RK73GB1J562J CHIP R 5.6K J 1/16W
R52 RK73GB1J101J CHIP R 100 J 1/16W
R53 RK73GB1J222J CHIP R 2.2K J 1/16W
R54 RK73GB1J102J CHIP R 1.0K J 1/16W
R55 RK73GB1J333J CHIP R 33K J 1/16W
R56 ,57 RK73GB1J102J CHIP R 1.0K J 1/16W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
5
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
RXD-M32MD
48
PARTS LIST
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299

Kenwood RXD-M32MD Specifications

Amplifier Section

effective output power during STEREO operation	20 W + 20 W
rated output power during STEREO operation	15 W + 15 W
wow and flutter	0.2 %

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
MW (AM) tuning frequency range (for U.K. and Europe)	531 kHz ~ 1, 602 kHz
MW (AM) tuning frequency range (for other countries)	530 kHz ~ 1, 610 kHz

General

power consumption	60 W
dimensions (W x H x D)	180 mm x 239 mm x 305 mm
weight (net)	5.7 kg

Speaker Section

woofer size	100 mm
tweeter size	50 mm
impedance	6 Ω

MD Recorder Section

dimensions (W x H x D)	150 mm x 234 mm x 197 mm
weight (net)	2.4 kg
maximum input level	30 W
