KERN 440 Operating Instructions

440-BA-defsi-0634
31
KERN 440-35N 440-35A 440-43N 440-45N
Readout 0,01 g 0,01 g 0,1 g 0,1 g
Weighing range 400 g 600 g 400 g 1000 g
Taring range (subtractive) 400 g 600 g 400 g 1000 g
Reproducibility 0,01 g 0,01 g 0,1 g 0,1 g
Linearity ±0,03 g ±0,03 g ±0,2 g ± 0,2 g
Min. weight for counting parts 0,02 g 0,02 g 0,2 g 0,2 g
Reference pieces for counting
parts
5, 10, 25, 50
Unites
details „Weighing units“ capture 7.8
Test weight (included)
The details can be found in
capture 8.3 „Select the adjust-
ing weight“
200g (M1) 500g (M1) 200 g (M3) 500 g (M2))
Stabilisation time (typical) 3 sec.
Optimal temp. of operation + 10° C .... + 40° C
Humidity max. 80 % (non-condensing)
Size (W x D x H) mm 165 x 230 x 80
Weighing plate mm Ø 105 Ø 105 130 x 130 130 x 130
Weight kg (net) 1,0 1,0 1,0 1,0
Underfloor weighing Standard
Hook for underfloor weighing Option
