Kenwood RXD-M32MD User Manual

RXD-M32MD
53
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
C29 CK73GB1H221K CHIP C 220PF K
C30 CK73GB1H103K CHIP C 0.010UF K
C31 C92-0095-05 CHIP C 330UF 6.3WV
C32 CC73FSL1H101J CHIP C 100PF J
C33 CK73GB1H102K CHIP C 1000PF K
C34 CK73GB1C104K CHIP C 0.10UF K
C35 C92-0084-05 CHIP C 100UF 4WV
C36 CK73GB1H103K CHIP C 0.010UF K
C38 CK73GB1H102K CHIP C 1000PF K
CN1 E40-9963-05 FLAT CABLE CONNECTOR
CN2 ✽ E40-8600-05 FLAT CABLE CONNECTOR
CN3 E40-3248-05 PIN ASSY
L1 ,2 L40-1001-31 SMALL FIXED INDUCTOR (10UH,K)
L3 ✽ L33-0591-05 SMALL FIXED INDUCTOR
L4 L40-1001-31 SMALL FIXED INDUCTOR (10UH,K)
L5 L92-0308-05 FERRITTE CORE
X1 ✽ L77-2295-05 CRYSTAL RESONATOR (33.8688MHZ)
R1 RK73GB1J224J CHIP R 220K J 1/16W
R6 RK73GB1J224J CHIP R 220K J 1/16W
R7 RK73GB1J100J CHIP R 10 J 1/16W
R8 ,9 RK73GB1J273J CHIP R 27K J 1/16W
R10 RK73GB1J622J CHIP R 6.2K J 1/16W
R11 ,12 RK73GB1J101J CHIP R 100 J 1/16W
R13 ,14 RK73GB1J103J CHIP R 10K J 1/16W
R15 RK73GB1J153J CHIP R 15K J 1/16W
R16 RK73GB1J273J CHIP R 27K J 1/16W
R17 RK73GB1J474J CHIP R 470K J 1/16W
R18 RK73GB1J364J CHIP R 360K J 1/16W
R19 RK73GB1J102J CHIP R 1.0K J 1/16W
R20 RK73GB1J472J CHIP R 4.7K J 1/16W
R21 RK73GB1J182J CHIP R 1.8K J 1/16W
R22 RK73GB1J224J CHIP R 220K J 1/16W
R23 RK73GB1J154J CHIP R 150K J 1/16W
R24 RK73GB1J133J CHIP R 13K J 1/16W
R25 RK73GB1J225J CHIP R 2.2M J 1/16W
R26 ,27 RK73GB1J153J CHIP R 15K J 1/16W
R28 RK73GB1J104J CHIP R 100K J 1/16W
R29 RK73GB1J333J CHIP R 33K J 1/16W
R30 RK73GB1J104J CHIP R 100K J 1/16W
R31 RK73GB1J105J CHIP R 1.0M J 1/16W
R32 RK73GB1J103J CHIP R 10K J 1/16W
R33 ,34 RK73GB1J332J CHIP R 3.3K J 1/16W
R35 RK73GB1J472J CHIP R 4.7K J 1/16W
R36 RK73GB1J511J CHIP R 510 J 1/16W
R37 ,38 RK73GB1J221J CHIP R 220 J 1/16W
R40 RK73GB1J471J CHIP R 470 J 1/16W
R41 ,42 RK73GB1J105J CHIP R 1.0M J 1/16W
R43 -48 RK73GB1J273J CHIP R 27K J 1/16W
R49 RK73GB1J100J CHIP R 10 J 1/16W
R50 RK73GB1J473J CHIP R 47K J 1/16W
R51 RK73GB1J101J CHIP R 100 J 1/16W
R52 RK73GB1J221J CHIP R 220 J 1/16W
R53 RK73GB1J101J CHIP R 100 J 1/16W
R54 -59 RK73GB1J221J CHIP R 220 J 1/16W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
^
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
Q9 2SC4116(Y,GR) TRANSISTOR
Q10 2SD2012 TRANSISTER
Q10 2SD2061 TRANSISTER
Q11 ,12 ✽ 2SC2362(G,H) TRANSISTOR
Q13 ✽ 2SA1016(G,H) TRANSISTOR
Q21 2SB1640 TRANSISTOR
Q91 ✽ 2SC2362(G,H) TRANSISTOR
