Kenwood RXD-M32MD User Manual

RXD-M32MD
49
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
C75 CQ93FMG1H473J MYLAR 0.047UF J
C78 CE04DW1V221M ELECTRO 220UF 35WV
C79 CE04KW1H100M ELECTRO 10UF 50WV
C80 CE04KW1E470M ELECTRO 47UF 25WV
C81 ,82 CK73GB1H103K CHIP C 0.010UF K
C90 CK73GB1C473K CHIP C 0.047UF K MM1
C91 C91-1488-05 MF 6800PF 250VAC
C92 CE04KW1E470M ELECTRO 47UF 25WV MM1
C93 CQ93FMG1H104J MYLAR 0.10UF J XTEHH1
C93 CQ93FMG1H184J MYLAR 0.18UF J MM1
C94 CE04KW1H2R2M ELECTRO 2.2UF 50WV
C95 CE04KW1C332M ELECTRO 3300UF 16WV XTEHH1
C95 CE04KW1E332M ELECTRO 3300UF 25WV MM1
C98 CE04KW1E470M ELECTRO 47UF 25WV
C101 CK73GB1H103K CHIP C 0.010UF K
C102 CE04KW1H010M ELECTRO 1.0UF 50WV
C103 CE04KW0J331M ELECTRO 330UF 6.3WV
C104 CE04KW1A101M ELECTRO 100UF 10WV
C105 CE04KW1C471M ELECTRO 470UF 16WV
C106 CE04KW1V101M ELECTRO 100UF 35WV
C107,108 CE04KW1H3R3M ELECTRO 3.3UF 50WV
C115-118 CE04KW1C100M ELECTRO 10UF 16WV
C119,120 CK73GB1C104K CHIP C 0.10UF K
C121,122 CK73FB1C154K CHIP C 0.15UF K
C123,124 CK73FB1E683K CHIP C 0.068UF K
C125,126 CK73GB1A154K CHIP C 0.15UF K
C127,128 CK73GB1C563K CHIP C 0.056UF K
C129,130 CK73GB1H122K CHIP C 1200PF K
C131,132 CE04KW1H2R2M ELECTRO 2.2UF 50WV
C133,134 CC73GCH1H100D CHIP C 10PF D
C135,136 CE04KW1H010M ELECTRO 1.0UF 50WV
C137-140 CC73GCH1H221J CHIP C 220PF J
C149 CC73GCH1H100D CHIP C 10PF D
C150 CK73GB1C104K CHIP C 0.10UF K
C151 CK73GB1H102K CHIP C 1000PF K
C152 CK73GB1C104K CHIP C 0.10UF K
C153 CC73GCH1H220J CHIP C 22PF J
C154 CC73GCH1H180J CHIP C 18PF J
C155 CK73GB1H103K CHIP C 0.010UF K
C156 CK73GB1C104K CHIP C 0.10UF K
C157,158 CE04KW1C100M ELECTRO 10UF 16WV
C159,160 CK73GB1H681K CHIP C 680PF K
C161-164 CC73GCH1H221J CHIP C 220PF J
C165,166 CE04KW1H3R3M ELECTRO 3.3UF 50WV
C167,168 CK73GB1H103K CHIP C 0.010UF K
C169,170 CE04KW1A221M ELECTRO 220UF 10WV
C171,172 CE04KW1H010M ELECTRO 1.0UF 50WV
C173,174 CE04KW1H3R3M ELECTRO 3.3UF 50WV
C175 CE04KW1A101M ELECTRO 100UF 10WV
C176 CE04KW1E101M ELECTRO 100UF 25WV
C177 CK73GB1H103K CHIP C 0.010UF K
C178 CC73GCH1H080D CHIP C 8.0PF D
C179,180 CK73GB1H472K CHIP C 4700PF K
C181 CK73GB1H103K CHIP C 0.010UF K
C182-184 CE04KW1C100M ELECTRO 10UF 16WV
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
8
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
D1 MA143A DIODE
D1 1SS302 DIODE
D3 HZS8.2N(B2) ZENER DIODE
D3 MTZJ8.2(B) ZENER DIODE
D4 HZS5.1N(B2) ZENER DIODE
D4 MTZJ5.1(B) ZENER DIODE
