RXD-M32MD
50
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
CN106 E40-3259-05 PIN ASSY
CN108 E40-3249-05 PIN ASSY
CN109 ✽ E40-8601-05 FLAT CABLE CONNECTOR
CN111 E40-3249-05 PIN ASSY
CN113 ✽ E40-8606-05 PIN ASSY
CN114 E40-3249-05 PIN ASSY
CN115,116
✽ E40-8634-05 FLAT CABLE CONNECTOR
CN117 ✽ E40-8603-05 FLAT CABLE CONNECTOR
CN118 ✽ E40-8635-05 FLAT CABLE CONNECTOR
CN119 ✽ E40-8613-05 FLAT CABLE CONNECTOR
J1 E70-0053-05 LOCK TERMINAL BOARD
J101 E63-0095-05 PIN JACK
F1 F05-8013-05 FUSE (SEMKO) (250V T800MAL)
F2 F05-8013-05 FUSE (SEMKO) (250V T800MAL) MM1
CN95,96 J13-0075-05 FUSE CLIP
CN97,98 J13-0075-05 FUSE CLIP MM1
E100 J11-0809-05 WIRE CLAMPER
L101,102 L40-1035-29 SMALL FIXED INDUCTOR(10MH, J)
L103 L32-0592-05 BIAS OSCILLATING COIL
L104 L40-1001-17 SMALL FIXED INDUCTOR(10UH,K)
L105,106 L92-0089-05 CHIP FERRITE
L107 L92-0089-05 CHIP FERRITE
L108 L92-0017-05 FERRITE CORE
T91 L07-2758-05 POWER TRANSFORMER MM1
T91 ✽ L07-2897-08 POWER TRANSFORMER XTEHH1
X101 L78-0294-05 RESONATOR (10.000M)
X102 L77-2173-05 CRYSTAL RESONATOR(32.768KHZ)
X103 L77-2002-05 CRYSTAL RESONATOR(4.332MHZ) TEHH1
R1 ,2 RK73GB1J222J CHIP R 2.2K J 1/16W
R3 ,4 RK73GB1J102J CHIP R 1.0K J 1/16W
R5 ,6 RK73GB1J222J CHIP R 2.2K J 1/16W
R7 ,8 RK73GB1J203J CHIP R 20K J 1/16W
R9 ,10 RK73GB1J223J CHIP R 22K J 1/16W
R11 ,12 RK73GB1J102J CHIP R 1.0K J 1/16W
R13 ,14 RK73GB1J203J CHIP R 20K J 1/16W
R15 ,16 RK73GB1J391J CHIP R 390 J 1/16W
R21 ,22 RS14KB3DR22J FL-PROOF RS 0.22 J 2W
R23 ,24 RK73GB1J102J CHIP R 1.0K J 1/16W
R25 ,26 RK73GB1J103J CHIP R 10K J 1/16W
R27 ,28 RK73GB1J472J CHIP R 4.7K J 1/16W
R29 ,30 RK73GB1J473J CHIP R 47K J 1/16W
R31 ,32 RS14KB3A2R7J FL-PROOF RS 2.7 J 1W
R35 RS14KB3A101J FL-PROOF RS 100 J 1W
R36 RK73GB1J332J CHIP R 3.3K J 1/16W
R37 RK73GB1J104J CHIP R 100K J 1/16W
R41 RK73GB1J561J CHIP R 560 J 1/16W
R42 RK73GB1J122J CHIP R 1.2K J 1/16W
R43 RK73GB1J473J CHIP R 47K J 1/16W
R44 RK73GB1J103J CHIP R 10K J 1/16W
R45 RK73GB1J102J CHIP R 1.0K J 1/16W
R46 RK73GB1J472J CHIP R 4.7K J 1/16W
R47 RK73GB1J331J CHIP R 330 J 1/16W
R48 RK73GB1J473J CHIP R 47K J 1/16W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
0
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
C185 CK73FF1C105Z CHIP C 1.0UF Z
C186 CQ93HP2A103J MYLAR 0.010UF J
C187 CE04KW1C220M ELECTRO 22UF 16WV
C189,190 CE04KW1H3R3M ELECTRO 3.3UF 50WV
C191,192 CC73GCH1H821J CHIP C 820PF J
C193-196 CE04KW1H3R3M ELECTRO 3.3UF 50WV
C197 CE04KW1E101M ELECTRO 100UF 25WV
C198 CK73GB1C104K CHIP C 0.10UF K
C199 CE04KW1A101M ELECTRO 100UF 10WV
C200 CC73GCH1H101J CHIP C 100PF J
C201 CE04KW1A101M ELECTRO 100UF 10WV
C202 CK73GB1H103K CHIP C 0.010UF K
C203 CE04KW1A471M ELECTRO 470UF 10WV
C204 CC73FCH1H680J CHIP C 68PF J
C205 CK73GB1C104K CHIP C 0.10UF K
C206 CE04KW1A101M ELECTRO 100UF 10WV
C212 CE04KW1A470M ELECTRO 47UF 10WV TEHH1
C213 CK73GB1H103K CHIP C 0.010UF K TEHH1
C214 CC73GCH1H220J CHIP C 22PF J TEHH1
C215 CC73GCH1H470J CHIP C 47PF J TEHH1
C216 CC73GCH1H561J CHIP C 560PF J TEHH1
C217 CK73GB1H103K CHIP C 0.010UF K TEHH1
C218 CC73GCH1H331J CHIP C 330PF J TEHH1
C219 CE04KW1H2R2M ELECTRO 2.2UF 50WV TEHH1
C220 CC73GCH1H101J CHIP C 100PF J TEHH1
C222 CE04KW1A101M ELECTRO 100UF 10WV
C225,226 CC73GCH1H080D CHIP C 8.0PF D
C229,230 CC73GCH1H101J CHIP C 100PF J
C231 CE04KW1C471M ELECTRO 470UF 16WV
C232 CC73GCH1H470J CHIP C 47PF J
C233 CK73GB1C104K CHIP C 0.10UF K
C234 CE04KW1C331M ELECTRO 330UF 16WV
C235 CE04KW1E331M ELECTRO 330UF 25WV
C240 CK73GB1H103K CHIP C 0.010UF K
C241,242 CC73GCH1H101J CHIP C 100PF J
C243 CC73GCH1H220J CHIP C 22PF J
C245 CK73GB1H103K CHIP C 0.010UF K
C248 CK73GB1H102K CHIP C 1000PF K
C249 CC73GCH1H101J CHIP C 100PF J
C250 CK73GB1H103K CHIP C 0.010UF K
C251 CC73GCH1H470J CHIP C 47PF J
C252 CC73GCH1H220J CHIP C 22PF J
C253 CC73GCH1H100D CHIP C 10PF D
C254 CK73GB1H103K CHIP C 0.010UF K
CN1 E40-5066-05 PIN ASSY
CN2 E40-8605-05 PIN ASSY
CN4 E40-3247-05 PIN ASSY
CN91 E40-4245-05 PIN ASSY
CN93 E40-4281-05 PIN ASSY
CN101 E40-3251-05 PIN ASSY
CN102 E40-4899-05 FLAT CABLE CONNECTOR
CN103 E40-4874-05 PIN ASSY
CN104 E40-8307-05 FLAT CABLE CONNECTOR
CN105 E40-3248-05 PIN ASSY
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
9
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
