Kenwood RXD-M32MD User Manual

RXD-M32MD
52
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
D43 ✽ MTZJ9.1(B) ZENER DIODE
D43 RD9.1ES(B2) ZENER DIODE
D44 ✽ DSK10B-AT DIODE
D90 MA111 DIODE MM1
D91 S1ZB20(4072) DIODE
D92 -94 MA111 DIODE
D95 ,96 MA111 DIODE XTEHH1
D97 ,98 MA111 DIODE
D99 MA111 DIODE MM1
D101 1SS402 DIODE
D102 HSS104A DIODE
D102 1SS133 DIODE
D103 MTZJ5.6(B) ZENER DIODE
D103 RD5.6ES(B2) ZENER DIODE
D105 MTZJ5.6(B) ZENER DIODE
D105 RD5.6ES(B2) ZENER DIODE
D106,107 HSS104A DIODE
D106,107 1SS133 DIODE
D108 MTZJ5.1(B) ZENER DIODE
D108 RD5.1ES(B2) ZENER DIODE
D109 MTZJ6.8(B) ZENER DIODE
D109 RD6.8ES(B2) ZENER DIODE
D110 MA111 DIODE
D111 HSS104A DIODE
D111 1SS133 DIODE
D114 HSS104A DIODE
D114 1SS133 DIODE
D115 MA111 DIODE
D116 MTZJ5.6(B) ZENER DIODE
D116 RD5.6ES(B2) ZENER DIODE
IC1 ✽ LM4766T ANALOGUE IC
IC2 TA7812S ANALOGUE IC
IC91 XC62HR5102P ANALOGUE IC
IC92 ✽ NJM2930F05 ANALOGUE IC MM1
IC101 S-80840ANY ANALOGUE IC
IC103 TA8409S MOS-IC
IC104 M30624MG-307FP MI-COM IC
IC105 ✽ M62498AFP ANALOGUE IC
IC106 HA12219NT ANALOGUE IC
IC107 BA3126N ANALOGUE IC
IC108 TC74HCT7007AF MOS-IC
IC109 NJM4565D ANALOGUE IC
IC110 BA05T ANALOGUE IC
IC110 BA17805T ANALOGUE IC
IC110 LM2940CT-5.0 ANALOGUE IC
IC110 TA7805S ANALOGUE IC
IC110 UPC7805AHF ANALOGUE IC
IC111 TA8409S MOS-IC
IC112 L88M33T ANALOGUE IC
IC114 SAA6579T/R ANALOGUE IC TEHH1
Q1 ,2 2SC2878(B) TRANSISTOR
Q3 -5 ✽ 2SC2362(G,H) TRANSISTOR
Q7 2SA933AS(Q,R) TRANSISTOR
Q8 ✽ 2SA1016(G,H) TRANSISTOR
Q9 2SC4081(R,S) TRANSISTOR
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
$
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
R283,284 RK73GB1J332J CHIP R 3.3K J 1/16W
R285 RK73GB1J162J CHIP R 1.6K J 1/16W
R286,287 RK73GB1J101J CHIP R 100 J 1/16W
R288 RK73GB1J162J CHIP R 1.6K J 1/16W
R289 RK73GB1J101J CHIP R 100 J 1/16W
R290 RK73GB1J271J CHIP R 270 J 1/16W
R291 RK73GB1J104J CHIP R 100K J 1/16W
R292 RK73GB1J104J CHIP R 100K J 1/16W MM1
R292 RK73GB1J123J CHIP R 12K J 1/16W TEHH1
R292 RK73GB1J473J CHIP R 47K J 1/16W X
R293 RK73GB1J511J CHIP R 510 J 1/16W
R294-296 RK73GB1J103J CHIP R 10K J 1/16W
R297,298 RK73GB1J153J CHIP R 15K J 1/16W
R299 RK73GB1J101J CHIP R 100 J 1/16W
R300 RD14GB2E5R6J FL-PROOF RD 5.6 J 1/4W
R301,302 RK73GB1J123J CHIP R 12K J 1/16W
R303 RK73GB1J102J CHIP R 1.0K J 1/16W
R305,306 RK73GB1J133J CHIP R 13K J 1/16W
R307,308 RK73GB1J182J CHIP R 1.8K J 1/16W
VR101,102 R32-0041-05 SEMI FIXED VARIABLE RESISTOR
W502-504 R92-0670-05 CHIP R 0 OHM
W508 R92-0670-05 CHIP R 0 OHM E1E2
W508-510 R92-0670-05 CHIP R 0 OHM K1M1M2
W508-510 R92-0670-05 CHIP R 0 OHM X1X2
W510 R92-0670-05 CHIP R 0 OHM E1E2
W512-517 R92-0679-05 CHIP R 0 OHM
W518,519 R92-0670-05 CHIP R 0 OHM K1M1M2
W518,519 R92-0670-05 CHIP R 0 OHM X1X2
W519 R92-0670-05 CHIP R 0 OHM E1E2
W520 R92-0679-05 CHIP R 0 OHM M1X1E1
W522,523 R92-0679-05 CHIP R 0 OHM
K1 S76-0076-05 MAGNETIC RELAY
K91 S76-0099-05 MAGNETIC RELAY
S91 S62-0001-05 SLIDE SWITCH MM1
D1 D3SBA20F03 DIODE
D2 D2SBA20F03 DIODE
D3 D4SBL20UF03 DIODE
D4 MTZJ3.9(B) ZENER DIODE
D4 RD3.9ES(B2) ZENER DIODE
D5 MTZJ5.1(B) ZENER DIODE
D5 RD5.1ES(B2) ZENER DIODE
D6 ,7 MA111 DIODE
D8 HSS104A DIODE
D8 1SS133 DIODE
D9 ,10 MA111 DIODE
D13 -16 MA111 DIODE
D21 MTZJ10(B) ZENER DIODE
D21 RD10ES(B2) ZENER DIODE
D22 MTZJ6.8(B) ZENER DIODE
D22 RD6.8ES(B2) ZENER DIODE
D23 MTZJ10(B) ZENER DIODE
D23 RD10ES(B2) ZENER DIODE
D24 MTZJ8.2(B) ZENER DIODE
D24 RD8.2ES(B2) ZENER DIODE
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
#
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299

Kenwood RXD-M32MD Specifications

Amplifier Section

effective output power during STEREO operation	20 W + 20 W
rated output power during STEREO operation	15 W + 15 W
wow and flutter	0.2 %

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
MW (AM) tuning frequency range (for U.K. and Europe)	531 kHz ~ 1, 602 kHz
MW (AM) tuning frequency range (for other countries)	530 kHz ~ 1, 610 kHz

General

power consumption	60 W
dimensions (W x H x D)	180 mm x 239 mm x 305 mm
weight (net)	5.7 kg

Speaker Section

woofer size	100 mm
tweeter size	50 mm
impedance	6 Ω

MD Recorder Section

dimensions (W x H x D)	150 mm x 234 mm x 197 mm
weight (net)	2.4 kg
maximum input level	30 W