D8 MA111 DIODE
D11 MA111 DIODE TEHH1
D13 MA111 DIODE
D102 UDZ5.6B ZENER DIODE
ED101 ✽ BL-150NK FLUORESCENT INDICATOR TUBE
IC1 LA1837 ANALOGUE IC TEHH1
IC1 LA1838 ANALOGUE IC MM1X
IC2 LC72131 MOS-IC
Q1 2SC4081(R,S) TRANSISTOR
Q1 2SD1819A(Q,R) TRANSISTOR
Q2 2SA1576A(R,S) TRANSISTOR
Q2 2SB1218A(Q,R) TRANSISTOR
Q3 ,4 2SC4081(R,S) TRANSISTOR MM1
Q3 ,4 2SD1819A(Q,R) TRANSISTOR MM1
Q6 ,7 2SC4081(R,S) TRANSISTOR TEHH1
Q6 ,7 2SD1819A(Q,R) TRANSISTOR TEHH1
Q14 2SA1576A(R,S) TRANSISTOR
Q14 2SB1218A(Q,R) TRANSISTOR
Q100 2SD1963 TRANSISTOR
Q101 DTA124EUA DIGITAL TRANSISTOR
Q101 UN5112 DIGITAL TRANSISTOR
A1 W02-2584-05 FM FRONT-END ASSY TEHH1
A1 W02-2622-05 FM FRONT-END ASSY MM1X
A100 W02-2537-05 ELECTRIC CIRCUIT MODULE
C1 ,2 CE04KW1H2R2M ELECTRO 2.2UF 50WV
C3 ,4 CK73GB1H102K CHIP C 1000PF K
C5 ,6 CE04KW1C100M ELECTRO 10UF 16WV
C7 ,8 CK73GB1H561K CHIP C 560PF K
C9 ,10 CC73GCH1H100D CHIP C 10PF D
C11 ,12 CK73GB1H122K CHIP C 1200PF K
C13 ,14 CK73GB1H561K CHIP C 560PF K
C15 ,16 CK73GB1H102K CHIP C 1000PF K
C17 -20 CQ93FMG1H224J MYLAR 0.22UF J
C21 ,22 CK73GB1H103K CHIP C 0.010UF K
C23 ,24 CC73GCH1H330J CHIP C 33PF J
C31 CE04HW1E100M NP-ELEC 10UF 25WV
C33 CE04KW1E470M ELECTRO 47UF 25WV
C41 CK73GB1H102K CHIP C 1000PF K
C42 CE04KW1A221M ELECTRO 220UF 10WV
C43 CE04KW1H4R7M ELECTRO 4.7UF 50WV
C51 ,52 ✽ C90-3928-05 ELECTRO 2200UF 35WV
C53 -55 C91-1567-05 FILM 0.1UF J
C61 CE04KW1V222M ELECTRO 2200UF 35WV
C62 CQ93FMG1H104J MYLAR 0.10UF J
C64 CK73GB1H102K CHIP C 1000PF K
C71 CE04KW1E332M ELECTRO 3300UF 25WV
C72 CQ93FMG1H104J MYLAR 0.10UF J
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
7
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
CONTROL CIRCUIT (X29-2690-XX)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299

Kenwood RXD-M32MD Specifications

Amplifier Section

effective output power during STEREO operation	20 W + 20 W
rated output power during STEREO operation	15 W + 15 W
wow and flutter	0.2 %

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
MW (AM) tuning frequency range (for U.K. and Europe)	531 kHz ~ 1, 602 kHz
MW (AM) tuning frequency range (for other countries)	530 kHz ~ 1, 610 kHz

General

power consumption	60 W
dimensions (W x H x D)	180 mm x 239 mm x 305 mm
weight (net)	5.7 kg

Speaker Section

woofer size	100 mm
tweeter size	50 mm
impedance	6 Ω

MD Recorder Section

dimensions (W x H x D)	150 mm x 234 mm x 197 mm
weight (net)	2.4 kg
maximum input level	30 W
