KERN 440 Operating Instructions

440-BA-defsi-0634
30
1 Technical data
KERN 440-21N 440-21A 440-33N
Readout 0,001 g 0,001 g 0,01 g
Weighing range 40 g 60 g 200 g
Taring range (subtractive) 40 g 60 g 200 g
Reproducibility 0,001 g 0,001 g 0,01 g
Linearity ±0,003 g ±0,003 g ±0,0 2 g
Min. weight for counting parts 0,002 g 0,002 g 0,02 g
Reference pieces for counting
parts
5, 10, 25, 50
Unites
details „Weighing units“ capture 7.8
Test weight (included)
The details can be found in
capture 8.3 „Select the adjusting
weight“
20g (F2) 50g (F2) 100g (M1)
Stabilisation time (typical) 3 sec.
Optimal temp. of operation + 10° C .... + 40° C
Humidity max. 80 % (non-condensing)
Size (W x D x H) mm 165 x 230 x 80
Weighing plate mm Ø 81 Ø 81 Ø 105
Weight kg (net) 1,0 1,0 1,0
Underfloor weighing - - Standard
Hook for underfloor weighing - - Option
