RXD-M32MD
51
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
R176-180 RK73GB1J472J CHIP R 4.7K J 1/16W
R181 RK73GB1J562J CHIP R 5.6K J 1/16W
R182 RK73GB1J473J CHIP R 47K J 1/16W
R183 RK73GB1J272J CHIP R 2.7K J 1/16W
R184 RK73GB1J473J CHIP R 47K J 1/16W
R185 RK73GB1J472J CHIP R 4.7K J 1/16W
R186 RK73GB1J102J CHIP R 1.0K J 1/16W
R187,188 RK73GB1J332J CHIP R 3.3K J 1/16W
R189,190 RK73GB1J912J CHIP R 9.1K J 1/16W
R191,192 RK73GB1J223J CHIP R 22K J 1/16W
R193,194 RK73GB1J103J CHIP R 10K J 1/16W
R195,196 RK73GB1J104J CHIP R 100K J 1/16W
R197 RK73GB1J100J CHIP R 10 J 1/16W
R198 RK73GB1J471J CHIP R 470 J 1/16W
R199 RK73GB1J473J CHIP R 47K J 1/16W
R200 RK73GB1J102J CHIP R 1.0K J 1/16W
R201,202 RK73GB1J101J CHIP R 100 J 1/16W
R203,204 RK73GB1J104J CHIP R 100K J 1/16W
R205 RK73GB1J100J CHIP R 10 J 1/16W
R208 RK73GB1J363J CHIP R 36K J 1/16W
R209 RK73GB1J473J CHIP R 47K J 1/16W
R213 RK73GB1J222J CHIP R 2.2K J 1/16W TEHH1
R214 RK73GB1J101J CHIP R 100 J 1/16W TEHH1
R215 RK73GB1J473J CHIP R 47K J 1/16W TEHH1
R216 RK73GB1J101J CHIP R 100 J 1/16W TEHH1
R218,219 RK73GB1J472J CHIP R 4.7K J 1/16W
R220 RK73GB1J473J CHIP R 47K J 1/16W
R221 RK73GB1J102J CHIP R 1.0K J 1/16W
R222,223 RK73GB1J472J CHIP R 4.7K J 1/16W
R224 RK73GB1J102J CHIP R 1.0K J 1/16W
R225,226 RK73GB1J473J CHIP R 47K J 1/16W TEHH1
R227 RD14BB2E2R2J RD 2.2 J 1/4W
R228 RK73GB1J121J CHIP R 120 J 1/16W
R229-231 RK73GB1J101J CHIP R 100 J 1/16W
R232,233 RK73GB1J100J CHIP R 10 J 1/16W
R234,235 RK73GB1J101J CHIP R 100 J 1/16W
R236 RK73GB1J103J CHIP R 10K J 1/16W
R237 RK73GB1J101J CHIP R 100 J 1/16W
R238 RK73GB1J561J CHIP R 560 J 1/16W
R239,240 RK73GB1J101J CHIP R 100 J 1/16W
R241,242 RK73GB1J162J CHIP R 1.6K J 1/16W
R243,244 RK73GB1J332J CHIP R 3.3K J 1/16W
R245 RK73GB1J101J CHIP R 100 J 1/16W
R247-258 RK73GB1J101J CHIP R 100 J 1/16W
R259 RK73GB1J332J CHIP R 3.3K J 1/16W
R260 RK73GB1J101J CHIP R 100 J 1/16W
R261 RK73GB1J103J CHIP R 10K J 1/16W
R262 RK73GB1J102J CHIP R 1.0K J 1/16W
R263 RK73GB1J2R2J CHIP R 2.2 J 1/16W
R264 RK73GB1J101J CHIP R 100 J 1/16W
R265 RK73GB1J472J CHIP R 4.7K J 1/16W
R266 RS14KB3A1R0J FL-PROOF RS 1 J 1W
R267 RK73GB1J473J CHIP R 47K J 1/16W
R268-279 RK73GB1J101J CHIP R 100 J 1/16W
R280-282 RK73GB1J473J CHIP R 47K J 1/16W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
@
