Octal Decimal Hexadecimal Sign
12 10 OA LF
Line feed
15 13 OD CR
Carriage return
40 32 20 sp
space pace
53 43 2B +
55 45 2D -
56 46 2E .
60 48 30 0
61 49 31 1
62 50 32 2
63 51 33 3
64 52 34 4
65 53 35 5
66 54 36 6
67 55 37 7
70 56 38 8
71 57 39 9
12.2 Setting of the interface
The output has to be adapted for special requirements (see point 10 „General
programmations).
The output format, the output conditions, the Baud rate and the parity can be set.
12.3 Additional technical data
Transfer format: serial data transfer
8-bit word length (standard-ASCII-format)
1 Start-Bit
2 Stop-Bits
Parity 0 or 1 (see point 10 „General programmations“)
Baud rate: 1200 baud/2400 baud/4800 baud can be set.
(see point 10“General programmations“)
Signal level: TTL
