KERN 440 Operating Instructions

440-BA-defsi-0634
32
KERN 440-47N 440-49N 440-49A
Readout 0,1 g 0,1 g 0,1 g
Weighing range 2000 g 4000 g 6000 g
Taring range (subtractive) 2000 g 4000 g 6000 g
Reproducibility 0,1 g 0,1 g 0,1 g
Linearity ± 0,2 g ± 0,3 g ± 0,3 g
Min. weight for counting parts 0,2 g 0,2 g 0,2 g
Reference pieces for counting
parts
5, 10, 25, 50
Unites
details „Weighing units“ capture 7.8
Test weight (included)
The details can be found in
capture 8.3 „Select the adjusting
weight“
1000 g (M1) 2000 g (M1) 2000 g (M1)
Stabilisation time (typical) 3 sec.
Optimal temp. of operation + 10° C .... + 40° C
Humidity max. 80 % (non-condensing)
Size (W x D x H) mm 165 x 230 x 80
Weighing plate mm 130 x 130 150 x 170 150 x 170
Weight kg (net) 1,0 1,0 1,0
Underfloor weighing Standard
Hook for underfloor weighing Option

KERN 440 Specifications

General

Brand	KERN
Model	440
Category	Scales
Language	English