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
R50 RS14KB3A152J FL-PROOF RS 1.5K J 1W
R51 -53 RK73GB1J473J CHIP R 47K J 1/16W
R54 RK73GB1J332J CHIP R 3.3K J 1/16W
R55 RK73GB1J472J CHIP R 4.7K J 1/16W
R56 RK73GB1J103J CHIP R 10K J 1/16W
R57 RK73GB1J153J CHIP R 15K J 1/16W
R59 ,60 RS14KB3A331J FL-PROOF RS 330 J 1W
R63 RK73GB1J102J CHIP R 1.0K J 1/16W
R64 RK73GB1J104J CHIP R 100K J 1/16W
R66 RD14NB2E1R0J RD 1 J 1/4W
R91 RK73GB1J104J CHIP R 100K J 1/16W
R92 RK73GB1J332J CHIP R 3.3K J 1/16W
R94 RK73GB1J105J CHIP R 1.0M J 1/16W
R95 RK73GB1J104J CHIP R 100K J 1/16W
R96 RK73GB1J101J CHIP R 100 J 1/16W
R98 RS14KB3A101J FL-PROOF RS 100 J 1W XTEHH1
R98 RS14KB3A560J FL-PROOF RS 56 J 1W MM1
R101 RK73GB1J102J CHIP R 1.0K J 1/16W
R102 RK73GB1J103J CHIP R 10K J 1/16W
R103 RK73GB1J104J CHIP R 100K J 1/16W
R104 RK73GB1J102J CHIP R 1.0K J 1/16W
R105 RK73GB1J103J CHIP R 10K J 1/16W
R106 RK73GB1J2R2J CHIP R 2.2 J 1/16W
R107,108 RK73GB1J682J CHIP R 6.8K J 1/16W
R109,110 RK73GB1J103J CHIP R 10K J 1/16W
R111,112 RK73GB1J102J CHIP R 1.0K J 1/16W
R113,114 RK73GB1J104J CHIP R 100K J 1/16W
R127 RK73GB1J102J CHIP R 1.0K J 1/16W
R129 RK73GB1J222J CHIP R 2.2K J 1/16W
R130 RK73GB1J133J CHIP R 13K J 1/16W
R131 RK73GB1J104J CHIP R 100K J 1/16W
R132 RK73FB2A475J CHIP R 4.7M J 1/10W
R133,134 RK73GB1J103J CHIP R 10K J 1/16W
R135,136 RK73GB1J164J CHIP R 160K J 1/16W
R137-140 RK73GB1J103J CHIP R 10K J 1/16W
R141,142 RK73GB1J334J CHIP R 330K J 1/16W
R143,144 RK73GB1J153J CHIP R 15K J 1/16W
R145,146 RK73GB1J223J CHIP R 22K J 1/16W
R147,148 ✽ RK73GB1J200J CHIP R 20 J 1/16W
R149,150 RK73GB1J222J CHIP R 2.2K J 1/16W
R151,152 RK73GB1J272J CHIP R 2.7K J 1/16W
R153,154 RK73GB1J682J CHIP R 6.8K J 1/16W
R155 RK73GB1J912J CHIP R 9.1K J 1/16W
R156 RK73GB1J392J CHIP R 3.9K J 1/16W
R157 RK73GB1J223J CHIP R 22K J 1/16W
R159 RK73GB1J102J CHIP R 1.0K J 1/16W
R160 RD14GB2E100J FL-PROOF RD 10 J 1/4W
R163,164 RK73GB1J273J CHIP R 27K J 1/16W
R165 RD14GB2E100J FL-PROOF RD 10 J 1/4W
R166 RK73GB1J103J CHIP R 10K J 1/16W
R167 RK73GB1J182J CHIP R 1.8K J 1/16W
R168 RK73GB1J102J CHIP R 1.0K J 1/16W
R169 RK73GB1J103J CHIP R 10K J 1/16W
R170 RD14GB2E100J FL-PROOF RD 10 J 1/4W
R171-175 RK73GB1J101J CHIP R 100 J 1/16W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
!
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