Q92 ✽ 2SA1016(G,H) TRANSISTOR
Q101 2SC2458(Y,GR) TRANSISTOR
Q101 2SC2785(F,E) TRANSISTOR
Q102 2SC2003(L,K) TRANSISTOR
Q103 2SB764(E,F) TRANSISTOR
Q104 2SA1286-T11 TRANSISTOR
Q105,106 DTC124ESA DIGITAL TRANSISTOR
Q105,106 UN4212 DIGITAL TRANSISTOR
Q107 2SC2458(Y,GR) TRANSISTOR
Q107 2SC2785(F,E) TRANSISTOR
Q108 2SC4081(R,S) TRANSISTOR
Q108 2SC4116(Y,GR) TRANSISTOR
Q109 2SD863(E,F) TRANSISTOR
Q110 DTA124ESA DIGITAL TRANSISTOR
Q110 UN4112 DIGITAL TRANSISTOR
Q111,112 DTC124ESA DIGITAL TRANSISTOR
Q111,112 UN4212 DIGITAL TRANSISTOR
Q113 DTA124ESA DIGITAL TRANSISTOR
Q113 UN4112 DIGITAL TRANSISTOR
Q114 DTC124ESA DIGITAL TRANSISTOR
Q114 UN4212 DIGITAL TRANSISTOR
Q117 2SC2003(L,K) TRANSISTOR
Q118 2SA1286-T11 TRANSISTOR
Q119 DTC124ESA DIGITAL TRANSISTOR
Q119 UN4212 DIGITAL TRANSISTOR
Q120 2SC3246 TRANSISTOR
C1 ,2 C92-0084-05 CHIP C 100UF 4WV
C3 CC73GCH1H150J CHIP C 15PF J
C4 CC73GCH1H100D CHIP C 10PF D
C5 C92-0084-05 CHIP C 100UF 4WV
C6 C92-0044-05 CHIP-ELE 47UF 10WV
C7 CK73FB1C104K CHIP C 0.10UF K
C8 CK73FB1H563K CHIP C 0.056UF K
C9 C92-0085-05 CHIP C 220UF 4WV
C10 CC73GCH1H471J CHIP C 470PF J
C11 CK73FB1H223K CHIP C 0.022UF K
C12 CK73GB1H221K CHIP C 220PF K
C13 CK73FB1C474K CHIP C 0.47UF K
C14 CK73GB1H332K CHIP C 3300PF K
C15 CK73GB1H103K CHIP C 0.010UF K
C16 CK73GB1C473K CHIP C 0.047UF K
C17 CK73GB1H152K CHIP C 1500PF K
C18 ,19 CC73GCH1H150J CHIP C 15PF J
C20 CK73GB1H103K CHIP C 0.010UF K
C21 ,22 CC73FCH1H681J CHIP C 680PF J
C23 ,24 CC73GCH1H101J CHIP C 100PF J
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
%
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
CD PLAYER UNIT (X32-3810-00)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299

Kenwood RXD-M32MD Specifications

Amplifier Section

effective output power during STEREO operation	20 W + 20 W
rated output power during STEREO operation	15 W + 15 W
wow and flutter	0.2 %

Tuner Section

FM tuning frequency range	87.5 MHz ~ 108 MHz
MW (AM) tuning frequency range (for U.K. and Europe)	531 kHz ~ 1, 602 kHz
MW (AM) tuning frequency range (for other countries)	530 kHz ~ 1, 610 kHz

General

power consumption	60 W
dimensions (W x H x D)	180 mm x 239 mm x 305 mm
weight (net)	5.7 kg

Speaker Section

woofer size	100 mm
tweeter size	50 mm
impedance	6 Ω

MD Recorder Section

dimensions (W x H x D)	150 mm x 234 mm x 197 mm
weight (net)	2.4 kg
maximum input level	30 W
